Summary of Contents for Phantom A10
- Page 1 A10 Electric Scooter USER MANUAL...
-
Page 2: Table Of Contents
Contents Product Features Accessories Specifications Assembly Charger Your Scooter How To Ride Folding Unfolding Phantomgogo APP Safety Precautions Cleaning And Storage Tire Inflation Maintenance Battery Maintenance Environmental Protection After-sales Service Non-warranty Rule Warranty Content User Stub Manufacturer Stub Fault Code... -
Page 3: Product Features
Product Features Handlebar Accelerator Brake lever Folding hook Front tube Hook fixing buckle Motor unit Folding handle Charging port Atmosphere light Gear mode: is for walking mode, and its maximum speed is about 3 mph; tthe ambient light will blink when this mode is enabled. -
Page 4: Specifications
Specifications Name Electric Scooter Product Model Vehicle: L × W × H (in) 45×17.5×48 Dimensions After Folding: L × W × H 45×17.5×20.3 (in) Net Weight Vehicle Net Weight (lb) 38.0 Max. Load (lb) Rider Age (years) Height (in) 4.72~7.87 Max. - Page 5 Model C1387A3 Nominal Voltage (VDC) 36.5 Max. Charge Voltage (VDC) Rated Energy (Wh) Battery Pack Rated Capacity (Ah) Normal Charging 0 to 45 Temperature Range (°C) Over-heating, short Intelligent Battery circuit, over-current, Management System over-discharge, and over-charge protection Wheel Motor Rated Power (W) FY-4201700/ Model...
-
Page 6: Assembly
Assembly 1. Pull the folding handle upwards until an audible click is heard. then pull the folding handle confirming the lock is in place. 2. Manually connect the handlebar and data cable in the front tube Once connected, check if the scooter powers on normally. 3. -
Page 7: How To Ride
Attention: ● Only use the original power adapter when charging. ● Keep away from children and animals when charging, and keep away from flammable materials. ● Do not charge or use the battery if it emits a peculiar smell, overheats or leaks. -
Page 8: Folding
3. While riding, place the other foot on the pedal and lightly press the accelerator to engage the motor. 4. When steering or decelerating, release the accelerator and use the brake lever to brake. Folding Turn off the scooter, press the red safety lock, and release the folding handle;... -
Page 9: Unfolding
Unfolding Remove the folding hook from the hook fixing buckle, straighten the front tube, close the folding handle until there is a“click”sound; flip the folding handle and confirm whether it is locked. -
Page 10: Phantomgogo App
Phantomgogo APP Scan QR code with your mobile phone to download and install the APP. If the APP has been installed on your mobile phone, make sure that the APP is the latest. STEP 1 Press the button to turn on the scooter and then turn on the Bluetooth function of your mobile phone. - Page 11 Scooter Maintenance Schedule (Recommended): Maintaining the scooter regularly can help keep the scooter neat and in good condition, avoid safety hazards, minimize breakdowns, slow down the deterioration of the scooter, and extend the scooter's service life.
-
Page 12: Safety Precautions
Safety Precautions 1. Please carefully read the User Manual, which will assist in explaining the basic working principles and provide tips on how to best enjoy your scooter experience. 2. Please wear all appropriate safety and protective gear as previously mentioned in the User Manual before operating the scooter. - Page 13 15. Do not ride in or near pools or other large bodies of water. 16. Traffic in the city has many obstacles to cross such as curbs or steps. lt is important to anticipate and adapt your trajectory and speed to those of a pedestrian before crossing these obstacles.
- Page 14 distances. 31. Do not step forward off your scooter. 32. Do not attempt to jump on or off your scooter. 33. Do not attempt any stunts or tricks with your scooter. 34. Do not ride the scooter in dark or poorly lit areas. 35.
- Page 15 47. WARNING! It is recommended to preform periodic inspections of the frame, fork and suspension attachments (if any). 48. Regularly check the tightening of the various bolted elements. in particular the wheel axles, the folding system, the steering system and the brake shaft.
- Page 16 following conditions shall be cautioned not to operate: Those with heart conditions: Persons with head, back, or neck ailments, or prior surgeries to those areas of the body. 59. an intentional or unintentional radiator shall caution the user thatchanges or modifications not expressly approved by the partyresponsible for compliance could avoid the user's authority to operate the equipment.
-
Page 17: Cleaning And Storage
Cleaning And Storage If there are stains on the surface of the scooter, use a soft cloth and dip in a small amount of water to wipe; lf there are stains that are difficult to clean, smear them with toothpaste and brush them repeatedly, then clean them with a damp cloth. - Page 18 product; it is forbidden to throw this product into water, fire (including heat sources such as stove, heater, etc.) or expose it to an environment with a temperature higher than 122°F. 3. Water entering the battery may cause damage to the internal circuit, and there is a risk of fire or even explosion;...
-
Page 19: Environmental Protection
Environmental Protection This product contains battery or recyclable electronic waste, and the built-in rechargeable battery contains substances that may pollute the environment. When disposing of the product, please do not pile it with general household waste, but hand it to the electronic waste collection point designated by the state, which is beneficial to environmental protection. -
Page 20: Warranty Content
Warranty Content Type Parts Times Frame, Hub Motor, Auxiliary Hub, Handlebar, Hood Cover, Front Fork Main Parts 12 Months Cover, Folding Riser Set, Mechanical Brake Line Battery, Charger, Dial, Headlight, Tailight Accessories 6 Months Brake lever, Instrumentation, Controller Handlebar Grip, Front/Rear Tire, Front Fender, Rear Fender, Silicone Mats, Warning Reflective Stickers, Kickstand, Wearing... -
Page 21: User Stub
User Stub User information (Please fill in the real information.User information will only be used for after-sales warranty services). User name: Phone number: E-mail: Postal code: Address: Product information Product name: Model: SN code: Color: Date of manufacture: Service: Return Replace Repair Fault phenomenon:... -
Page 22: Manufacturer Stub
Manufacturer Stub User information (Please fill in the real information.User information will only be used for after-sales warranty services). User name: Phone number: E-mail: Postal code: Address: Product information Product name: Model: SN code: Color: Date of manufacture: Service: Return Replace Repair Fault phenomenon:... -
Page 23: Fault Code
Fault Code Description of Corresponding Code Solution Fault Content Parts Undervoltage, Please charge in time. Battery low battery Overvoltage, too Needs to unplug the Battery high battery charger. Controller needs to be Controller Fault Controller replaced. After 15 minutes of shutdown, restart to confirm whether the fault MOS Tube Fault... - Page 24 Check the brake lever connection line, if the connection is normal, Brake Lever whether the fault is Brake Lever Fault resolved; if not, the brake lever needsto be replaced. Shut down for 5 minutes, then restart to confirm OCP Protection whether the fault is Controller resolved, if not, replace...
- Page 25 The statements should be displayed in the user manual: changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 26 Scooter Maintenance Schedule (Recommended): Maintaining the scooter regularly can help keep the scooter neat and in good condition, avoid safety hazards, minimize breakdowns, slow down the deterioration of the scooter, and extend the scooter's service life. Every Every Every Service Every Every 3 Item...
- Page 28 Distributed by Phantom E-Moto Inc. Address: 15830 El Prado Unit E Chino, CA 91708 Contact us via email info@phantomgogo.com or call us at 866-570- 8755 if you need replacement parts, or have any questions. We will reply within 24 hours.
