- Page 1 Electric Pressure Cooker Instruction Manual CPC80116MBSS IMPORTANT NOTE: Please read the manual carefully before operating your product. Retain it for future reference. (Picture are for reference only, atual product may differ from picture shown)
-
Page 2: Table Of Contents
CONTENT IMPORTANT PRECAUTIONS SPECIFICATIONS PRODUCT OVERVIEW QUICK START GUIDE • Rea OPERATION INSTRUCTIONS • For CLEANING AND MAINTENANCE TROUBLESHOOTING • Do • Ne • Clo • Ele • The • Be • Do • Do • Do... -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS CAUTION • READ ALL INSTRUCTIONS. carefully and save all the instructions. • Do not touch hot surfaces. Only use side handles or dditional protection, we recommend the use knobs for carrying or moving. ower outlet with a rated current of 10A. To •... - Page 4 CAUTION • This appliance cooks under pressure. Improper use may result in scalding injury. Make certain unit is properly closed before operating. Please see the “Getting Start- ed” section. • Do not fill the appliance over 2/3 full. When cooking foods that expand during cooking such as rice or dried vegetables, do not fill the appliance over 1/2 full.
- Page 5 • This appliance is not intended for deep frying foods. “This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit into a polarized outlet only one way.
-
Page 6: Specifications
SPE CIFICATIONS Product Model CPC80116MBSS Capacity 8 Quart Power Supply 120V~ 60Hz Rated Power 1200W Size of Inner Pot 9.45" Working Pressure 80kPa Keep Warm Temperature 167° F~203° F... -
Page 7: Product Overview
PRODUCT OVERVIEW Component Name Exhaust opening Exhaust valve handle Float valve Upper cover handle Seal ring Sealing ring Block proof cover Inner pot Cooker body handle Control Box Cooker body Parts List Spoon Soup Scoop User Manual Measuring cup Condensation box Steam rack NOTE All the pictures in this manual are for explanation purpose only. -
Page 8: Quick Start Guide
QUICK START GUIDE Product Structure Tips 1. Please move the product with the handle of the cooker body; 2. Please remove the water from the housing cover with cloth. NOTE 1. Exhaust valve: Pull out the exhaust valve from the lid. Clean the internal side of the exhaust valve and the exhaust valve and float valve of the lid with brush and cloth at least once a month. - Page 9 QUICK START GUIDE Disassemble and install the seal ring 1. Please do not pull the seal ring, otherwise, the distorted seal ring may influence the seal and pressure effect. 2. Do not use the dam aged seal ring, please replace it at the autho rized repair office.
- Page 10 QUICK START GUIDE Disassemble and install the water box 1.The water box sits at the back of the appliance base and catches any overflow from the condensation rim. It should be installed before cooking, then emptied and rinsed out after each use.
-
Page 11: Prepare For Cooking
QUICK START GUIDE Prepare for Cooking 1. Opening the lid correctly • Hold the handle of upper cover, turn it anticlockwise for about 30°till the lid at unlock state, and then lift the upper cover. Unlock State 2. Check if the parts and accessories of lid are well installed •... - Page 12 QUICK START GUIDE 4. Put the inner pot into the cooker • Wipe to clean the external surface of inner pot, foreign object and water are not allowed on the inner surface of electric pressure cooker; • Turn the inner pot to left and right to ensure good contact with the heating plate.
-
Page 13: General Function
QUICK START GUIDE 6. Put the exhaust valve well • When working, please turn the exhaust valve to the sealing place, which means the electric pressure cooker keeps at sealing state; • For manual exhaust, please turn the exhaust valve handle to the exhaust place, the electric pressure cooker keeps at the exhaust state;... - Page 14 QUICK START GUIDE Safely Open the Lid 1. Cut off power supply or remove the power plug 2. Exhaust method A. Quickly open the lid (For non-fluid foods) Turn the exhaust valve to the exhaust place for exhausting, Some unit by pressing steam release button “...
-
Page 15: Operation Instructions
OPERATION INSTRUCTIONS Operation Part Display Screen Keep Warm Button Start Cancel Button “-” Button “+” Button Menu Function Panel Function Selection Function Operation Guidelines During function setting or delay timer setting, press “Start/ Start/ Cancel” to start heating or delay timer. During heating or delay Cancel timer runs, press “Start/Cancel”... - Page 16 Function Operation Guidelines In the standby mode, press the “Slow Cook” key, the “Slow Cook” key light will be on, and the display screen will display the default time and the default medium gear. At this time, you can Slow press the “Level”...
- Page 17 Function Operation Guidelines In the standby mode, press the “Sous Vide” key, the “Sous Vide” key light will be on, and the display screen will display the default temperature. At this time, press the “Level” key to switch the temperature or time display. Sous Vide When the temperature is displayed, press the “+”...
-
Page 18: Cleaning And Maintenance
CLEANING AND MAINTENANCE For use the product safely with a longer service life, please carefully check and maintain it. If followings occur Solutions • Power cord and plug is expanded, deformation, damaged and it color is changed. • One part of the power cord and plug are hotter. Stop using, and •... -
Page 19: Safety Precautions
Safety Precautions To avoid personal injury and property loss, be sure to observe the following safety precautions. • Meanings of the marks: General Disassemble Wet hands Means Forbid Forbidden Forbidden “Forbidden” Contact Spray Water items Forbidden Forbidden Means Remove the Must be “Mandatory”... - Page 20 WARNING A socket shall be used alone • A socket of more than 10A rated current with grounding wire shall be used alone; • If shared with other electrical appliances, the socket may cause abnormal heat and result in fire. It is strictly prohibited to use other lid •...
- Page 21 WARNING Modification is prohibited • Modification or repair by non-professionals is prohibited. • Violation may cause a fire or electric shock. • Repair or replacement of parts shall be made in a designated service center. Products may not be immersed or sprin- kled in water •...
- Page 22 CAUTION Never pull the plug with a wet hand • To avoid electric shock. When pulling the plug, you must pinch the plug • When pulling the plug, you must pinch the plug; • Do not pull the power cord, otherwise it will damage the cord, causing electric shock and short circuit.
- Page 23 CAUTION The total amount of food and water can not exceed Max scale • The total amount of food and water can not exceed Max scale, otherwise food may be cooked unfamil- iar, or cause malfunction. Do not use a pot other than the dedicated pot •...
-
Page 24: Clean After Use
Safety Precautions • Periodically clean the cooker and remove oil and dirt if it is stored on the table. • Put the electric pressure cooker 30cm away from other kitchen appliances. Clean After Use 1. Clean after each use. 2. Before cleaning and maintenance, please unplug the power cord until the product cools. -
Page 25: Troubleshooting
TROUBLESHOOTING Operation of your appliance can lead to errors and malfunctions. The following tables contain possible causes and notes for resolving an error message or malfunction. It is recommended to read the tables carefully below in order to save your time and money that may cost for calling to the service center. Problem Reason Solution... - Page 26 Problem Reason Solution Solution • Too little food and water • Add water and food in inner pot. according to the recipe. Float valve unable to rise • Send to the service • Steam leaks from the lid center for repair. or exhaust valve.
- Page 27 SERVICE AND SUPPORT 1 YEAR LIMITED WARRANTY g after use. g after use. after use. after use. remove plug from power outlet. This is the only express warranty for this product and is in lieu of any other warranty or condition. This product is warranted to be h reduced h reduced ith reduced...
