- Page 2 ZOTAC. Products and corporate names mentioned in this manual may be registered trademarks or copyrights of their respective companies, and are used for identification purposes only.
- Page 3 Notes: This manual also apply for below series, the CPU, GPU and graphic memory configuration may vary, more detail can refer to ZOTAC website. ZP-QTG73060C series ZP-QTG73070C series ZP-QTG73080C series...
-
Page 4: Table Of Contents
Table of Contents Specifications ----------------------------------------------------------------------------------------------------3 Safety instructions----------------------------------------------------------------------------------------------5 Package contents -----------------------------------------------------------------------------------------------6 Getting to know your ZP-QTG7A4500 --------------------------------------------------------------------7 Front view -----------------------------------------------------------------------------------------------------7 Rear view ------------------------------------------------------------------------------------------------------8 Installing hardware inside ZP-QTG7A4500 -------------------------------------------------------------9 Installing an M.2 SSD module ----------------------------------------------------------------------------10 Installing a memory module -------------------------------------------------------------------------------12 Installing a hard disk drive ---------------------------------------------------------------------------------13 Installing the L-shaped mountings ------------------------------------------------------------------------16 Installing your ZP-QTG7A4500 to a monitor -----------------------------------------------------------17 Setting up your ZP-QTG7A4500 ----------------------------------------------------------------------------18... -
Page 5: Specifications
Specifications Microprocessor Support • 11th generation Intel Core i7-11850HE, Octa-core running at 2.6GHz/4.7GHz, 24MB cache, 45W TPD Chipset • Intel HM570 Mobile Chipset Onboard Graphics Support • NVidia RTX A4500 embedded GPU, 5,888 CUDA processor, 16GB GDDR6, 184 Tensor Cores, Max. -
Page 7: Safety Instructions
Safety instructions ZP-QTG7A4500 is designed and tested to meet the latest standards of safety for information tech- nology equipment. However, to ensure your safety, it is important that you read the following safety instructions. Read and follow all instructions in the documentation before you operate your system. ™... -
Page 8: Package Contents
Package contents Thank you for choosing our ZP-QTG7A4500. The following illustration displays the package contents of your new ZP-QTG7A4500. If any of the below items are damaged or missed, contact your retailer. • 1 x ZP-QTG7A4500 • 1 x L-shape mount, VESA mount screws •... -
Page 9: Getting To Know Your Zp-Qtg7A4500
Getting to know your ZP-QTG7A4500 Front view 1. Power button The power button turns the system ON and OFF. 2. USB 3.1 port The USB 3.1 port supports the SuperSpeed USB 3.1 device. Use this port for USB 3.1 devices for maximum performance with USB 3.1 compatible devices. -
Page 10: Rear View
Rear view 1. COM port Use the COM port to connect serial devices such as mouse or fax/modem. 2. Power input (DC19.5V) The supplied power adapter converts AC power to DC power for use with this power port. To prevent damage to the mini-PC, always use the supplied power adapter. 3. -
Page 11: Installing Hardware Inside Zp-Qtg7A4500
Installing hardware inside ZP-QTG7A4500 Before installing hardware, please follow the instructions below to remove the cover of your ZP-QTG7A4500. 1. Remove the four thumb screws of bottom cover. 2. Hold the bottom cover with two hands, and lift it up as shown below. -
Page 12: Installing An M.2 Ssd Module
Installing an M.2 SSD module 1. Locate the M.2 SSD slot and remove the screw on the bolt as shown below. 2. Attach the screw to the M.2 SSD module. - Page 13 3. Insert the M.2 SSD module into the slot. The M.2 SSD slot only support SATA SSD module. 4. Gently press down on the M.2 SSD module, and install the screw.
-
Page 14: Installing A Memory Module
Installing a memory module 1. Insert the memory module into the socket. 2. Gently press down on the memory module until it is locked by the arms of the socket. -
Page 15: Installing A Hard Disk Drive
Installing a hard disk drive 1. Unscrew and remove the hard disk drive bracket as shown below. 2. Locate the 2.5-inch SATA hard disk drive and the hard disk drive bracket. - Page 16 3. Install the hard disk drive/ SSD to the hard disk drive bracket. 4. Insert the hard disk drive /SSD into the socket and gently slide into the connector.
- Page 17 5. Reinstall the screw for the hard disk drive bracket. 6. Reinstall the bottom cover.
-
Page 18: Installing The L-Shaped Mountings
Installing the L-shaped mountings Locate the bottom cover upwards, and take out the L-shaped mounting kit and screws from accessory box. Install the L-shaped mountings to the bottom cover with screws. -
Page 19: Installing Your Zp-Qtg7A4500 To A Monitor
Installing your ZP-QTG7A4500 to a monitor You can also install your ZP-QTG7A4500 to the back of a monitor. To do so: Secure four screws (M4XH15.0MM) to your monitor (VESA100 standard). Place your ZP-QTG7A4500 to the monitor noting the correct alignment. Mechanical Loading Stability - Mounting of the equipment on the backside of the ... -
Page 20: Setting Up Your Zp-Qtg7A4500
Setting up your ZP-QTG7A4500 Please connect your peripherals before using your ZP-QTG7A4500. 1. Connecting a COM device Connect serial devices such as mouse or fax/modems. 2. Connecting to a network device Connect one end of a network cable to the LAN port on the system rear panel and the other End to a hub or switch. - Page 21 5. Connecting to HDMI displays Connect one end of an HDMI cable to an HDTV or monitor, and the other end to the HDMI port on the system rear panel. 6. Connecting to USB 3.1 devices Connect USB 3.1 devices such as external hard drives, SSDs and flash drives to the USB 3.1 port on the system rear panel.
-
Page 22: Installing Drivers And Software
Installing drivers and software Installing an operating system The ZP-QTG7A4500 does not ship with an operating system preinstalled. The user must install the operating system before the ZP-QTG7A4500 can be used. The following operating systems are supported: • Windows 11 •... - Page 23 The following drivers are available on the USB flash drive: • Intel Chipset Driver • NVIDIA Graphics Driver • Intel Graphics Driver • Intel Ethernet PCI-E Driver • Wireless Network Driver • Intel Management Engine • BayHub_SD Driver • Thunderbolt •...
-
Page 24: Using Your Zp-Qtg7A4500
Using your ZP-QTG7A4500 Configuring a wireless connection Please follow the instructions below to connect to a wireless network: Click the icon on the right of wireless network icon Select the wireless network you want to connect to from the list. Note 1: For security concerns, Do NOT connect to an unsecured network, otherwise, the transmitted information without encryption might be visible to others.
