GE Profile PDT715SBN Dimensions And Installation Information

PDT715SBN/SFN/SMN/SYN
GE Profile Series Stainless Steel Interior Dishwasher with Hidden Controls
™
DIMENSIONS AND INSTALLATION INFORMATION (IN INCHES)
ELECTRICAL RATING
Voltage AC................................................................120
Hertz..........................................................................60
Total connected load amperage................................6.6
Calrod heater watts max................................800/500
®
For use on adequately wired 120-volt, 6.6-amp circuit
having 2-wire service with a separate ground wire.
This appliance must be grounded for safe operation.
INSTALLATION INFORMATION: Before installing,
consult installation instructions packed with product
for current dimensional data.
For answers to your GE Profile
website at geappliances.com or call GE Answer Center® Service, 800.626.2000.
This Wall Area
must be Free
of Pipes or
wires
33-1/2" to 34-3/4"
Underside of
Countertop
to Floor
Plumbing and Electric Service
Must Enter Inside This Area
Figure A
24"
Min.
or GE appliances product questions, visit our
™
33-3/8" MIN.
adj to
34-5/8" MAX.
24"
Min.
4"
Cabinets
Square
and
6"
Plumb
Certified to NSF
Standard 184 for
sanitization
24"
23-3/4"
Typical
29-7/8"
Overall depth including
handle: 25.6"
4" (toekick)
Listed by
Underwriters
Laboratories
27-1/2"
As an ENERGY STAR ®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
Specification Revised 6/20
