- Page 1 Installation Manual -5000 DHCP IP Intercom System www.eos.com.au MC-1189-V1.0...
-
Page 2: Table Of Contents
Content---Door Station 1. Specification --------------------------------------------------------------------------4 2. Accessories ----------------------------------------------------------------------------5 3. Data sheet -------------------------------------------------------------------------------6 4. Wiring Diagram ----------------------------------------------------------------------7 5. Operation Instruction -----------------------------------------------------------9 Password for system setting menus ------------------------------------------------9 5.2 Password Management --------------------------------------------------------------10 5.3 Language setting -----------------------------------------------------------------------11 5.4 Door Station Setting -------------------------------------------------------------------11 5.5 Ring Settings ----------------------------------------------------------------------------17 5.6 Door Station Mode --------------------------------------------------------------------17... - Page 3 Content--Indoor Monitor 1. System Installation Diagram -----------------------------------------------29 Typical system setup with PoE switch ----------------------------------------------29 1.2 System installation diagram -----------------------------------------------------------30 1.2.1 Wiring diagram: Multi-apartment ---------------------------------------------30 1.2.2 Villa wiring diagram -------------------------------------------------------------32 1.2.3 Indoor monitor diagram --------------------------------------------------------33 2. Monitor Operation Instruction --------------------------------------------34 Main GUI ----------------------------------------------------------------------------------34 2.2 Recording Center ----------------------------------------------------------------------35...
-
Page 4: Specification
Specification Accessories Outdoor station......... 1pcs Rubber stopper. -
Page 5: Data Sheet
Data sheet Wiring Diagram No. Name Description Cable: Recommended cable and length: CAT5E or CAT6, the network cable between devices is less than 100 meters, and a switch is required if it is longer Viewing angle Horizontal 150 degrees than 100 meters. Product Type 1. -
Page 6: Operation Instruction
2.2 Exit button + Magnetic lock diagram Operation Instruction EXIT 1. Password for system setting menus. Type Password Operation Instruction EXIT NC COM NO DC+ GND Project 999999 1. To enter the system setting menu in the villa or password high-level apartment mode, input the project password followed by '√'. -
Page 7: Password Management
2. Password Management Input old password, input new password, confirm new password twice, and click "√" to prompt on door station to set successfully. The password change is completed. 2.1 Change public unlock password Step: Home → System Settings Menu with the project password → Password 3. - Page 8 4.4 Building mode 4.2 Door station mode switch Step: Home →System Settings Menu with the project password →Door Step: Home → System Settings Menu with the project password →Door Settings → Click Door’s Mode Switch. Settings → Click Door’s Mode Switch → Click Building Mode. Villa, high-level apartment, building mode optional.
- Page 9 4.6 High-level apartment Number of User Settings (1). Click Single Row: The list is displayed in single row, 4 users per page. (2). Click Double Row: The list is displayed in double row, 8 users per page. Step: Home → System Settings Menu with the project password →Door (Note: The double raw mode becomes available when there are more than Settings →...
-
Page 10: Ring Settings
5. Ring settings 4.9 High-level user Management Settings Step: Home → System Settings Menu with the project password →Door Step: Home → System Settings Menu with the project password →Door Settings → Click Ringtone Settings. Settings → Click Door’s Mode Switch → Click Small High Level Mode → Click User Management. -
Page 11: Card Management
7. Card Management Building and high-level mode: enter the online indoor monitor room number, such as 0101, and click "√" to enter adding mode. Put the IC card close to 7.1 Card Management RFID reader and hear one beep. Step: Home →System Settings Menu with the project password → Click NOTE: Cards Management. -
Page 12: User Defined Function Options
7.6 Clear all cards Step: Home →System Settings Menu with the project password →Click Cards Management → Click Cards Deleting → Empty all Cards. 7.5 Delete Card by Room Number Step: Home → System Settings Menu with the project password →Click Cards Management →... - Page 13 (1) Administrator call switch 8.3 Digital photo frame settings It is enabled by default. When door station is in building mode, you can see Step: Home → System Settings Menu with the project password →Custom Settings → Click Standby Mode → Click Digital Photo Frame. the administrator button on the call page.
- Page 14 8.5 Time and Date Settings 8.7 View device information Step: Home → System Settings Menu with the project password →Custom Step: Home → System Settings Menu with the project password → Right-click Settings → Click Standby Mode → Click in lower right corner to turn the in the lower right corner to turn the page →...
-
Page 15: Installation Drawing
Installation Drawing Doorstation Installation Surface Mount RF CARD 1. Avoid installa on the device near sources of radia on, such as AC motors or li s. 2. Maintenance must be performed by a qualified technician. 3. Avoid strong shaking, impacts, or collisions, as these may damage the internal precision components. -
Page 16: Indoor Monitor
Unit 10 Unit 11 Unit 12 Unit 13 Indoor Monitor UTP cable Power supply for the door lock To Lift Control Room Strike Lock Strike Lock WIEGAND output Door station #1 Door station #2 Lift Controller Access Controller www.eos.com.au... -
Page 17: System Installation Diagram
2. System Installation Diagram System Diagram With PoE 2.1 Wiring Diagram: Multi-apartment Wiegand Router EXIT PoE switch EXIT NC COM NO DC+ GND Apartment 1 Lock PoE switch RJ45 Lift Apartment 2 Apartment 3 PoE LAN Apartment 4 Electric Lock Magne c Lock Wiegand NOTE:... -
Page 18: Villa Wiring Diagram
BUTTON LOCK PoE switch RS 485 CHIME Electric Lock Magne c Lock Type B indoor monitor diagram (VM-5000-Monitor) Wiegand NOTE: EXIT When the door station is powered by POE, the outdoor station does EXIT not need to be powered separately. -
Page 19: Monitor Operation Instruction
4) Status Icon Instruction Monitor Operation Instruction ① Network status: Connected, Disconnected, Network Conflict. ② Unread message: 1. Main GUI ③ Missed call: ④ Unread public message: Connected Disconnected IP Conflict Network Unread Message Missed Call High-level, Villa System Main GUI Others 1) There are Menu, Shortcut keys, Status. -
Page 20: Message Record
APP Download Android: Download “ TuyaSmart” app from Google Play 2.3 Message Record iOS: Download “TuyaSmart” app from Apple App Store Open the app to create an account, Pay attention to selecting the correct Visitors can leave voice or video messages on the monitor when a call is country and region when registering. - Page 21 Click “QRCode” to scan the QR code of the monitor (pic 3). APP screen pic 3 After successful connection, return to the “Tuya Smart” app. (pic 4). Wait until the SamrtDoorBell-IPBox is successfully added. (pic 5). ⑧ Hang up (Back). Speaker On/Off...
-
Page 22: How To Share Access With Additional Users
4. User Settings 3.3 How to Share Access with Additional Users Register a New Account: New users must register for a Tuya Smart account using their email or phone number. Open the Tuya Smart App: On the first smartphone that already has access to the intercom, open the Tuya Smart App. -
Page 23: System Settings
5. System Settings Technical Parameter Do NOT share this information with end users unless necessary. Monitor Installation 5.1 Monitor Extension Setting The first four digits represent the room number, while the last two digits 1. Do not disassemble the device yourself to indicate the extension number.
