Power Dynamics 952.541 Instruction Manual page 4

OVERVIEW
Power ON / OFF
Short press for join the speaker group
Long press for exit the speaker group
No function
Volume UP
Volume Down
Previous
Play / Pause
Next
Switch UP for the predefined Channel
Switch Down for the predefined Channel
Short press for switch to the BT play mode
BT
Long press for switch to the BT pair mode
Short press for connect the speaker to the WIFI
Long press for restore to the factory settings
Switch between BT and WIFI
CONNECTION
Connect the DC adapter to the speakers and connect to the 110V~230V AC power. Then you can turn on power switch. The
status indicator LED will be red and fast blinks, after about 10 seconds the speaker will sound a tone, it means the speaker is
ready.
CONNECTING WITH BT
Connecting your BT-device to the speaker, follow below steps:
1. Turn on BT on your device
Search for "Smart-audio"
2.
Connect with "Smart-audio"
3.
Your device is now connected, no password needed
DISCONNECTING OR RECONNECTING WITH BT
If you want to change from BT-device, follow below steps:
Disconnect the current BT-device ("OFF")
1.
2. Connect new BT-device by following above steps
If you move out of range or turn off the BT-function on your device, the BT of the speaker will disconnect. To reconnect turn on
the BT on the device.
.
4
1. Power switch
2. DC Power connector
3. Speaker output connector for passive speaker
4. Infrared receiver and LED indicator
