GAIN
Main distortion control.
INPUT STAGE
PREGAIN
Makes the
incoming signal
hotter or colder.
CUTOFF
Pre-distortion
filter for the
incoming signal.
XOVER
Hold for 1 second to enable.
CUTOFF sets the crossover frequency.
If SWAP is ON: Distorted lows go to DIRTY, clean highs to CLEAN
If SWAP is OFF: Distorted HIGHS go to DIRTY, clean lows to CLEAN
TONE
More Bass
Scooped Mids
QUICK START
GODEATER+
NORMAL MODE
More Treble
SWAP
Hold for 1 second to enable. Square lights up.
ON: Input filter (CUTOFF knob) is LOW pass
OFF: Input filter is HIGH pass. (default mode)
DIRTY
Volume control
for distortion
path
CLEAN
Volume control
for clean path
BASS
Adds or reduces
bass depth of
the TONE knob
BYPASS
Relay true bypass.
Turn effect on/off.
Advertisement
Related Manuals for Animal Factory Amplification GODEATER+ NORMAL MODE
Summary of Contents for Animal Factory Amplification GODEATER+ NORMAL MODE
- Page 1 QUICK START GODEATER+ NORMAL MODE TONE GAIN More Bass Scooped Mids More Treble Main distortion control. DIRTY Volume control INPUT STAGE for distortion path PREGAIN CLEAN Makes the Volume control incoming signal for clean path hotter or colder. BASS CUTOFF Adds or reduces Pre-distortion bass depth of...
- Page 2 QUICK START GODEATER+ SIDECHAIN MODE SIDE SWITCHES (RIGHT) You can control PREGAIN, CUTOFF and TONE. Select which knob to control by pressing the TARGET button. These LEDs indicate which direction the sidechain “turns” Select the response of the the knob. Press DIRECTION sidechain filter (FREQ) with this button to select this.
- Page 3 GODEATER+ SIGNAL FLOW SWAP HP/LP UNATTENUATED DISTORTION ONLY DISTORTION CIRCUIT Goes to BALANCED PATH FILTER PRE-GAIN GAIN CLIP STAGES BASS TONE DIRTY 1 and 2 INPUT BUFFER LOW PASS JACK DIODE MAIN OUTPUT MIXER HIGH PASS STAGE NORMAL (DEFAULT) PATH INPUT STAGE CLEAN BUFFER...
- Page 4 GODEATER+ SIGNAL ROUTING DEFAULT MODE SPLIT OUTPUT MODE ON SWAP OFF DIRTY DIRTY INPUT JACK BUFFER INPUT FILTER DISTORTION DISTORTION FILTER JACK MAIN MAIN OUTPUT OUTPUT MIXER SWAP ON STAGE CLEAN CLEAN BUFFER CLEAN BOOST CLEAN BOOST OUTPUT XOVER ON (SWAP OFF) MIXER BALANCING STAGE...
