  • Page 1 Service Manual Refrigerator Wine Chiller Model: JC-110GD HA AA 321136...
  • Page 2 Fisher & Paykel Appliances Ltd 78 Springs Road, East Tamaki, Manukau 2013 PO Box 58-732, Botany Manukau 2163 New Zealand Telephone: 09 273 0600 Facsimile: 09 273 0656 COPYRIGHT © FISHER & PAYKEL LTD 2011 - ALL RIGHTS RESERVED...

  • Page 3: Table Of Contents

    SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD Contents Table of Contents ·········································································································· 2 1. General Information ··································································································· 3 1-1. General guideline ································································································ 3 1-2. Insurance test ······································································································ 3 1-3. How to read this Service Manual ········································································ 4 2. Product Feature ········································································································· 5 2-1.

  • Page 4: Chapter 1 General Information

    SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD Chapter 1 General Information 1-1. General Guidelines When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.

  • Page 5: How To Read This Service Manual

    SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD resume the power supply in order to prevent damage to the compressor caused by continuous restart. . Photo used in this manual The illustration and photos used in this Manual may not base on the final design of products, which may differ from the products in some way.

  • Page 6: Chapter 2 Product Feature

    SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD Chapter 2 Product Feature 2-1. SPECIFICATIONS Wine cellar Model JC-110GD Factory Model JC-110GD PHOTO Last update Model JC-110GD Commercial brand Haier Product description WINE CELLAR Type of Appliance (FS= freestanding BI= built-in)
  • Page 7 SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD Max noise level Aesthetics Colours (see L): Black Cabinet Black Door Glass Transparent Door Frame Aluminium Fascia panel / Handle (w / b / g / s) - / - Inside door/-drawers (w=white t=transpar.)
  • Page 8 Compressor Specifications Make: Model GVY44AA Output watts 122 W Refrigerant R600a Run current 0.44 amps Packing dimensions H / W / D 104/56.8/61 Gross weight 40’ container load 40’ HC container load Recycling symbols Carton Polystyrene 1.32 Polyethylene foil 0.18 Service Users instruction (languages) English...

  • Page 9: External Views

    2-2) External views (Features may vary per model) White indicator light Interior light and fan button White Wine Button / Temperature adjust down Interior shelves (storage quantity and style varies per model) Red indicator light Door Red Wine Button / Temperature adjust up Interior fan Dewproof indicator light Adjustable levelling legs...

  • Page 10: Chapter 3 Installation, Adjustments And Maintenance

    SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD Chapter 3 Installation, adjustments and maintenance 3-1. Installation 3-1-1.Unpacking the Wine Cellar: Remove all packaging material. This includes the foam base and all adhesive tape holding the wine cellar accessories inside and outside, compressor from shipping damage due to vibration and shock.

  • Page 11: Maintenance

    SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD 3-1-5. Net Dimension Model JC-110GD Unit Dimension(W*D*H) 506*580*980 3-2. Maintenance To avoid electric shock always unplug the wine cellar before cleaning, ignoring this warning may result in death or injury. General: ...

  • Page 12: Chapter 4 Disassembly

    SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD Chapter 4 Disassembly 4-1. Door assembly 1. Remove the worktop: Remove the two screws behind the worktop → 2. Remove the screws fixed the up hinge and lift the door. 4-2.Fan motors There are two fans.
  • Page 13 Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD 2. Take out the fan block from the compartment and you can see the fan which is assembled in the block. 3. Loosen the screws which connect the fan and the block, and you can take out the single fan from the fan block slowly.

  • Page 14: Main Control Panel

    SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD 2. Display panel Firstly, you must loosen the screws and take off the Electronic box. Then you must disconnect the wire end. And loosen the screws to take off the display panel.

  • Page 15: Transformer

    SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD 3. Loosen the screws of the main control panel, firstly disconnection the wire end. Then you can take off the main control panel，and check it. 4-5.Transformer There is a transformer in the engine room. It is supply the voltage to the door heater.

  • Page 16: Chapter 5 Control And Display System

    SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD Chapter 5 Control and display system 5-1.Control and display panel Once we plugged the unit into an electrical outlet, Let the unit run for at least 30 minutes to acclimate itself before making any adjustments, during this time ,depending on the internal temperature, the red or white wine light will stay on for the upper compartment and red or white wine light will stay on for the lower.

  • Page 17: Function Adjustment And Control Principles

    SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD 5-3. Function adjustment and control principles 5-3-1 Temperature Adjustments: The wine cellar is preset in the factory to automatically accommodate temperature requirements for red or white wines. The wine cellar can be set to any temperature between 6°and 18°C in either of the compartments to accommodate your wine storage requirements.

  • Page 18: Failure Code Display

    SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD 5-4. Failure code display Some times the display works out of orders, reading the following contention may give you some help. Failure code display Error Description and reason Solutions code display “LL” blinks with buzzing; That means the...

  • Page 19: Chapter 6 System Flow Principle

    SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD Chapter 6 System flow principle 6-1. Refrigeration Flow System Chat 6-2.Compressor’s starting and stopping control Form: The temperature display & the compressor’s and valves’ working status. ℃ Actual ℃ Working Not working...

  • Page 20: Heaters' Working Control

    SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD 6-3. The Heaters’ working control Heaters are designed in the wine cellar in order to make the compartment temperature reach the temperature you set when the compartment temperature is lower than what you set.

  • Page 21: Chapter 7 Circuit Diagram

    SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD Chapter 7 Circuit diagram 7-1.Circuit Diagram...

  • Page 22: Connection Sketch Map

    SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD 7-2.Connection Sketch Map Chapter 8 Trouble shooting 8-1. Normal Problems 8-1-1 Sounds of Wine cellar 1. Boiling water, gurgling sounds or slight vibrations that are the result of the refrigerant circulating through the cooling coils.

  • Page 23: Main Parts Parameter

    SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD 7-3. Main Parts Parameter Part Name Check Method and Criterion Measure the resistance with a tester. (Ambient temperature : Room temperature 25°C) Model Main Wiring Auxiliary Wiring Compressor Normal 38.3 Ω 33.4 Ω...

  • Page 24: Normal Problems

    SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD 8-1. Normal Problemes Problems Reasons Removing methods 1. Fuse is broken 1. Check if there is short circuit and 2. The contact of plug, socket, and cable solve it, if not, change capable fuse is not good.
  • Page 25 SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD jump repeatedly. Compressor does not run. 4. The shaft and piston in the compressor is blocked, please change. 1. The voltage is too high. 2. Over load protection unit is not good, it Supplement a stabilizer and adjust jumps earlier.

  • Page 26: 8-2.Abnormal Problems

    SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD 8-2.Abnormal Problems 8-2-1. Compressor doesn’t start...
  • Page 27 SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD 8-2-2.Poor cooling Poor cooling Check the diaplay temperature Change to lower nomber whether it is setted at 18°C Whether the rear side and the top is too close to the wall Avoid these...
  • Page 28 SERVICE MANUAL Issue 2011-09-14 Rev. Ref1109S023V0 Model: JC-110GD Sincere forever Haier Group Haier Industrial Park, No.1, Haier Road 266101, Qingdao, China http://www.haier.com...
