Panasonic RX-D45EB Service Manual

Panasonic RX-D45EB Service Manual

Portable stereo cd system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Notes: Please refer to the original service manual for:
G CD Mechanism Unit (DLS6F), Order No. PSG1002024AE

TABLE OF CONTENTS

1 Safety Precautions----------------------------------------------- 3
1.1. General Guidelines---------------------------------------- 3
1.2. Caution for AC Cord -------------------------------------- 4
1.3. Before Repair and Adjustment ------------------------- 5
Portable Stereo CD System
Model No.
Product Color : (W)...White Type (For RX-D45 only)
PAGE
1.4. Caution For Fuse Replacement ------------------------5
1.5. Protection Circuitry ----------------------------------------5
1.6. Safety Part Information -----------------------------------5
2 Warning -------------------------------------------------------------- 7
© Panasonic Corporation 2010. All rights reserved.
Unauthorized copying and distribution is a violation of
law.
RX-D45EB
RX-D45EG
RX-D50EB
RX-D50EG
(S)...Silver Type (For RX-D50 only)
PSG1002014CE
PAGE
