EN User Manual | Washer Dryer
LWX60746B
aeg.com\register

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LWX60746B and is the answer not in the manual?

Questions and answers

Related Manuals for AEG LWX60746B

Summary of Contents for AEG LWX60746B

  • Page 1 EN User Manual | Washer Dryer LWX60746B aeg.com\register...

  • Page 2: Table Of Contents

    Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooting, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. PRODUCT DESCRIPTION................8 4. TECHNICAL DATA..................9 5.

  • Page 3: General Safety

    • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
  • Page 4 • The appliance shall be installed as a freestanding product or below the kitchen worktop if space margins permit. • Do not install the appliance behind a lockable door, a sliding door or a door with a hinge on the opposite side, that would prevent the appliance door from being fully open.

  • Page 5: Safety Instructions

    • Items that have been soiled with substances such as vegetable or mineral oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed separately with an extra amount of detergent before being dried in the washer dryer. •...

  • Page 6: Electrical Connection

    • Make sure that there is air circulation (water meters, etc.), let the water flow until between the appliance and the floor. it is clean and clear. • Remove all the packaging and the transit • Ensure that there are no visible water bolts.
  • Page 7 2.5 Service repairers, and that not all spare parts are relevant for all models. • To repair the appliance contact the • Concerning the lamp(s) inside this product Authorised Service Centre. Use original and spare part lamps sold separately: spare parts only. These lamps are intended to withstand •...

  • Page 8: Product Description

    Access your appliance details, documentation and articles on how to use the best features (User Manual also available at aeg.com/manuals ) • Get usage advice, troubleshooting, service and repair information (also available at aeg.com/ support ) • Buy accessories, Consumable and Original Spare parts for your appliance (also available at aeg.com/ shop ) ENGLISH...

  • Page 9: Technical Data

    4. TECHNICAL DATA Dimension Width/ Height/ Total depth 59.7 cm /84.7 cm /55.7 cm Electrical connection Voltage 230-240 V Overall power 2100 W Fuse 13 A Frequency 50 Hz Level of protection against ingress of solid particles and moisture IPX4 ensured by the protective cover, except where the low voltage equipment has no protection against moisture Cold water...

  • Page 10: Information For Installation

    4. Open the door. Remove the polystyrene 7. Remove the power supply cable and the piece from the door seal and all the items drain hose from the hose holders. from the drum. 8. Remove the three bolts by using a 5.
  • Page 11 1. Install the appliance on a flat hard floor. sure that the inlet hose is not in vertical The appliance must be levelled and stable. position. Make sure that the appliance does not touch 3. If necessary, loosen the ring nut to set it the wall or other units and there is air in the correct position.

  • Page 12: Installation On Suspended Flooring

    It is possible to connect the drain hose in different ways: min.600 mm max.1000 mm * Subject to change spare parts without notice. Make sure that the drain hose makes a loop To a stand pipe with vent hole - Insert the to prevent particles going into the appliance drain hose directly into a drain pipe or stand from the sink.

  • Page 13: Control Panel

    The rating plate and the 'Technical Data' The power supply cable must be easily chapter indicate the necessary electrical accessible after installing the appliance. ratings. Make sure that they are compatible For any electrical work required to install this with the mains power supply. appliance, contact our Authorised Service Check that your domestic electrical Centre.
  • Page 14 6.2 Display Time area : Programme duration : Selected drying time : Delay start : Alarm codes : Message of error : The programme is completed. Time programme indicators : Normal duration indicator : Quick indicator : Super quick indicator Delay start indicator Child safety lock indicator Door locked indicator...

  • Page 15: Programmes

    7. PROGRAMMES 7.1 Programme Chart Programme Maximum load Programme description Default temperature Reference spin (Type of load and level of soiling) Temperature range speed 7 kg White cotton and fast-coloured cotton. Normally 1600 rpm soiled items. Eco 40-60 (Wash only mode) 1600 rpm - 800 rpm 40 °C 4 kg...
  • Page 16 Programme Maximum load Programme description Default temperature Reference spin (Type of load and level of soiling) Temperature range speed Rinse To rinse and spin the laundry. All fabrics, except 7 kg woollens and very delicate fabrics. Reduce the spin 1600 rpm speed accordingly to the type of laundry.
  • Page 17 Programme Cottons ■ ■ ■ ■ ■ ■ ■ Synthetics ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ Wool Delicates ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ ■ Anti-allergy 20min 3kg ■ ■ ■...

  • Page 18: Automatic Drying

    7.2 Automatic drying Initial cycle times for programmes with Auto Dry option are only estimates, the actual drying time may slightly differ from the time displayed. Dryness Level Type of fabric Load Cottons and Linen up to 4 kg Extra Dry (bathrobes, bath towels, etc) For towelling materials For items to be stored...

  • Page 19: Options

    7.4 Woolmark Wool Care - Blue according to the instructions on the garment label and those issued by the manufacturer of this washing machine. M1380. • The wool drying cycle of this machine has been tested and approved by The Woolmark Company.

  • Page 20: Settings

    The display shows the related indicator. 8.5 Prewash 8.8 Time Save With this option you can add a prewash phase to a washing programme. This option Press Time Save to decrease the programme is recommended for heavily soiled laundry, time. especially if containing sand, dust, mud and other solid particles.

  • Page 21: Before First Use

    10. BEFORE FIRST USE 2. Open the water tap. 3. Put 2 litre of water in the detergent compartment for washing phase. During installation or before first use you This activates the drain system. may observe some water in the 4.

  • Page 22: Setting A Programme

    11.3 Check the position of the • Do not set the delay start function. detergent flap 5. Measure out the detergent and the fabric conditioner. 1. Pull out the detergent dispenser until it 6. Carefully close the detergent dispenser. stops. Make sure that the flap does not cause a 2.

  • Page 23: Starting A Programme With The Delay Start

    11.8 Interrupting a programme and changing the options After approximately 15 minutes from the You can change only some options before start of the programme: they operate. • The appliance adjusts automatically the programme duration agree with 1. Press the laundry load. The indicator flashes.

  • Page 24: At The End Of The Programme

    11.11 At the end of the programme 3. When the programme is completed, and the door lock indicator goes off, you • The appliance stops automatically. can open the door. • The acoustic signal operates (if it is 4. Turn the programme knob to position activated).

  • Page 25: Drying At Automatic Levels

    12.2 Drying at automatic levels calculates also the duration of the anti- crease and the cooling phases. The laundry can be dried at pre-defined 2. Press to start the programme. levels of dryness: • The display shows regularly a new time value.

  • Page 26: Non-Stop Programme

    13.1 Non-Stop programme The display shows regularly a new time value. 1. Turn the programme knob to the desired programme to activate the appliance. 2. Load the laundry one item at a time. The last minutes of the drying cycle the appliance performs the anti-crease and the cooling phases.

  • Page 27: How To Remove The Fluff In The Garments

    To prevent the fluff in your laundry, we 1. Empty the drum. recommend that you: 2. Clean the drum, the gasket and the door with a wet cloth. • Do not wash dark fabrics after you have 3. Set the rinse programme. washed and dried light coloured fabrics 4.

  • Page 28: Stubborn Stains

    woollens, cottons, etc), the colour of clothes, size of the load, degree of soiling, wash temperature and hardness of the water used. • Follow the instructions that you find on packaging of the detergents or other treatments without exceeding the indicated maximum level ( •...

  • Page 29: Drying Cycle Duration

    15.5 Water hardness • = The item can be tumble dried If the water in your area is hard or medium • = The drying cycle is at high hard, we recommend that you use a water temperature softener for washing machines. •...

  • Page 30: Removing Foreign Objects

    After each cycle, keep the door and the CAUTION! detergent dispenser slightly open to get air circulation and dry the humidity inside the Do not use alcohol, solvents or chemical appliance: this will prevent mildew and products. odours. CAUTION! If the appliance is not used for a long time: close the water tap and unplug the appliance.

  • Page 31: Cleaning The Detergent Dispenser

    Always obey the instructions that you find on the packaging of the product. Check and remove objects (if there are any) that could be trapped in the fold. Make sure that no laundry remains between the seal and the door. Use a moist cloth to wipe off any dirt or water Clean it when needed, using ammonia cream residue left behind in the door seal after...

  • Page 32: Cleaning The Drain Filter

    16.8 Cleaning the drain filter Regularly check the drain pump filter and make sure that it is clean. Do not clean the drain filter if the water in the appliance is hot. Do not remove the filter while the appliance operates. Clean the drain pump if : -The appliance does not drain the water.

  • Page 33: Cleaning The Inlet Hose And The Valve Filter

    16.9 Cleaning the inlet hose and the valve filter ENGLISH...

  • Page 34: Emergency Drain

    45° 20° 16.10 Emergency drain 1. Disconnect the mains plug from the mains socket. Because of a malfunction, the appliance 2. Close the water tap. cannot drain the water. 3. Put the two ends of the inlet hose in a container and let the water flow out of the If this occurs, do steps (1) through (8) of hose.
  • Page 35 With some problems, the display shows an alarm code and the Start/ Pause button may flash continuously: Problem Possible solution • Make sure that the water tap is open. • Make sure that the pressure of the water supply is not too low. For this infor‐ The appliance does not fill mation, contact your local water authority.
  • Page 36 Problem Possible solution • Set the spin programme. The spin phase does not op‐ erate or the washing cycle • Adjust manually the items in the tub and start the spin phase again. This prob‐ lasts longer than usual. lem may be caused by balance problems. •...

  • Page 37: Emergency Door Opening

    Problem Possible solution The fabrics washed in the previous cycle released fluff of a different colour: • The drying phase helps to eliminate some fluff. • Clean the clothes with a fluff remover. In case of an excessive amount of fluff in the drum refer to “Fluff in the fabrics" paragraph for more details.

  • Page 38: Consumption Values

    18. CONSUMPTION VALUES 18.1 Introduction The QR codes on the EU and UK energy labels supplied with the appliance provide a web link to the information related to the performance of the appliance. For the energy label with the EU flag, it is also possible to find the information in the EU EPREL database using the link https://eprel.ec.europa.eu and the model name and product number that you find on the rating plate of the...
  • Page 39 Eco 40-60 pro‐ rpm 1) Litres hh:mm °C gramme Quarter load 0.230 33.0 02:27 54.00 26.0 1551 Maximum spin speed. Wash and dry cycle Eco 40-60 pro‐ rpm 1) gramme and Cup‐ Litres hh:mm °C board dry level Full load 2.700 70.0 05:40...

  • Page 40: Environmental Concerns

    Programme rpm 1) Litres hh:mm °C Wool 0.200 55.0 01:05 30.00 30.0 1200 30°C Reference indicator of the spin speed. Suitable for washing heavily soiled textiles. Suitable for washing lightly soiled cottons, synthetic and mixed fabrics. It also performs as quick washing cycle for lightly soiled laundry. 18.5 Common programmes - Wash and dry These values are indicative only.
  • Page 44 157083470-A-132024...
