Ameriwood HOME 6387341COM Instruction Booklet

Ameriwood HOME 6387341COM Instruction Booklet

Fp console for 85" tvs
Hide thumbs

Advertisement

Table of Contents

6387341COM
FP Console for 85" TVs
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
B346387341COM00SF
Easy
Assembly Difficulty Meter
People needed for assembly: 2
Follow Ameriwood Home
You
Tube
Tough

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6387341COM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ameriwood HOME 6387341COM

Summary of Contents for Ameriwood HOME 6387341COM

  • Page 1 WARNING Assembly Difficulty Meter People needed for assembly: 2 Follow Ameriwood Home - Unit can tip over causing severe injury or death. - Anchor unit to stud in wall (if instructed to). - Do Not allow children to climb on unit.

  • Page 2: Helpful Hints

    Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Call us! 1-800-489-3351 Visit ameriwoodhome.com Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 2 - Open your item in the area you plan to keep it to avoid excessive heavy lifting. - Identify, sort and count the parts before attempting assembly.

  • Page 3: Before You Start

    Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight.
  • Page 4 Before You Start Please Note: You may need to lightly tap the wood dowels with a hammer into the holes during your assembly process. Wood Dowel Insertion: Insert wood dowel completely into the hole. Not Actual Size Wood dowel will extend out approximately 3/8".

  • Page 5: Board Identification

    Board Identification Not Actual Size Top Panel Top Apron Upper Back Panel Upper Partition T6387341010SF T6387341020SF T6387341030SF T6387341040SF QTY: 3 PCS Fixed Shelf Fixed Shelf Rail Upper Molding Lower Back Panel T6387341050SF T6387341060SF T6387341070SF T6387341080SF QTY: 2 PCS Left Side Frame Left Partition Side Molding Right Partition...
  • Page 6 Board Identification Not Actual Size Left Door Bottom Panel Right Side Frame T6387341150SF T6387341140SF T6387341130SF Right Door Middle Leg Adjustable Shelf T6387341180SF T6387341160SF T6387341170SF QTY: 3 PCS QTY: 2 PCS Fireplace Insert FA42V60L * See the manual came with your insert for part numbers and important safety information.
  • Page 7 Board Identification Not Actual Size Fireplace Insert FA42V60L ameriwoodhome.com Tube...

  • Page 8: Part List

    Hardware Bag Reference Number: 26387341COM0SF Part List Part List Actual Size For any replacement hardware, 26387341COM0SF order part # (x53) (x53) TSF0314 TSF0354 Cam Bolt Cam Lock Ø15x12 mm Ø7x34 mm (x70) (x4) (x7) TSF0501 TSF1811 TSF0610 (x2) Wood Dowel Bolt Screw Ø8x30 mm...
  • Page 9 Hardware Bag Reference Number: 26387341COM0SF Part List Part List Not Actual Size (x4) (x8) (x2) (x4) TSF2722 TSF0557 TSF2221 TSF3506 Hinge Shelf Support Knob Bumper WARNING ADVERTENCIA AVERTISSEMENT (x1) (x1) (x22) (x1) TSF2635 TSF2914 TSF3514 TSF0015 Angel Bracket Warning Label Cam Cover Glue ameriwoodhome.com...
  • Page 10 STEP Dowels extend out 3/8". For more details, please see page 4 x 14 · Attach 14 Cam Bolts (1) to the Top Panel (A) as illustrated. Do NOT over-tighten. Wooden · Insert four Wood Dowels (3) into Top Apron (B) as illustrated. Dowel Hole for wooden...
  • Page 11 STEP Dowels extend out 3/8". For more details, please see page 4 x 10 · Attach ten Cam Bolts (1) to Fixed Shelf (E) as illustrated. Do NOT Wooden over-tighten. Dowel · Insert eight Wood Dowels (3) into Fixed Shelf (E) as illustrated. Hole for wooden dowel...
  • Page 12 STEP x 11 · Attach five Cam Bolts (1) to Fixed Shelf Rail (F) as illustrated. Do NOT over-tighten. · Attach three Cam Bolts (1) to Side Molding (J) x 2 as illustrated. Do NOT over-tighten. ameriwoodhome.com Tube...
  • Page 13 STEP Wooden Dowel Dowels extend out 3/8". For Hole for more details, please see page 4 wooden dowel x 22 Use one drop of glue in · Insert four Wood Dowels (3) into Upper Partition (D) x 3 as illustrated. dowel hole.
  • Page 14 STEP Dowels extend out 3/8". For more details, please see page 4 x 12 · Attach two Cam Bolts (1) to Left and Right Partition (I) & (K) as illustrated. Do NOT over-tighten. Wooden · Insert 12 Wood Dowels (3) into Left and Right Partition (I) & (K) as Dowel illustrated.
  • Page 15 STEP Dowels extend out 3/8". For more details, please see page 4 x 20 · Attach two Cam Bolts (1) to Bottom Panel (N) as illustrated. Do NOT over-tighten. · Insert four Wood Dowels (3) into Bottom Panel (N) as illustrated. ·...
  • Page 16 STEP Dowels extend out 3/8". For more details, please see (x12) x 14 page 4 · Attach 14 Cam Bolts (1) to Left and Right Side Panel (L) & (M) as illustrated. Do NOT over-tighten. · Insert four Wood Dowels (3) into Left and Right Side Panel (L) & (M) as Wooden illustrated.
  • Page 17 STEP Wooden Dowel Hole for wooden dowel Use one drop of glue in dowel hole. · Attach Top Apron (B) to Top Panel (A) using five Screws (7) as illustrated. ameriwoodhome.com Tube...
  • Page 18 STEP Wooden Dowel Hole for wooden dowel · Attach Fixed Shelf Rail (F) to Fixed Shelf (E) using five Cam Locks Use one drop of glue in (2) as illustrated. dowel hole. ameriwoodhome.com Tube...
  • Page 19 STEP Wooden Dowel Hole for wooden dowel Use one drop of glue in dowel hole. · Attach Upper Molding (G) to Fixed Shelf (E) using four Cam Locks (2) as illustrated. ameriwoodhome.com Tube...
  • Page 20 STEP Wooden Dowel Hole for wooden dowel · Attach Side Molding (J) to Left and Right Partition (I) & (K) Use one drop of glue in using six Cam Locks (2) as illustrated. dowel hole. ameriwoodhome.com Tube...
  • Page 21 STEP Wooden Dowel Hole for wooden dowel Use one drop of glue in · Attach Lower Back Panel (H) to Left Partition (I) using Cam dowel hole. Lock (2) as illustrated. ameriwoodhome.com Tube...
  • Page 22 STEP Wooden Dowel Hole for wooden dowel Use one drop of glue in · Attach Lower Back Panel (H) to Right Partition (K) using dowel hole. Cam Lock (2) as illustrated. ameriwoodhome.com Tube...
  • Page 23 STEP · Attach boards (H), (I), (K), (J) to Bottom Panel (N) using four Screws (8) and two Cam Locks (2) as illustrated. Wooden Dowel Hole for wooden dowel Use one drop of glue in dowel hole. Unfinished ameriwoodhome.com Tube...
  • Page 24 STEP · Attach three Middle Legs (P) to Bottom Panel (N) as illustrated. Do NOT over-tighten. ameriwoodhome.com Tube...
  • Page 25 STEP Wooden Dowel Hole for wooden dowel Use one drop of glue in dowel hole. · Attach three Upper Partitions (D) to Fixed Shelf (E) using six Screws (8) as illustrated. · Make sure the cam lock holes face to the same side as illustrated. Cam lock hole orientation Cam lock hole...
  • Page 26 STEP Wooden Dowel Hole for wooden dowel Use one drop of glue in · Attach Upper Back Panel (C) to Fixed Shelf (E) using four dowel hole. Screws (8) as illustrated. ameriwoodhome.com Tube...
  • Page 27 STEP · Attach Fixed Shelf (E) to boards (H), (K), (I) using six Cam Locks (2) as illustrated. Wooden Dowel Hole for wooden dowel Use one drop of glue in dowel hole. ameriwoodhome.com Tube...
  • Page 28 STEP · Attach two Metal Plates (6) to Upper Molding (G) and Side Moldings (J) using four Screws (10) as illustrated. ameriwoodhome.com Tube...
  • Page 29 STEP · With the assistance of a second person, carefully turn the unit over so that the front is accessible. Wooden Dowel · Attach Left Side Frame (L) to boards (H), (N), (E), and (F) using five Cam Locks (2) as illustrated. Hole for wooden dowel...
  • Page 30 STEP · Attach Right Side Frame (M) to boards (H), (N), (E), and (F) Wooden using five Cam Locks (2) as illustrated. Dowel Hole for wooden dowel Use one drop of glue in dowel hole. ameriwoodhome.com Tube...
  • Page 31 STEP · With the assistance of a second person, turn the unit upright. · Attach Left and Right Side Frame (L) & (M) to Upper Back Panel (C) and Lower Back Panels (H) using four Cam Locks (2) as illustrated. ameriwoodhome.com Tube...
  • Page 32 STEP x 14 (x10) · Attach Top Panel (A) to boards (L), (M), (C) and (D) using 14 Cam Locks as illustrated. Wooden · Attach ten Cam Covers (17) to boads (L), (M) and (D) as illustrated. Dowel Hole for wooden dowel Use one drop of glue in...
  • Page 33 STEP · Insert 8 Shelf Supports (12) into the TV Stand at the desired shelf heights. · Put Adj Shelves (Q) onto the Shelf Supports (12) as illustrated. ameriwoodhome.com Tube...
  • Page 34 STEP · Attach four Hinges (11) to Left and Righ Door (O) & (R) using eight Screws (9) as illustrated. · Attach two Knobs (13) to Left and Righ Door (O) & (R) using four Bolts (4) as illustrated. ameriwoodhome.com Tube...
  • Page 35 STEP x 16 · Attach Left and Right Door (O) & (R) to Left and Right Side Frame (L) & (M) using 16 Screws (9) as illustrated. · Attach four Bumpers (14) to Left and Right Door (O) & (R) as illustrated. ameriwoodhome.com Tube...
  • Page 36 STEP To adjust the vertical height. Loosen the four screws "A" on both hinges. Two of them are usually in slotted holes which allows you to adjust up of down by a few mm and then tighten back Para ajustar la altura vertical Afloje los cuatro tornillos "A"...
  • Page 37 STEP · Carefully insert the Fireplace (AA) into the back of the TV Stand and slide to the front of the unit. · Attach Fireplace (AA) to Side Molding (J) with 6 Screws (5) as illustrated. ameriwoodhome.com Tube...
  • Page 38 STEP · Attach Metal Bracket (16) to Bottom Panel (N) using screw (5) as illustrated. ameriwoodhome.com Tube...
  • Page 39 STEP BEFORE CONNECTING THE UNIT TO A WALL ELECTRIC OUTLET Please carefully read and follow instructions and safety warnings in “Fireplace Homeowners Operating Manual” to operate your fireplace. WARNING IF THE INFORMATION IN THE FIREPALCE OPERATING MANUAL IS NOT FOLLOWED, AN ELECTRIC SHOCK OR FIRE MAY RESULT IN PROPERTY DAMAGE, PERSONAL INJURY , OR LOSS OF LIFE .

  • Page 40: Warning Label

    STEP WARNING ADVERTENCIA AVERTISSEMENT (x1) Apply Warning Label (18) to the center of Top Panel (A) as shown, ensuring that the TV covers the label. Please note that the label is permanent. Once affixed to your item, it will not come off and will damage the surface if removal is attempted.
  • Page 41 Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. WARNING ADVERTENCIA AVERTISSEMENT Certificate of Conformity 1. This certificate applies to the Dorel Home Furnishings, Inc. product identified by this instruction manual. 2.
  • Page 42 Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this Ameriwood Home product, and to give us your valuable feedback. ameriwoodhome.com Tube...
  • Page 43 Español Cubierta Delantera Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo para referencia en el futuro. No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener ayuda. Llamenos al: 1-800-489-3351 (Gratis) Visitar: www.ameriwoodhome.com PRECAUCION Este mueble puede volcarse y causar graves heridas y/o muerte.
  • Page 44 Español Identificación de los Paneles (Página 5-7) Lista de Piezas (Página 8-9) Tamaño real Este no es el tamaño real Este no es el tamaño real PANEL SUPERIOR Perno de leva (11) Bisagra Bloqueo de leva (12) Soporte de estante DELANTAL SUPERIOR Taco de madera (13)
  • Page 45 Español Página 15 Conecte dos pernos de leva (1) al panel inferior (N) como se ilustra. NO apriete demasiado. Inserte cuatro clavijas de madera (3) en el panel inferior (N) como se ilustra. Inserte ocho clavijas de madera (3) en el panel trasero inferior (H) x 2 como se ilustra. Página 16 Conecte 14 pernos de leva (1) al panel lateral izquierdo y derecho (L) y (M) como se ilustra.
  • Page 46 Español Página 29 Con la ayuda de una segunda persona, gire con cuidado la unidad para que se pueda acceder al frente. Conecte el marco lateral izquierdo (L) a las tablas (H), (N), (E) y (F) usando cinco cerraduras de leva (2) como se ilustra.
  • Page 47 Visite el sitio web de su distribuidor local, califique el producto que compró y déjenos sus comentarios. Nos gustaría enviar un gran "Agradecimiento" a todos nuestros clientes por tomarse el tiempo de ensamblar este producto de Ameriwood Home, y por darnos sus valiosos comentarios. Gracias ameriwoodhome.com...
  • Page 48 Français Couverture Avant CE LIVRET D'INSTRUCTION CONTIENT DES INFORMATIONS IMPORTANTES SUR LA SÉCURITÉ. VEUILLEZ LIRE ET GARDER POUR UNE RÉFÉRENCE FUTURE Ne retournez pas ce produit! Contactez notre équipe de service à la clientèle amicale d'abord pour obtenir de l'aide. Appelez-nous: 1-800-489-3351 (sans frais) Visitez: www.ameriwoodhome.com ATTENTION...
  • Page 49 Français Identification des matériaux Liste des pièces (Page 8-9) (Page 5-7) Taille réelle Pas de taille réelle Pas de taille réelle Boulon à came (11) Charnière PANNEAU SUPÉRIEUR Verrouillage à came (12) Support d'étagère TABLIER SUPÉRIEUR Cheville en bois (13) Bouton PANNEAU ARRIÈRE SUPÉRIEUR (14)
  • Page 50 Français Page 15 Fixez deux boulons à came (1) au panneau inférieur (N), comme illustré. Ne pas trop serrer. Insérez quatre chevilles en bois (3) dans le panneau inférieur (N), comme illustré. Insérez huit chevilles en bois (3) dans le panneau arrière inférieur (H) x 2 comme illustré. Page 16 Fixez 14 boulons à...
  • Page 51 Français Page 29 Avec l'aide d'une deuxième personne, retournez soigneusement l'appareil afin que la façade soit accessible. Fixez le cadre latéral gauche (L) aux planches (H), (N), (E) et (F) à l'aide de cinq verrous à came (2), comme illustré. Page 30 Fixez le cadre latéral droit (M) aux planches (H), (N), (E) et (F) à...
  • Page 52 Visitez le site Web de votre détaillant local, évaluez le produit que vous avez acheté et laissez-nous vos commentaires ! Nous tenons à offrir un grand "Merci" à tous nos clients pour avoir pris le temps d'assembler ce produit "Ameriwood Home", et de nous donner vos commentaires précieux. Merci ameriwoodhome.com...
