- Page 1 Salzburg Flaker "Pfiffikorn“ Operating instructions Operating instructions and safety instructions before the first Please read the device commissioning instructions carefully!
-
Page 2: Table Of Contents
Contents: "Pfiffikorn" - a smart idea ................4 Operating elements ..................5 Operating elements ..................5 Suitable location ....................7 Commissioning ....................7 Attaching and removing the cranks ............7 Flake Feed ......................10 Suitable seeds ....................10 Setting the flake fineness ................11 Care and cleaning ................... - Page 3 We are delighted that you have chosen our new "Pfiffikorn" flaker and hope you enjoy using it. "Pfiffikorn" is the latest innovation in the world of cereal flakers. With its well-thought-out design and practical handling, this smart appliance makes it possible to produce fresh flakes in any kitchen -...
-
Page 4: Pfiffikorn" - A Smart Idea
That you can do it yourself and would like to be independent of electricity. Using "Pfiffikorn" is as easy as riding a bike with training wheels and in fact has a lot in common with this childhood experience. -
Page 5: Operating Elements
Operating elements Removable funnel Gear wheels with cover Stainless steel rollers Scraper plate Extension arm (left and right) Container made of wood Hand crank (left and right) Cleaning brush... - Page 6 Operating elements Swivel extension arm to the stop There is a recessed grip on the inside edge of the underside of each bracket for easy swinging out Magnets prevent the container from falling out of the appliance unintentionally and center the flake drawer correctly Wing nuts for adjusting the fineness...
-
Page 7: Suitable Location
Swivel the outriggers as far as they will go. Now place your "Pfiffikorn" on the desired work surface and attach the cranks as described below. Attaching and removing the cranks The two cranks can be fitted and removed without tools. - Page 8 Lifting the funnel Place the Flaker on a work surface and hold the base plate down. Open both clamping wing nuts. Pull the hopper vertically upwards. The hopper is connected to the base of the flaker by 4 wooden dowels. If a dowel becomes jammed when lifting the hopper, it may break.
- Page 9 Attaching the funnel Place the funnel vertically from top to bottom. Ensure that the wooden dowels are carefully inserted into the holes provided and do not tilt. The gear cover On the one hand, the gear cover is a protective device and at the same time serves to absorb any wear on the gears.
-
Page 10: Gear Drive
Attaching the gear cover The wooden cladding is placed with the cut-out over the gear wheels. The cladding is pressed down slightly. The pin holders are centered with their slanted flanks in the slotted holes. It is important that the cladding lies flat on the uprights and that both pins engage in the slotted holes. -
Page 11: Setting The Flake Fineness
Crushing Process After you have placed the "Pfiffikorn" on a firm, straight plate, attach the two hand cranks. Fill the funnel with suitable crushed material. Move the right-hand crank to the highest position and press it down. This simultaneously raises the left-hand crank, which you press down once the highest position has been reached. -
Page 12: Care And Cleaning
Care and cleaning Cleaning the rollers: To maintain the technical functionality of your flaker, regular cleaning is recommended. Some crushed material sticks to the rollers during the flaking process. It is therefore advisable to clean the rollers from time to time with the brass brush supplied. -
Page 13: Problem Solutions
Problem solutions Pressed material "Tap" the outside of the funnel with the flat of does not fall from your hand and gently shake the flaker. The the hopper to the light knock should cause the grains to fall into rollers the funnel opening. -
Page 14: Guarantee
Guarantee 3-year guarantee on the Salzburg "Pfiffikorn" with gear drive The warranty applies from the date of purchase for all verifiable material and processing defects and is based on our choice of replacement, repair or reimbursement of the purchase price. -
Page 15: Shipping - Packaging
Warranty processing Repairs of material and processing defects within the warranty period are of course carried out completely free of charge. Before you return the device However, we would ask you to send us a short e-mail or call us before you send the device to us. -
Page 16: Safety Regulations
Safety regulations Please read the operating instructions carefully. 2. The appliance may only be used for its intended purpose (pressing flakes). 3. Only ever operate the flaker on a level, stable surface. 4. The appliance may only be operated by children under supervision. -
Page 17: Interesting Facts About Muesli
Interesting facts about Muesli The Swiss doctor and nutrition researcher Maximilian Oskar Bircher-Brenner "invented", so to speak, the original "mush" before 1900, which was later called "Bircher muesli" after him. He didn't actually invent it but took up a well-known dish in the Swiss Alps. - Page 18 Each type of grain has a different content of minerals, trace elements, vitamins, enzymes and unsaturated fatty acids. However, children will love superfood oats the most. What goes into a tasty muesli Seasonal fruits and berries are best. Vegetables such as carrots, zucchinis or pumpkin can also add variety.
- Page 19 The original Bircher-Benner recipe For one portion: Ingredients: • 1 level tablespoon of rolled oats • 3 tablespoons of water • Soak for 12 hours • 1 tablespoon lemon juice • Add 1 tablespoon of sweetened condensed milk and mix to a sauce.
- Page 20 AGRISAN NATURPRODUKTE GMBH Gasteigweg 25 A 5400 Hallein, Austria Tel. 0043 (0)6245 83282 E-mail: info@agrisan.at Internet: www.getreidemuehle.com www.natural-grainmills.us www.facebook.com/Getreidemuehlen...
