- Page 1 Listo EMS Controller Model: UP3006CTa Installation Manual Unico Power Corporation 3655 36th Street NW Calgary, Alberta, Canada T3K 6J2 May 2024 208-10337-01 v1.3 (English)
- Page 2 ©2024 by Unico Power Corp. All rights reserved. Trademarks Unico Power logo and Listo are trademarks of Unico Power, Corp. Other brand and product names are registered trademarks or trademarks of their respective holders. Statement of Conditions In the interest of improving internal design, operational function, and/or reliability, Unico Power reserves the right to...
-
Page 3: Table Of Contents
Contents Listo EMS Controller Manual Getting to Know Your Controller ..................1 Unpacking Your EMS Controller Kit................1 Hardware Features ..................... 3 Front Panel......................3 Positioning Your Controller Prior to Install..............4 Installing The Listo EMS Controller .................5 Configuring Your Listo EMS System ................8... -
Page 4: Getting To Know Your Controller
Once your Listo EMS is installed and commissioned, you can access all operating instructions and help via the mobile app or desktop browser at https://app.unicopower.com. If any of the package contents are incorrect, missing, or damaged, contact Unico Power at support@unicopower.com. Keep the carton, including the original packing materials, in case you need to return the product for repair. - Page 5 DANGER: Hazardous Voltage. The Listo EMS must be installed by a qualified electrical professional and requires access to the service compartment of your electrical panel. Contact with live electrical wires can result in serious injury or death. To prepare your Listo EMS Controller prior to installation: Open the White Box labeled Listo Controller and remove the items from the protective packaging - save the box and packaging.
-
Page 6: Hardware Features
Hardware Features Before you install and connect your router, take a moment to become familiar with important information on the label, and with the front and back panels of the router—especially the status lights on the front panel. Front Panel The controller front panel, shown in Figure 2, contains two (2) status lights and six (6) -
Page 7: Positioning Your Controller Prior To Install
Positioning Your Listo EMS Controller Prior to Mounting The Listo EMS controller must be located close to your main electrical panel. For best results, place your controller: • Accessible to an AC power outlet. • Within 1 Meter (3.25 feet) from the top of the electrical panel where the main current transformers (CTs 1 and 2) will be located. -
Page 8: Installing The Listo Ems Controller
Installing The Listo EMS Controller The Listo EMS Controller comes with four mounting holes located on the faceplate and rear panel. Locations are shown in Figure 3 below. 2. The unit should be mounted with the Antenna facing up as shown below, and must be mounted using the included #8 x 3/4"... -
Page 9: Pre-Installation Checklist
Installing The Current Transformers DANGER: Hazardous Voltage. The Listo EMS must be installed by a qualified electrical professional and requires access to the service compartment of your electrical panel. Contact with live electrical wires can result in serious injury or death. Precautions •... - Page 10 Installing the Current Transformers Warning: To reduce the risk of electric shock, always open or disconnect the circuit from the power-distribution system (or service) before installing current transformers. 1. Locate the arrow on the bottom of the CT. Ensure that the CT is installed so that the arrow points TOWARDS the load (into the panel).
-
Page 11: Configuring Your Listo Ems System
Configuring Your Listo EMS Installation of Home Router, Wi-Fi Repeater, and EVSEs are not described in this manual. Refer to the manuals provided with this equipment. Figure 5 depicts a typical home installation and identifies the components required to activate your Listo EMS. - Page 12 Your device will need internet access again (and should use whatever other connection you had before). Once the form page detects that there is internet access, your browser will be redirected to the Unico Power app to sign up/in and set up your account information.
