Summary of Contents for M-Audio AIR 192/14
- Page 1 User Guide English ( 3 – 7 ) Guía del usuario Español ( 8 – 13 ) Guide d'utilisation Français ( 14 – 19 ) Guida per l'uso Italiano ( 20 – 25 ) Benutzerhandbuch Deutsch ( 26 – 31 ) Appendix English ( 33 –...
- Page 2 User Guide (English) Introduction Thank you for purchasing the AIR 192|14. At M-Audio, we know how serious music is to you. That’s why we design our equipment with only one thing in mind—to make your performance the best it can be.
- Page 3 5. Select your Sample Rate and then click OK to close the Setup window. 6. Go to the Setup > I/O and select M-Audio AIR 192|14 for the Input and Output devices. You can now add tracks to send and receive audio and MIDI from sources connected to AIR 192|14 inputs and stream recorded audio back through the AIR 192|14 outputs.
-
Page 4: Connection Diagrams
Connection Diagrams Items not listed under Introduction > Box Contents are sold separately. Example 1 Powered Microphones Monitors Computer Top/Front Panel Electric Guitars Rear Panel Power Headphones Example 2 Powered Microphones Monitors Computer Top/Front Panel Electric Guitars Power Keyboard Rear Panel Headphone Amplifier Headphones... -
Page 5: Top Panel
Features Top Panel 1. Power Button: Press this button to power the AIR 192|14 on or off. The Power LED below this button lights up when the unit is powered on. 2. Input Gain: Adjusts the input's gain level. Set this knob so the corresponding LED Meter (located below the knob) displays a "healthy"... -
Page 6: Rear Panel
Direct Monitor Selector: Leave this switch in the raised position (blue Stereo LED is lit) to monitor the direct input signal with Inputs 1, 3, 5, and 7 in the left channel and Inputs 2, 4, 6, and 8 in the right channel. -
Page 7: Technical Specifications
Appendix (English) Technical Specifications All specifications are measured at 20 kHz bandwidth. Mic Inputs 1–4 (balanced XLR) Dynamic Range 113 dB (A-weighted) 0.001% (1 kHz, +4 dBu, -1 dBFS) THD+N 20 Hz – 20 kHz (+/-0.2 dB) Frequency Response -137 dBu (40 Ω source, A-weighted) Preamp EIN -129 dBu (150 Ω... -
Page 8: Trademarks And Licenses
1.8 kg Specifications are subject to change without notice. Trademarks & Licenses M-Audio and AIR Music Tech are registered trademarks of inMusic Brands, Inc., registered in the U.S. and other countries. Ableton is a trademark of Ableton AG. Kensington and the K & Lock logo are registered trademarks of ACCO Brands. - Page 9 Manual Version 1.0...
