Summary of Contents for Globus GTF 250-19
- Page 1 User manual and spare parts Snow blower GTF 250-19...
-
Page 2: Product Information
Our goal is for you to be a satisfied Globus customer. To achieve this, we focus on quality and user- friendly products. In collaboration with our dealers, we aim to solve any problems that may arise and guarantee the supply of spare parts for 10 years. -
Page 3: Declaration Of Conformity
Torlandsveien 3 4365 Nærbø N-NORWAY We hereby declare under our own responsibility that the following product: Type: Globus Snowblower GTF 250 Serial No.: Year of Manufacture: 2024-> covered by this declaration, complies with the following standards: • NS/EN ISO 13857: 2008 •... -
Page 4: Table Of Contents
Retightening Color code Replaceing ware parts Lubrication points for the nozzle and swing ring Lubrication points for the drive shaft Warranty Warranty terms of Globus products Spare parts Content Screw, gir and fan Chassis Chute Wear blade and wear shoes... -
Page 5: Safety
2 SAFETY 2.1 Instruction Manual Anyone using the Globus snow blower GTF 250-19 must familiarize themselves with the contents of the instruction manual before operating the machine. 2.2 Caution Ensure no people are in the snow blower’s discharge area. Snow, ice, stones, and other foreign objects ejected from the blower can cause injury to people, vehicles, buildings, and other objects. -
Page 6: Lifting Points
The machine is designed for 540 RPM. Rotating parts. Read the user manual. Warning. When repairing, always remove the key from the ignition. 2.9 Lifting points The snow blower body is equipped with two lifting points as illustrated in the image. Be aware that the snow blower weighs approximately 900 kg, so always use straps rated for this total weight. -
Page 7: Product Information
3 PRODUCT INFORMATION 3.1 Application The Globus GTF 250-19 is a two-stage snow blower suitable for tractors from 70 hp. The snow blower comes with a fixed 3-point hitch adapted to the applicable standards. The blower requires skilled operation, and the user manual should be read before connecting and operating the machine, even if the operator has prior experience with similar equipment. -
Page 8: Assembly And Connection
Weight PTO shaft 30kg Weight, approx. 900kg Additional accesories Available optional equipment for the Globus GTF 250-19 is listed below. Drawings and parts lists for the individual items can be found further back in the manual. Art. no. . Description Add. infp... -
Page 9: Connection
4.2 Adapting the P.T.O. Shaft Always use the power take-off (P.T.O.) shaft that is supplied with the machine. It is adapted to the snow blower's power requirements and is equipped with a 12mm 8.8 shear bolt for overload protection. NB! It is extremely important that the P.T.O. shaft is adapted to the tractor/snow blower. Failure to do so can cause significant damage to both the tractor and/or the snow blower's gearbox. -
Page 10: Maintenance
• Clear the full width of the road during the first snowfall and create an even base. Do not wait until the snow depth becomes too large; instead, clear several times. • Choose a speed that ensures smooth progress, as this will make the job easier. •... - Page 11 1. Chute The chute has 8 grease nipples and should be greased every 8 operating hours. Use universal grease, such as Statoil UniWay Li 712. 2. Drive shaft Gear oil Statoil GearWay 80W-90 (Change after 50 hours of operation, then every 200 hours or annually).
-
Page 12: Warranty Terms
WARRANTY TERMS 7.1 What is covered by the warranty 1. The warranty covers the repair of defects and deficiencies in the product or components included in the product. This applies to faults that can be traced back to manufacturing or material defects. -
Page 13: Spare Parts
SPARE PARTS Content POS: Description: Chapter: Page: Screw, gir and fan Chassis Chute Wear blade and wear shoes Additional equipment Slew ring Maintenance shedule Side 13... -
Page 14: Screw, Gir And Fan
Screw, gir and fan Side 14... - Page 15 Kapittel 8.2 Screw, gir and fan Serial no. POS: Art. no: Description: From Add. info: 1 124782 Gir box S2100 100 - 2 140369 Rear cover 100 - 3 032321 Screw M6x12 100 - 4 012911 Washer Ø7 100 - 5 125959 Rear chain cpl 100 -...
-
Page 16: Chassis
Chassis Kapittel 8.3 Chassis Serial no. POS: Art. no: Description: From Add. info: 33 140166 Chassis welded and paintet 100 - 34 930468 Clearing rod 100 - Side 16... -
Page 17: Chute
Chute Side 17... - Page 18 Kapittel 8.4 Chute cpl Serial no. POS: Art. no: Description: From Add. info: 124171 Chute lower part near slewing ring 2011 100 - 124176 Chute lower part 2011 100 - 124181 Flap 1 chute 2011 100 - 124184 Flap 2 chute 2011 100 - 124187 Linkage transmission...
- Page 19 Wear blade and wear shoes Side 19...
-
Page 20: Wear Blade And Wear Shoes
Kapittel 8.5 Wear blade and wear shoes Serial no. POS: Art. no: Description: From Add. info 34 140368 Wear blade Main 100 - 35 034840 Locking screw L-40 100 - 36 012927 Washer Ø17 100 - 37 016010 M16 Locking nut 100 - 38 125909 Wearing blade R+L STD. -
Page 21: Additional Equipment
Additional Equipment Side 21... - Page 22 Side 22...
- Page 23 Side 23...
- Page 24 Kapittel 8.6 Additional equipment Serial no. POS: Art. no: Description: From Add. info: 80 125988 Edge cutter L. cpl 100 - 81 125964 Edge cutter R. cpl 100 - 82 125963 Wheel set cpl 100 - (2 stk.) 83 125834 Hydr.
-
Page 25: Slewing Ring
Slewing ringg Serial no. 8.8 Slewing ring POS: Art. no: Description: From Add. info: 360 124804 Slewing ring 361 123956 Brake lower part 362 123955 Brake upper part 363 033635 Screw M12x35 DIN 933 364 033640 Screw M12x40 DIN 933 365 033425 Screw M8x25 DIN 933 368 012983... -
Page 26: Maintenance Schedule
Maintenance schedule: Date Housing Axle Slew ring Auger Chute Sign. Annual mandatory inspection of the machine (according to the user manual). Date: Controller (approved) Stamp/Signature Side 26... -
Page 27: Notes
8.12 Notes Side 27... - Page 28 8.12 Notes Side 28...
- Page 29 WWW.UNDERHAUG.NO PRODUCER: Underhaug AS 4365 Nærbø N-NORWAY Side 29...
