GTF 2550 / GTF 2750
Bruksanvisning og deleliste

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GTF 2550 and is the answer not in the manual?

Questions and answers

Related Manuals for Globus GTF 2550

Summary of Contents for Globus GTF 2550

  • Page 1 GTF 2550 / GTF 2750 Bruksanvisning og deleliste...
  • Page 2 Our goal is for you to be a satisfied Globus customer. To achieve this, we focus on quality and user- friendly products. In collaboration with our dealers, we aim to solve any problems that may arise and guarantee the supply of spare parts for 10 years.

  • Page 3: Declaration Of Conformity

    User manual and spare parts snow blower GTF 2550 og GTF 2750 DECLARATION OF CONFORMITY Producer: Underhaug AS Address: Torlandsveien 3 4365 Nærbø N-NORWAY We hereby declare under our own responsibility that the following product: Type: Globus Snowblower GTF 2550 Globus Snowblower GTF 2750 Serial No.:...
  • Page 4 User manual and spare parts snow blower GTF 2550 og GTF 2750 INNHOLD Introduction Side Welcome as customer Product information Declaration of conformity Safety User Manual Caution Crushing hazard Safety labeling Lifting points Product Information Intended use Power requirements Construction and functions...
  • Page 5 User manual and spare parts snow blower GTF 2550 og GTF 2750 2. SAFETY 2.1 User Manual All users of the Globus Snowblower GTF 2550 and GTF 2750 must familiarize themselves with the content of the user manual before using the machine. 2.2 Caution Ensure that no one is in the snowblower's throwing area.

  • Page 6: Lifting Points

    The snow blower body is equipped with lifting eyes marked with the symbol as illustrated. Please note that the GTF 2550 and GTF 2750 weigh approximately 1650 kg and 1750 kg, respectively. Always use straps rated for this total weight.
  • Page 7 Replaceable Wear Blades The Globus GTF 2550 and GTF 2750 come standard with replaceable wear blades made of Hardox 500. As an option, perforated wear blades can be supplied, providing less slippery surfaces. Wear Shoe Adjustment Sturdy wear shoes are located at the rear of the housing and can be easily adjusted to the desired height.

  • Page 8: Technical Data

    User manual and spare parts snow blower GTF 2550 og GTF 2750 Technical data Model GTF 2550 GTF 2750 Arbeidsbredde 235 cm 255 cm Working Width with Solid Side Plates 255 cm 275 cm (Standard) Working Width with Solid Side Plates and...
  • Page 9 User manual and spare parts snow blower GTF 2550 og GTF 2750 Additional Equipment Available additional equipment for the Globus GTF 2550 and GTF 2750 is listed below. Drawings and parts lists for each item can be found later in the manual.

  • Page 10: Assembly And Connection

    User manual and spare parts snow blower GTF 2550 og GTF 2750 4. ASSEMBLY AND CONNECTION Assembly The snow blower is delivered fully assembled and ready for use, unless otherwise agreed. For practical reasons during transportation, the chute may be delivered disassembled or lowered.
  • Page 11 The side blades should only be used with mounted side plates, which provide working widths of 255 cm (GTF 2550) and 275 cm (GTF 2750). The depth of the snow blower is adjusted using the skid shoes, which offer multiple options to achieve the correct height.

  • Page 12: Maintenance

    User manual and spare parts snow blower GTF 2550 og GTF 2750 6. MAINTENANCE Retightening After a few hours of operation with a new snow blower, all bolt connections should be checked and retightened where necessary. This should then be checked regularly.
  • Page 13 User manual and spare parts snow blower GTF 2550 og GTF 2750 3. Lubrication Points - Drive System The gear oil used in the distribution gearbox, mounted between the augers and the discharge fan, should be Texaco Meropa 320 or oil with equivalent specifications from another brand.

  • Page 14: Warranty Terms

    User manual and spare parts snow blower GTF 2550 og GTF 2750 Warranty Terms What is covered by the warranty 1. The warranty covers the repair of defects or malfunctions in the product or components included in the product. This applies to faults that can be traced back to production or material defects.

  • Page 15: Spare Parts

    User manual and spare parts snow blower GTF 2550 og GTF 2750 SPARE PARTS Contents POS: Beskrivelse: Kapittel: Side: Screws, gears, fan Chassis Chute Wear plates and shoes Drawbar mounting Additional equipment Swing gir with Drive Page 15...
  • Page 16 User manual and spare parts snow blower GTF 2550 og GTF 2750 Screw, gir, fan Page 16...
  • Page 17 User manual and spare parts snow blower GTF 2550 og GTF 2750 8.2 Auger screws, gears, and discharge fan Serial no. POS: Art. nr: Beskrivelse: from Add. info: 140346 Right auger screw for GTF 2750 4171 - 140257 Right auger screw for GTF 2750...
  • Page 18 User manual and spare parts snow blower GTF 2550 og GTF 2750 Chassis Serial no. 8.3 Chassis POS: Art. no: Discription: From Add.Info: 930468 Stake pin 4171 - 500950 Welded chassis GTF 2550 4171 - 500900 Welded chassis GTF 2750...
  • Page 19 User manual and spare parts snow blower GTF 2550 og GTF 2750 Chute Serienr. 8.4 Tut POS: Art. no: Discription: From Add.Info: Lower part of the chute towards the 124920 swing ring 2011 4171 - 500304 Lower part 4171 -...
  • Page 20 User manual and spare parts snow blower GTF 2550 og GTF 2750 124163 Complete cylinder with hoses 4171 - Hoses not illuatrated Wear plates and shoes Page 20...
  • Page 21 User manual and spare parts snow blower GTF 2550 og GTF 2750 Wear plates and shoes Serial no. POS: Art. no: Discription: From Add. Info: 38 130085 Waer plates, outre 4171 - 129701 Wear plates R+L edge wing 4171 -...

  • Page 22: Additional Equipment

    User manual and spare parts snow blower GTF 2550 og GTF 2750 Additional equipment Page 22...
  • Page 23 User manual and spare parts snow blower GTF 2550 og GTF 2750 (64) Serial no. 8.7 Additional Equipment POS: Art. no: Discription: From Add. Info: 500941 Left side plate 500940 Right side plate 130567 Right edge cutter 130566 Left edge cutter...
  • Page 24 User manual and spare parts snow blower GTF 2550 og GTF 2750 Slew Ring Serial no. 8.8 Slew ring POS: Art. no: Discription: From Add.Info: 360 124804 Slew ring 361 123956 Lower stopper 362 123955 Upper stopper 363 033635 Screw M12x35 DIN 933...
  • Page 25 User manual and spare parts snow blower GTF 2550 og GTF 2750 Notes Page 25...
  • Page 26 User manual and spare parts snow blower GTF 2550 og GTF 2750 Notes Page 26...
  • Page 27 User manual and spare parts snow blower GTF 2550 og GTF 2750 Notes Page 27...
  • Page 28 User manual and spare parts snow blower GTF 2550 og GTF 2750 WWW.UNDERHAUG.NO PRODUCER: UNDERHAUG AS 4365 Nærbø N-NORWAY Page 28...
