TouchTunes HRC540A Quick Start Manual

Document Number: MAN901214-001
1 About This Guide
1.1 Purpose
This guide explains the setup and operation of the TouchTunes 27 MHz
single-frequency wireless remote control, P/N 700842-001 (which should be
ordered as P/N 600330-001) and the 433 MHz single-frequency wireless
remote control, P/N 700841-001 (which should be ordered as P/N 600329-
001).
1.2 Package Contents
•
Remote control;
•
Two (2) AAA alkaline batteries;
•
This guide (901214-001).
1.3 Overview
The TouchTunes single-frequency wireless remote control has integrated
flash memory to help prevent it from losing its ID when the batteries drain.
It is RF-based, which eliminates the need to point it directly at the jukebox
and is powered by two (2) 1.5V AAA batteries (included with the remote).
The black remote transmits a 27 MHz signal [ Figure 1 - 27 MHz Remote (Black) ]
The blue remote transmits a 433Mhz signal [ Figure 2 - 433 MHz Remote (Blue) ]
Last saved: 2024-08-06
HRC540A
Figure 1 27 MHz Remote (Black)
