Summary of Contents for Miele DAC 2247
- Page 1 Operating and installation instructions Ventilation hood To prevent accidents and damage to the appliance, you must read these instructions before installing the appliance and using it for the first time. en-US M.-Nr. 12 574 570...
-
Page 2: Table Of Contents
Con@ctivity....................... 16 Power management ....................16 Commissioning......................17 Selecting extraction mode or recirculation mode............17 Setting up Miele@home ....................18 Performing Scan & Connect ................... 18 Signing off Wi-Fi and remote control..............19 Setting up Con@ctivity ....................19 Activating Con@ctivity 3.0 via the home Wi-Fi network ........19 Activating Con@ctivity 3.0 via a direct Wi-Fi connection ......... - Page 3 Contents Customizing settings....................24 Intervals for the grease filter operating hours counter..........24 Changing the intervals for the grease filter operating hours counter....24 Intervals for the charcoal filter operating hours counter .......... 24 Altering or deactivating the charcoal filter operating hours counter intervals . 24 Safety shut-off......................
-
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS This appliance complies with current safety requirements. Improper use of the appliance can lead to personal injury and material damage. Read all instructions before installing or using the appliance for the first time. Only use the appliance for its intended purpose. Keep these operating instructions in a safe place and pass them on to any future user. -
Page 5: Technical Safety
Unauthorized installation, maintenance, and repairs can cause considerable danger for the user. Installation, maintenance, and repairs should only be carried out by a Miele authorized technician. A damaged ventilation hood can be dangerous. Always check for visible signs of damage. Never use a damaged ventilation hood. - Page 6 The function and operation of the protective measures provided in the domestic electrical installation and in this Miele product must also be maintained in isolated operation or in operation that is not synchronized with the grid power supply, or these measures must be replaced by equivalent measures in the installation.
-
Page 7: Correct Use
qualified service technician. The bulbs are a built-in component of the lighting. Replacement bulbs should only be installed by a Miele authorized technician or by Miele Service. Important information on handling the remote control battery: - Do not short circuit or recharge the battery, or throw it into a fire. - Page 8 IMPORTANT SAFETY INSTRUCTIONS WARNING: TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A COOKTOP GREASE FIRE, OBSERVE THE FOLLOWING*: - a) SMOTHER FLAMES with a close fitting lid, cookie sheet, or metal tray then turn off the burner. BE CAREFUL TO PREVENT BURNS.
-
Page 9: Proper Installation
IMPORTANT SAFETY INSTRUCTIONS Proper installation WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: - a) Installation work and electrical wiring must be done by qualified person(s) in accordance with all applicable codes and standards, including fire-rated construction. -
Page 10: Cleaning And Maintenance
The steam can reach the electrical components and cause a short circuit. Accessories and parts Use only genuine original Miele parts. If parts or accessories from other manufacturers are used, the warranty may become void. Defective components should be replaced by Miele original parts ... -
Page 11: Industry Canada Statement
IMPORTANT SAFETY INSTRUCTIONS FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 8" (20 cm) between the radiator and your body. Industry Canada Statement This digital apparatus does not exceed the Class B limits for Radio ... -
Page 12: Sustainability And Environmental Protection
Separately collecting old batteries and power packs facilitates Consult with local authorities, dealers or handling and recycling. Miele in order to dispose of and recycle electrical and electronic appliances. Miele assumes no responsibility for deleting any personal data left on the appliance being disposed. -
Page 13: Familiarization
Familiarization Guide to the ventilation hood... -
Page 14: Components
Familiarization Components a Exhaust duct Exhaust air can be directed to the Grease filters and panel left-hand side, to the rear, or to the front. The edge extraction panel and the re- usable metal grease filters in the b Overhead lighting appliance remove solid particles c Ventilation grille for recirculation (grease, dust, etc.) from the kitchen... -
Page 15: Functions
Familiarization Blower power levels Functions Select power levels 1 to 3 for light to Extraction mode heavy cooking vapors, odors, or heat. Increase the power level as the level of vapors, odors, or heat increases. For short periods of cooking food with intensive vapors, odors, or heat, e.g., The air is drawn in and cleaned by the when searing meat, select Booster level... -
Page 16: Miele@Home
You can connect the ventilation hood to The ventilation hood is equipped with a your home Wi-Fi network and operate it power management system. Power using the Miele app on your mobile management helps to save energy. It device. ensures that the blower power level is... -
Page 17: Commissioning
Commissioning Activating/deactivating Settings are made via the ventilation Plug&Play hood control panel, not via the remote control. Switch off the blower and the lighting. Press the delayed shutdown Selecting extraction mode or control for approx. 10 seconds recirculation mode until 1 lights up. -
Page 18: Setting Up Miele@Home
Apple App app. ® Store or the Google Play Store™. Install the Miele app and set up a user Before installing the ventilation hood account. in its final location, ensure that the signal of your WiFi network is strong ... -
Page 19: Signing Off Wi-Fi And Remote Control
Prerequisites: - Home Wi-Fi network The sign-off process will always sign off the Wi-Fi and a connected remote - Wi-Fi-enabled Miele cooktop control at the same time. Connect the ventilation hood and Switch the ventilation hood off. cooktop to your home Wi-Fi network (see “Setting up Miele@home”). -
Page 20: Reattempting The Connection
Commissioning Preparing the remote control With a direct Wi-Fi connection, it is not possible to connect the cooktop Insert the batteries into the remote and the ventilation hood to a home control; see “Cleaning and care – network. Should this be required at a Inserting/replacing batteries”. -
Page 21: Operation (Automatic)
Operation (automatic) Frying with Con@ctivity Cooking with Con@ctivity over an electric cooktop For example, you switch on a cooking zone at the highest power level to Switch on a cooking zone at any heat cookware for frying. You reduce power level. -
Page 22: Temporarily Exiting Automatic Mode
Operation (automatic) Exiting Automatic mode for the entire Temporarily exiting Automatic cooking process mode Switch the blower on before the To exit Automatic mode temporarily: cooktop. Manually select a different blower Con@ctivity is deactivated until the power level, or ventilation hood is switched off. -
Page 23: Operation (Manual)
Operation (manual) Cooking without Con@ctivity Turning off the blower (Manual mode) Press the On/Off control to turn the blower off. The ventilation hood can be operated manually if: The symbol will go out. - The Con@ctivity function is not Delayed shutdown in Plug&Play activated. -
Page 24: Customizing Settings
Customizing settings If the selection is not confirmed within Settings are made via the ventilation 4 minutes, the system will revert to the hood control panel, not via the remote previous setting. control. Intervals for the charcoal filter Intervals for the grease filter operating hours counter operating hours counter The factory default setting is an interval... -
Page 25: Activating/Deactivating Power Management
Customizing settings Safety shut-off Activating/deactivating power management If power management has been deactivated, the ventilation hood will Keep in mind that deactivating this switch itself off automatically after function may increase energy 12 hours if it has been left on (blower consumption. -
Page 26: Energy-Saving Tips
Energy-saving tips This hood operates in a very efficient - Use the Con@ctivity function. The and energy-saving manner. The ventilation hood will switch on and off following will help you to save even automatically. The ventilation hood more energy when using it: will select the optimum power level for the cooking you are doing, which - Ensure that there is sufficient... -
Page 27: Cleaning And Care
Before proceeding with any stainless steel care product (available maintenance or cleaning task, the from Miele). ventilation hood must be disconnected from the power supply, Important information on see “IMPORTANT SAFETY cleaning the casing INSTRUCTIONS”. -
Page 28: Condensation On The Panel
Cleaning and care Condensation on the panel Condensation forms on the panel during cooking and evaporates once cooking is complete. Wait approximately 2 hours after finishing cooking before removing the panel. This will allow time for the condensation to evaporate and avoid dripping water. - Page 29 Cleaning and care Cleaning the grease filters by hand Important information on cleaning in a dishwasher Clean the grease filters with a soft nylon brush in a mild solution of hot Excessively high temperatures can water and a little liquid dish soap. Do render the grease filters unusable (due not use concentrated dish soap.
-
Page 30: Inserting The Panel
If you identify any damage, replace the grease filters. Grease filters are available to order via Miele Service (see end of these operating instructions for contact details) or from your Miele dealer. OdorFree Charcoal Filter Reactivation interval for the charcoal... -
Page 31: Resetting The Charcoal Filter Operating Hours Counter
Cleaning and care Remote control Inserting/replacing batteries The remote control requires 2 batteries, 1.5 V, type AAA. The batteries are supplied with the remote control and must be inserted before using for the first time. The batteries must be replaced if ventilation hood functions can no longer be selected using the remote control. -
Page 32: Customer Service
In the event of a fault which you cannot remedy yourself, please contact your Miele dealer or Miele Customer Service. You can book a Miele Service Call online at www.miele.com/service. Contact information for Miele Customer Service can be found at the end of this document. -
Page 33: Installation
Have specialists carry out the coating process. Clean the panel at regular intervals. Follow the cleaning instructions provided by the manufacturer of the coating used. Miele does not guarantee the durability of the coating. -
Page 34: Appliance Dimensions
Installation Appliance dimensions DAC 2247 in vented mode... - Page 35 Installation DAC 2247 in recirculation mode and Plug&Play recirculation mode...
- Page 36 Installation a Exhaust duct 6" (150 mm) The duct is installed on the left-hand side at the factory. – If you want to install the duct at the front or rear, you can rotate the blower casing by 90° during installation. To rotate the casing, there must be a clearance of 4" (100 mm) in the ceiling in front of and behind the ceiling cut- out.
-
Page 37: Distance Between Cooktop And Ventilation Hood (S)
Please also observe the information contained in the “IMPORTANT SAFETY INSTRUCTIONS” section. Minimum distance S Cooking appliance Miele Non-Miele appliance appliance Electric Cooktops 24" (610 mm) Electric Barbeques and Fryers 26"... -
Page 38: Installation Notes
Installation structure can support the load. Installation notes Around the clamps, components such - A minimum distance of 27 ⁹/₁₆" as supports and ducting must be at (700 mm) and a maximum distance of least 1" (25 mm) from the cut-out. 51 ³/₁₆" (1,300 mm) is recommended - If you install the appliance in a place between the cooktop and the that is used on a daily basis, e.g., in a... -
Page 39: Air Venting
(see “Appliance If the exhaust is ducted through an dimensions”). This applies in outside wall, a Miele wall vent or roof particular when using flat ducting. vent (available as an optional accessory) is recommended. Both of these have a - The ducting should be as short and built-in non-return flap. -
Page 40: Condensate
³/₈" (1 cm) per meter. This is to ensure that condensate cannot drain back into the ventilation hood. Miele will not accept warranty claims If you would like to reduce the for any functional defects or damage environmental impact of your ventilation caused by inadequate ducting. -
Page 41: Electrical Connection
If there is any question concerning accordance with CSA C22.1-12, the electrical connection of this Canadian Electrical Code, Part I. appliance to your power supply, please consult a licensed electrician or call Miele’s Technical Service Department. WARNING: THIS APPLIANCE MUST BE GROUNDED... -
Page 42: Technical Data
Technical data Blower motor 180 W Overhead lighting 2 x 7.2 W Total rated load 194.4 W Light temperature for the overhead lighting 3,500 K Voltage, frequency 120 V AC, 60 Hz Fuse rating 10 A Power supply cord length 2.3 ft (0.7 m) Weight 49.1 lbs (22.3 kg) WiFi module Frequency range 2.400–2.4835 GHz Maximum transmission power <... - Page 43 Customer Service. U.S.A. Canada Miele, Inc. Importer Miele Limited National Headquarters Headquarters and Miele Centre 9 Independence Way 161 Four Valley Drive Princeton, NJ 08540 www.mieleusa.com Vaughan, ON L4K 4V8 www.miele.ca Customer Support Phone: 888-99-MIELE (64353) Customer Care Centre info@mieleusa.com...
- Page 44 DAC 2247 en-US M.-Nr. 12 574 570 / 01...
