Removing the Stand

1 2
Important: Before removing the stand, turn off the monitor, disconnect all
cables, and place the monitor on a flat, stable surface with the
screen facing down.

Mounting the Monitor

After removing the stand, the monitor can be mounted using an optional mounting
kit.
Note: For use only with a UL certified mounting kit. To obtain a mounting kit or
height adjustment base, contact ViewSonic® or your local dealer.
Refer to the table below for the standard dimensions for mounting kits.
Maximum Loading
14 kg
1. Attach the mounting bracket to the VESA mounting holes at the rear of the
monitor, securing it with four M4 x 8 mm screws.
2. Follow the mounting kit instructions to mount the monitor.
1
3 4
Hole pattern (W x H) Screw Specification Screw Quantity
75 x 75 mm
75 mm
2 3
1
2
M4 x 8 mm
11
4
1
2
4
