About this Product
The X3-21 Pro shroud is a matte black covering designed to slip over the cylinder, pressure reducer and backframe assembly to
obscure potentially reflective features of the Self-Contained Breathing Apparatus (SCBA) during stealth operations.
Assembly Procedure
The following steps demonstrate how to use the X3-21 Pro Shroud.
1.
Lay the shroud on a clean surface with the inside facing up. Open the hook and loop fasteners, slide the straps out of the
adjustment rings and unsnap the lower attachment snap strap as shown in Figures 1 and 2.
2.
Set the SCBA on its backframe with the base of the SCBA and pressure reducer toward you. Lay the shroud, inside facing up
with the lower attachment snap strap next to the reducer of the SCBA.
3.
Thread the attachment snap strap under the waist pad strap that connects it to the base of the backframe and snap as shown in
Figures 3 and 4.
X3-21 Pro Shroud
P/N 201809-01
User Instructions
Advertisement
Related Manuals for 3M Scott Pro Shroud X3-21
Summary of Contents for 3M Scott Pro Shroud X3-21
- Page 1 User Instructions X3-21 Pro Shroud P/N 201809-01 About this Product The X3-21 Pro shroud is a matte black covering designed to slip over the cylinder, pressure reducer and backframe assembly to obscure potentially reflective features of the Self-Contained Breathing Apparatus (SCBA) during stealth operations. Assembly Procedure The following steps demonstrate how to use the X3-21 Pro Shroud.
- Page 2 The method of access is dependent on the size of the cylinder and valve assembly being used. Personal Safety Division 3M Canada In United States of America © 3M 2025. Al All rights reserved. 3M and Scott P.O. Box 5757 Technical Service 1-800-243-4630 are trademarks of 3M Company and its affiliates.
- Page 3 Instructions d'utilisation Housse X3-21 Pro P/N 201809-01 À propos de ce produit La housse X3-21 Pro est un revêtement noir mat conçu pour se glisser sur la bouteille, le détendeur et le cadre arrière afin de masquer les éléments potentiellement réfléchissants de l'Appareil de Protection Respiratoire Autonome (l'APRA) lors d’opérations furtives.
- Page 4 Le choix de la méthode d’accès dépend de la taille de la bouteille et du modèle de robinet utilisé. Division des produits de Compagnie 3M Canada Aux États-Unis Veuillez recycler. © 2025, 3M. Tous droits protection individuelle Case postale 5757 Service technique 1-800-243-4630 réservés.
