Summary of Contents for Zotac ZBOX PRO
- Page 2 ZOTAC. Products and corporate names mentioned in this manual may be registered trademarks or copyrights of their respective companies, and are used for identification purposes only.
-
Page 3: Table Of Contents
Table of Contents Specifications ----------------------------------------------------------------------------------------------------3 Safety instructions----------------------------------------------------------------------------------------------5 Package contents -----------------------------------------------------------------------------------------------6 Getting to know your ZP-S35N150 ------------------------------------------------------------------------7 Front view -----------------------------------------------------------------------------------------------------7 Rear view ------------------------------------------------------------------------------------------------------8 Left view -------------------------------------------------------------------------------------------------------9 Right view -----------------------------------------------------------------------------------------------------9 Installing hardware inside ZP-S35N150 -----------------------------------------------------------------10 Installing a memory module -------------------------------------------------------------------------------10 Removing the memory module --------------------------------------------------------------------------11 Installing M.2 SSD module --------------------------------------------------------------------------------12 Installing drivers and software -----------------------------------------------------------------------------14 Installing an operating system ----------------------------------------------------------------------------14... -
Page 4: Specifications
Specifications Microprocessor Support • Intel TwinLake processor N150, Quad Cores, base clock 1.0GHz, up to 3.6GHz, 6MB cache, 6W TDP Onboard Graphics Support • Integrated Intel UHD Graphics up to 1,000MHz graphics frequency with 24 Execution Units • 2x HDMI 2.0output, max resolution 4096x2160@60Hz Operating Systems •... -
Page 6: Safety Instructions
Safety instructions ZP-S35N150 is designed and tested to meet the latest standards of safety for information technology equipment. However, to ensure your safety, it is important that you read the following safety instruc- tions. Read and follow all instructions in the documentation before you operate your system. ™... -
Page 7: Package Contents
Package contents Thank you for choosing our ZP-S35N150. The following illustration displays the package contents of your new ZP-S35N150. If any of the below items are damaged or missed, contact your retailer. • 1 x ZP-S35N150 • 1 x L-shape mount, mount screws •... -
Page 8: Getting To Know Your Zp-S35N150
Getting to know your ZP-S35N150 Front view 1. RS-485 RS-485 uses two signal lines (A and B) to transmit data differentially, and a ground line (G) to provide a reference for the signals. This setup allows for reliable communication over longer distances and in noisy environments. -
Page 9: Rear View
Rear view 1. Power input (DC19V) The supplied power adapter converts AC power to DC power for use with this jack. Power supplied through this jack supplies power to the PC. To prevent damage to the PC, always use the supplied power adapter. 2. -
Page 10: Left View
Left view 1. COM port Use the COM port to connect serial devices such as mouse or fax/modem. Right view 1. WiFi antenna connectors The WiFi antenna connector supports WiFi antenna module. -
Page 11: Installing Hardware Inside Zp-S35N150
Installing hardware inside ZP-S35N150 Installing a memory module 1. Insert the memory module into the socket. 2. Gently press down on the memory module until it is locked by the arms of the socket. -
Page 12: Removing The Memory Module
Removing the memory module 1. Locate the SO-DIMM memory slot and gently press the two arms securing the memory module outwards, as shown in the image below, to release the memory module. 2. Remove the memory module from the slot at a 45-degree angle. -
Page 13: Installing M.2 Ssd Module
Installing M.2 SSD module 1. Locate the mounting screw for the M.2 SSD module and use a screwdriver to loosen and remove the mounting screw from the bolt. 2. Attach the screw removed in the previous step into the screw notch on the M.2 SSD module. - Page 14 3. Insert the M.2 SSD module into the slot. 4. Tighten the screw with a screwdriver so that the M.2 SSD module is in place.
-
Page 15: Installing Drivers And Software
Installing drivers and software Installing an operating system The ZP-S35N150 does not ship with an operating system preinstalled. The user must install the operating system before the ZP-S35N150 can be used. The following operating systems are supported: • Windows 11 •... - Page 16 The following drivers are available on the USB flash drive: • Intel Chipset Driver • Intel Graphics Driver • Intel SerialIO Driver • Realtek Ethernet PCI-E Driver • Wireless Network Driver • Bluetooth Driver • Intel Management Engine Each driver must be installed individually to ensure proper operation of the ZP-S35N150. ...
-
Page 17: Using Your Zp-S35N150
Using your ZP-S35N150 Configuring a wireless connection Please follow the instructions below to connect to a wireless network: Click the icon on the right of wireless network icon Select the wireless network you want to connect to from the list. Note 1: For security concerns, Do NOT connect to an unsecured network, otherwise, the transmitted information without encryption might be visible to others.
