AEG LWX60846B User Manual

AEG LWX60846B User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
aeg.com/register
EN User Manual | Washer Dryer
LWX60846B
aeg.com\register

Advertisement

loading
Need help?

Need help?

Do you have a question about the LWX60846B and is the answer not in the manual?

Questions and answers

Rochelle Bloch
February 28, 2025

What is the change of variable spin speeds in this model?

0
1 comments:
Mr. Anderson
February 28, 2025

The AEG LWX60846B model has variable spin speeds, with a maximum spin speed of 1600 rpm. Specific spin speeds for different wash programs include:

- Cottons: Up to 1600 rpm
- Synthetics: Up to 1200 rpm
- Delicates: Up to 1200 rpm
- Wool: Up to 1200 rpm

These spin speeds help in reducing drying time and are adjustable based on the selected wash program.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for AEG LWX60846B

Summary of Contents for AEG LWX60846B

  • Page 1 EN User Manual | Washer Dryer LWX60846B aeg.com\register...
  • Page 2 Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooting, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. PRODUCT DESCRIPTION................7 4. TECHNICAL DATA..................8 5.
  • Page 3 they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved. • Children between 3 and 8 years of age and persons with very extensive and complex disabilities shall be kept away from the appliance unless continuously supervised.
  • Page 4 • Do not install the appliance behind a lockable door, a sliding door or a door with a hinge on the opposite side, that would prevent the appliance door from being fully open. • Connect the mains plug to the mains socket only at the end of the installation process.
  • Page 5 be washed separately with an extra amount of detergent before being dried in the washer dryer. • Do not use the appliance if items have been soiled with industrial chemicals. • Do not dry unwashed items in the wash dryer. •...
  • Page 6 must be reattached to lock the drum to • When unpacking the appliance, It is prevent an internal damage. possible to see water flowing from the • Always take care when moving the drain hose. This is due to the testing of the appliance as it is heavy.
  • Page 7 • Concerning the lamp(s) inside this product • Cut off the mains electrical cable close to and spare part lamps sold separately: the appliance and dispose of it. These lamps are intended to withstand • Remove the door catch to prevent children extreme physical conditions in household or pets from becoming trapped in the appliances, such as temperature,...
  • Page 8 • Get usage advice, troubleshooting, service and repair information (also available at aeg.com/ support ) • Buy accessories, Consumable and Original Spare parts for your appliance (also available at aeg.com/ shop ) 4. TECHNICAL DATA Dimension Width/ Height/ Total depth 59.7 cm /84.7 cm /55.7 cm...
  • Page 9 5.1 Unpacking from the drum. WARNING! Remove all the packaging and the transit bolts before installing the appliance. 1. Use the gloves. Remove the external film. If necessary, use a cutter. 5. Put one of the polystyrene packaging elements on the floor behind the appliance.
  • Page 10 7. Remove the power supply cable and the 1. Install the appliance on a flat hard floor. drain hose from the hose holders. The appliance must be levelled and stable. Make sure that the appliance does not touch the wall or other units and there is air circulation below the appliance.
  • Page 11 contact the authorized service center for WARNING! information to replace the hose. The inlet water shall not exceed 25 °C. Water drainage The drain hose should stay at a height of no less than 60 cm and not more than 100 cm. 3/4”...
  • Page 12 The rating plate and the 'Technical Data' chapter indicate the necessary electrical ratings. Make sure that they are compatible Make sure that the plastic guide cannot with the mains power supply. move when the appliance drains and the drain hose end is not immersed in the Check that your domestic electrical water.
  • Page 13 6. CONTROL PANEL 6.1 Control panel description Programme knob Additional rinse (Extra Rinse) Spin speed reduction (Spin) Automatic drying level (Auto Dry) Temperature selection (Temperature ) Start/Pause Display Delay start setting (Delay Start) Drying time selection (Time Dry) Time saving (Time Save) Prewash phase (Prewash) 6.2 Display...
  • Page 14 Time area : Programme duration : Selected drying time : Delay start : Alarm codes : Message of error : The programme is completed. Time programme indicators : Normal duration indicator : Quick indicator : Super quick indicator Delay start indicator Child safety lock indicator Door locked indicator Indicators of dryness level...
  • Page 15 Programme Maximum load Programme description Default temperature Reference spin (Type of load and level of soiling) Temperature range speed Eco 40-60 + Cupboard dry level White cotton and fast-coloured cotton. 4 kg (Dry only mode) Cottons White cotton and coloured cotton. 8 kg 40 °C Normally, heavily and lightly soiled items.
  • Page 16 Programme Maximum load Programme description Default temperature Reference spin (Type of load and level of soiling) Temperature range speed Off position According to UK Ecodesign for Energy-Related Products and Energy Information Regulations and to EU Ecode‐ sign Regulation 2019/2023 and the EU Energy Label Regulation 2019/2014, this programme at default temperature and spin speed, in washing only mode, with rated capacity 8 kg is able to clean normally soiled cotton laundry de‐...
  • Page 17 Programme Rinse ■ ■ ■ ■ ■ ■ Wool ■ Synthetics ■ Cottons NonStop 60min ■ Suitable detergents for each programme Programme Universal Liquid Liquid for Delicates Special Universal coloureds woollens powder 1) Eco 40-60 ▲ ▲ ▲ Cottons ▲ ▲...
  • Page 18 Dryness Level Type of fabric Load For items to be stored Cottons and Linen up to 4 kg (bathrobes, bath towels, etc) Synthetics and mixed fabrics up to 3 kg (jumpers, blouses, underwear, household and bed linen) Wool items (woollen jumpers) up to 1 kg Cottons and Linen up to 4 kg...
  • Page 19 instructions issued by the manufacturer. The Woolmark symbol is a Certification mark M1381. in many countries. 8. OPTIONS 8.1 Temperature Set this option to change the default You cannot set all time values for temperature. different types of fabrics. Indicator = cold water.
  • Page 20 • QUICK: to wash items with daily soil. • SUPER QUICK: to wash quickly items Some programmes accept only one of with almost no soil. these options. 9. SETTINGS pauses, delayed start time). To visualise this 9.1 Child Lock value, proceed as follows: With this option you can prevent that the 1.
  • Page 21 If the procedure does not work (due to timeout, wrong programme dial position or wrong keys combination), switch the appliance off and repeat sequence from the beginning. 10. BEFORE FIRST USE 2. Open the water tap. 3. Put 2 litre of water in the detergent compartment for washing phase.
  • Page 22 11.2 Using detergent and additives With the flap in the position DOWN: • Do not use gelatinous or thick liquid 1. Measure out the detergent and the fabric detergents. • Do not exceed to liquid detergent dose conditioner. indicated on the flap. 2.
  • Page 23 If the indicator flashes, the door is locking. If the display shows an alarm If you set something incorrect, the display message after the indicator shows the message flashed for a few seconds, it indicates that the door is not properly locked (for 11.5 Starting a programme without more details see Troubleshooting the delay start...
  • Page 24 11.9 Cancelling a running • Close the water tap. programme • Turn the programme knob to position On/Off to deactivate the appliance. 1. Turn the programme knob to position • Keep the door ajar, to prevent the mildew to cancel the programme and to and odours.
  • Page 25 12. DAILY USE - DRYING ONLY The display shows the door locked indicator WARNING! . The drying indicator starts to flash. Refer to Safety chapters. You cannot set all dryness levels for any type of laundry. This appliance is an automatic washer dryer.
  • Page 26 2. Remove the laundry from the appliance. When the door locked goes off in the Make sure that the drum is empty. display, you can open the door. 3. Keep the door ajar, to prevent mildew and 1. Turn the programme knob to On/Off to odours.
  • Page 27 13.4 End of the programme The appliance stops automatically. The If you set only 10 minutes of drying after acoustic signals operate (if they are active). washing, the appliance calculates also For more information see "At the end of the the duration of the anti-crease and the drying programme "...
  • Page 28 • A very small load can cause balance 15.3 Detergent type and quantity. problems with the spin phase leading to excessive vibration. If this occurs: The choice of detergent and use of correct - interrupt the programme and open the quantities not only affects your wash door (refer to "Daily Use"...
  • Page 29 15.7 Items not suitable for drying • sudsing, • reduced washing effect, Do not set a drying programme for this • inadequate rinsing, laundry: • a greater impact for the environment. • Synthetic curtains. • Pieces of clothing with metal inserts. 15.4 Ecological hints •...
  • Page 30 To avoid the static charge at the end of the When the drying programme is completed drying cycle: remove the laundry promptly. 1. Use fabric conditioner in the washing cycle. 2. Use special fabric conditioner for tumble dryers. 16. CARE AND CLEANING 16.2 Removing foreign objects WARNING! Refer to Safety chapters.
  • Page 31 To remove rust particles use only special Clean it when needed, using ammonia cream products for washing machines. Do this cleanser agent without scratching the seal separately from the laundry wash. surface. Always obey the instructions that you find Always obey the instructions that you find on the packaging of the product.
  • Page 32 16.8 Cleaning the drain filter Do not clean the drain filter if the water in the appliance is hot. • Repeat the steps 2 and 3 until the water stops flowing out. • Always keep a rag nearby to dry up any water spillage. 180°...
  • Page 33 Regularly check the drain pump filter and make sure that it is clean. Make sure that the impeller of the pump can rotate. If it does not rotate, contact the Authorised Service Centre. Make sure also that you tighten the filter correctly to prevent leakages.
  • Page 34 16.9 Cleaning the inlet hose and the valve filter 45° 20° 16.10 Emergency drain 1. Disconnect the mains plug from the mains socket. Because of a malfunction, the appliance 2. Close the water tap. cannot drain the water. 3. Put the two ends of the inlet hose in a If this occurs, do steps (1) through (8) of container and let the water flow out of the 'Cleaning the drain filter'.
  • Page 35 17. TROUBLESHOOTING WARNING! Refer to Safety chapters. 17.1 Alarm Codes and Possible failures The appliance does not start or it stops during operation. First try to find a solution to the problem (refer to the tables). WARNING! Deactivate the appliance before carrying out any check. With some problems, the display shows an alarm code and the Start/ Pause button may flash continuously:...
  • Page 36 • Make sure that the sink spigot is not clogged. • Make sure that the drain hose has no kinks or bends. The appliance does not • Make sure that the drain filter is not clogged. Clean the filter, if necessary. Re‐ drain the water.
  • Page 37 Problem Possible solution • Make sure that a washing programme that ends with water in tub, has not been selected. • Make sure that the washing programme is finished. • Set the drain or the spin programme if there is water in the drum. You cannot open the appli‐...
  • Page 38 17.2 Emergency door opening To open the door, proceed as follows: 1. Turn the selector to On/Off position to In case of power failure or appliance failure switch the appliance off. the appliance door remains locked. The 2. Disconnect the mains plug from the washing programme continues, when the mains socket.
  • Page 39 18.2 Legend Laundry load. hh:mm Programme duration. Energy consumption. °C Temperature in the laundry. Litres Water consumption. Spin speed. Remaining moisture at the end of the cycle. The higher is the spin speed, the higher is the noise and the lower is the remaining moisture at the end of washing cycle. Values and programme duration may differ depending on different conditions (e.g.
  • Page 40 18.4 Common programmes - Washing only These values are indicative only. Programme rpm 1) Litres hh:mm °C Cottons 2.250 85.0 04:00 44.00 85.0 1600 90°C Cottons 1.350 80.0 03:25 44.00 55.0 1600 60°C Cottons 0.250 80.0 02:50 44.00 20.0 1600 20°C Synthetics 0.650...
  • Page 41 19. ENVIRONMENTAL CONCERNS appliances marked with the symbol with Recycle materials with the symbol . Put the the household waste. Return the product to packaging in relevant containers to recycle it. your local recycling facility or contact your Help protect the environment and human municipal office.
  • Page 44 157089050-A-362024...
