- Page 1 TUMBLE DRYER OWNER’S MANUAL MODEL: TD-T37BS90HWM Read This Manual Read and follow the instructions carefully. Keep the operation instructions handy for future use . Please contact the customer service if you are in need of a new user manual.
-
Page 2: Table Of Contents
CONTENTS SAFETY INSTRUCTIONS Safety Instructions ............ INSTALLATION Product Description ..........Installation ..............OPERATION Quick Start ..............Before Each Drying ........... Control Panel ............. Option................Display................Programmes..............Instructions to Connection with the TSmartLife ................Drying Programmes Table ........Steam Function ............MAINTENANCE Cleaning and Care ............. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS Safety Instructions For your safety,the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury or loss of life. Explanation of the symbols: Warning! This combination of symbol and signal word indicates a potentially dangerous situation which may result in death or serious injuries unless it’s avoided. -
Page 4: Risk Of Electric Shock
SAFETY INSTRUCTIONS Safety Instructions • This appliance must be grounded. In the event of malfunction or breakdown , grounding will reduce the risk of electric shock by providing a path of least resistance for electric current. • This appliance is equipped with a cord having an equipment-grounding conductor and grounding plug. -
Page 5: Risk Of Injury
SAFETY INSTRUCTIONS • The appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by a utility. • Do not use multiple outlet sockets,an extension power cable or double adapter with this appliance. - Page 6 SAFETY INSTRUCTIONS Warning! Risk of Explosion & Fire • Please do not dry the clothes with any flammable substances such as kerosene or alcohol. • The tumble dryer is not to be used if industrial chemicals have been used for cleaning. •...
- Page 7 SAFETY INSTRUCTIONS • If it is unavoidable that fabrics that contain vegetable or cooking oil or have been contaminated by hair care products are placed in a tumble dryer they should first be washed in hot water with extra detergent. This will reduce, but not eliminate, the hazard.
- Page 8 SAFETY INSTRUCTIONS For use in EU contries： • The appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 9 SAFETY INSTRUCTIONS • After the stops due to various reasons (power outage, fuse problem, machine door opening, etc.) while UV Hygiene Programs are in progress, the program will resume to disinfection from where it left. • In cases where UV-C lamp and related parts need to be replaced (expiration of lamp life, break of lamp glass, etc.), call the technical service.
- Page 10 For use in other contries This appliance doesn’t have symbol above. If you want to dispose your appliance, please contact your local authority or retailer for futher information on collection and disposal. Rated capacity Model TD-T37BS90HWM 8.0kg...
-
Page 11: Installation
INSTALLATION Product Description Power cord Top board Control panel Drum Door Door filter Note! The product picture is for illustration only, please refer to real product as reference. Accessories The following parts are optional for specific models. If your dryer has following parts, please wear gloves to install them as per the instruction below . -
Page 12: Installation Place
INSTALLATION Transport Move cautiously. Do not grasp any salient parts of machine. The machine door cannot be used as the handle for transport. If the dryer can't be transported erectly, the dryer can be tilted to right less than 30°. Risk of injury and damage! Improper handling of the appliance may result in injury. -
Page 13: Level Adjusting
INSTALLATION Level Adjusting Once in its permanent operating position, check that the dryer is absolutely level with the aid of a spirit level. If it is not, adjust the feet by hand or using a tool. Raise Lower Power Supply Connection 1.Make sure that the voltage of the power supply is more than the electric specification. -
Page 14: Operation
OPERATION Quick Start Note! Before using, make sure the tumble dryer is installed correctly. Before Drying plug in load close the door Drying program select program select function start or default After Drying Buzzer beep and " "on display. power off clean the filter open the door and take out laundry... -
Page 15: Before Each Drying
OPERATION Before Each Drying Note! • Leave it to stand for 2 hours after transporting. Before first use, please use the soft fabric to clean the inside drum. Put some clean rags into the drum. Plug the power, press 【 】... -
Page 16: Control Panel
OPERATION Control Panel Display On/Off Product is switched on or off. The display shows the setting, estimated program time remaining and status messages Start/Pause of your dryer. Press the button to start or pause the Programmes drying cycle. Different drying cycles can be selected according to the users need and the type of Option laundry to be dried. - Page 17 OPERATION The reference weight of dry clothes (weight per item) Sweater Jacket Jeans Bath Towel (mixed 800g) cotton 800g ) (800g) cotton 900g ) Shirt Single bedsheet Work clothes Pyjamas cotton 300g ) cotton 600g ) ( 1120g) ( 200g) Socks T-Shirt Underwear...
- Page 18 OPERATION Option STEAM By pressing the【STEAM】button, you can switch the steam On or Off. 1.【STEAM】is optional for the following program：【COTTON】,【BABY CARE】, 【SHIRTS】and【MIX】. 2. When dry level 【 】 is selected, steam can not be selected and vice INTENSITY versa. LUXE CARE LUXE CARE The LUXE CARE function can reduce or eliminate wrinkles in clothes by using steam, to make clothes more smooth and comfortable.
- Page 19 OPERATION SILENCE SILENCE DRY By pressing the 【SILENCE DRY】button, you can switch the silence dr y On or Off. When the silence dry programme starts, the whole machine sounds quieter. ANTI CREASE ANTI CREASE At the end of the drying cycle, the anti-crease time is 30 minutes (default) or 120 minutes (selected).
- Page 20 OPERATION WIRELESS NETWORK 】 for 3 seconds to configure the network or reset Press【DELAY/ the network. REMOTE This is the switch of remote control, if you want to use your smartphone to control the machine remotely, you need to hold 【REMOTE】for 3 seconds.
-
Page 21: Display
OPERATION Display Child lock Wireless Network Anti crease Delay Steam water tank empty, please fill it. Steam Remote Control Remaining Time indicator/Error message The wool drying cycle of this machine has been tested and approved by The Woolmark Company. The cycle is suitable to dry wool garments which are labelled “hand wash”... -
Page 22: Programmes
OPERATION Programmes Programme selector 1.When the LED display screen brightens up, rotate the programme knob to select the desired programme. 2.Select the【STEAM】, 【TIME+】, 【INTENSITY】, 【UV】, 【LUXE CARE】or 【SILENCE DRY】functions for additional options. 】button. 3.Press the【 】button after the programme has completed. 4.Press the【... -
Page 23: Instructions To Connection With The Tsmartlife App
OPERATION Instructions to Connection with the TSmartLife App Before you start, make sure that: 1. Your smartphone is connected to home wireless network , and you know the network password. 2. Make sure you are near the home appliance. 3. The 2.4GHz band wireless signal is enabled on your wireless router. Follow the below steps to enter the remote control state Download the TSmartLife App On an app market (Google Play Store, Apple App Store), search for... - Page 24 OPERATION 4:If a message of "Smart devices discovered nearby" appears, click to add. 5:If no message appears, select " + " on the page and select your device in the list of nearby devices available. If your device is not listed, please add your device manually by the device category and device model.
- Page 25 OPERATION Wireless Network Status Light Slowly flashing Waiting for connection Connecting Quickly flashing Quickly flashing solid Connected to your wireless router Notes Make sure your devices are powered on. Keep your mobile phone close enough to your device when you are connecting network to your device.
-
Page 26: Drying Programmes Table
OPERATION Drying Programmes Table (* Programmes can be set in App ) Programme Application/Properties Load 8.0kg Cotton For single or multi-layer cotton laundry . Baby Care 1.0kg To dry small amount of baby clothing 3.5kg Bed Linen To dry bed linen, bed sheets or other large items. easy care laundry, such as shirts and blouses equipped with anti-crease function to 1.0kg Shirts... - Page 27 OPERATION Programme Delay Steam Luxe Care Silence Dry Intensity Time+ Anti crease Cotton Baby Care Bed Linen Shirts Wool Time Dry Hygiene Quick Dry Quick-dry Clothing* Yoga Clothing* Outdoor* Jeans* Underwear* Chiffon * Warm* Cool* Cotton Baby Care Bed Linen Shirts Luxe Wool...
-
Page 28: Steam Function
OPERATION Steam Function Only use purified water for【Steam】function. If the 【 】icon is blinking, please open the water inlet cap at the left of the door filter and add the purified water until the indicator disappears. Then close the inlet cap. It is suggested to add about 350ml of purified water. -
Page 29: Maintenance
MAINTENANCE Cleaning and Care Clean the filters This dryer has a primary door lint filter. Make sure you clean the door filter after each cycle to avoid increased energy consumption and cycle time. Note! • To ensure the double-layer filter can be closed smoothly , the arrows at both ends need to be aligned, and the middle slot and the rib need to be aligned. - Page 30 MAINTENANCE Clean Tumble dryer Warning! • Disconnect the power cord before cleaning! • Clean the dryer with a wet cloth which is only damped by clean water. • Do not use solvents, abrasive cleaners, glass cleaners or all-purpose cleaners. These could damage plastic surfaces and other parts. •...
-
Page 31: Trouble Shooting
MAINTENANCE Trouble Shooting If you encounter an issue with the dryer, first check the table below and try to solve the issue before calling the service. Problem Solution • Check if the power supply works. • Display is not on •... - Page 32 MAINTENANCE Display Reason Solutions Water pump failure or water “ ” level sensor failure “ ” Humidity sensor error Please contact your local service center if the Temperature sensor error “ ” problem occurs. “ ” BLDC motor communication error “...
-
Page 33: Technical Specifications
MAINTENANCE Technical Specifications Model TD-T37BS90HWM Parameter Dimension(W*D*H) 595*595*850(mm) +2° ~ +35°C Ambient temperature Rated input power 1600W Rated voltage 220-240V~ Rated frequency 50Hz Refrigerant R134a Weight of product 49kg Rated capacity 8.0kg 1430 Tonne(s) of CO 0.372t Equivalent Quantity of refrigerant 260g Contains fluorinated greenhouse gases covered by the Kyoto Protocol.
