PCS133
!
·
For indoor use only.
·
For use on a normally dry work surface.
·
If any malfunction occurs, do not attempt to disassemble or
repair.
·
Avoid placing the unit in a high temperature environment or
near fire.
·
Avoid liquid spills into outlet.
·
Do not insert foreign objects into the socket.
·
Allow enough clearance for part operation.
·
Avoid cleaning the unit while it is plugged in.
SPECIFICATIONS
·
6 ft. cord length.
·
USB-A and USB-C ports are for charging use only.
·
Recommended table thickness is 1/2" MIN. to 1-1/2" MAX.
1
Clamp Mount
PCS133
Groove
Place clamp mount bracket at the back of the unit. Align the
groove on the bracket to the mounting track.
2024.10.07
WARNING
!
FRONT VIEW
Clamp
Mount
Bracket
175.00mm
[6-7/8"]
2
Hook the (2) clamp mount brackets to the back bottom track.
Once attached, tilt the (2) brackets up until they align with
the back of the unit.
1
TABLE OF CONTENTS
. . . . . . . . . . . . . 1X PCS133
. . . . . . . . . . . . . . . 4X 1/2"
No.2 Wood Screw
. . . . . . . . . . . 2X Clamp Mount
. . . . . . . . . . . 2X Under Mount
. . . . . . . . . . . 2X Thumb Screw
76.00mm
91.00mm
[3-19/32"]
SIDE VIEW
Bracket
Bracket
[3"]
