AEM G13000R Installation And Operation Manual Supplement

P139-HD Installation and Operation Manual Supplement
This supplement contains installation and operation information that is unique to the G13000R Digital Audio
Router. Installation and operation information common to the G13000 unit can be found in the P139-HD
Installation Manual and the P139-HD Digital Audio System User Manual.
Prepared By:
Tony Pearson
Designer
07-Mar-2025
1.1 Product Description
The G13000R Digital Audio Router is identical to the G13000 with the following exceptions:
a) The G13000R has a physically reduced mechanical outline with two mounting orientations,
wide and narrow for added flexibility.
b) The G13000R has reduced the number of available Headset output and Radios.
c) The G13000R has an integrated 25W speaker amplifier.
1.2 Product Approval/Certification
The G13000R currently has no STC or TSO certification.
March 6, 2025 Rev: 1.00
ENG-FORM: 810-0100.DOTX
CONFIDENTIAL AND PROPRIETARY TO ANODYNE ELECTRONICS MANUFACTURING CORP.
G13000R Digital Audio Router
Checked By:
Keatin Colegrave
Designer I
07-Mar-2025

Section 1.0 Description

Approved By:
Nathan Meade
TS Manager
07-MAR-2025
Johnathon White
Program Manager
07-March-2025
Page 1
