Tradesman 4 User Manual
Version 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tradesman 4 and is the answer not in the manual?

Questions and answers

Related Manuals for jcb Tradesman 4

Summary of Contents for jcb Tradesman 4

  • Page 1 Tradesman 4 User Manual Version 1.0...

  • Page 2: Table Of Contents

    Contents 1. Safety Precautions 2. Introduction 3. Getting Started 3.1 Inserting the SIM and SD Cards 3.2 Battery & Charging 3.3 Turning on the Phone 3.4 Using the Physical Keyboard 4. Phone Setup 4.1 Choosing a Language 4.2 Setting the Ringtone 4.3 Changing the Wallpaper 4.4 Restoring Factory Settings 5.

  • Page 3: Safety Precautions

     2.0 Introduction Introducing your new JCB Tradesman 4 rugged feature phone. The JCB Tradesman 4 is built to handle the rigours of a hard-working day and then to accompany you at play. Built to the toughest specifications and supplied with a long-lasting battery the JCB Tradesman 4 will not let you down.

  • Page 4: Getting Started

    3.0 Getting Started 3.1 Inserting the SIM and SD Cards The JCB Tradesman 4 supports: Dual Nano SIM cards (4FF size) x 2  Micro SD card (up to 128GB)  Steps to Insert SIM and SD Cards: 1. Power o@ the phone before inserting/removing SIM or SD cards.

  • Page 5: Battery & Charging

    3.2 Battery & Charging Battery Type: 1800mAh Li-Ion battery.  Charging Port: USB Type-C (2.0).  Charging Instructions: 1. Use the supplied USB Type-C charger to avoid damage. 2. Connect the charger to the USB Type-C port behind the protective cover. 3.

  • Page 6: Turning On The Phone

    3.3 Turning on the phone 1. Press and hold the red power key for five seconds until the JCB logo appears. 2. You will hear the JCB tractor engine tone during startup. To disable this enter Main menu > Apps > Profiles, then select Options and then Settings > Other alert rings and Power ringtone choose between Active and O<.

  • Page 7: Phone Setup

    4.0 Phone Setup 4.1 Choosing a Language 1. Go to Settings > Phone Settings > Language Settings. 2. Choose your preferred language from the list. Display language: Auto, English, Francais, Magyar, Portugues, Espanol, Italiano, Deutsch, Cestina, Romana, Dansk, Nederlands, Suomi, Slovencina and Svenska. Writing language: English, Francais, Magyar, Portugues, Espanol, Italiano, Deutsch, Cestina, Romana, Dansk, Nederlands, Suomi, Slovencina and Svenska.

  • Page 8: Setting The Ringtone

    4.2 Setting the Ringtone 1. Open Main menu > Apps > Profiles. 2. Select your preferred profile (Normal, Silent, Meeting, etc.). 3. Choose SIM 1 or SIM 2 ringtone and select from default tones or saved audio files. Tip: You can download your own audio file that you can then select as the ringtone for the phone.

  • Page 9: Changing The Wallpaper

    4.3 Changing the Wallpaper 1. Navigate to Main menu > Settings > Display > Wallpaper Settings. 2. Choose from preloaded wallpapers or select an image from the SD card. Your phone has 12 pre-installed wallpapers. To select one of these, select static wallpaper and the scroll to your preferred option.

  • Page 10: Restoring Factory Settings

    4.4 Restoring Factory Settings 1. Go to Settings > Phone Settings > Restore Factory Settings. 2. Confirm your selection (Default password: 1234). 3. Warning: This will erase all user data on the phone. Restore factory 5.0 General Usage 5.1 Making Calls & Managing Contacts Dial a number manually or select a contact.

  • Page 11: Sending Text Messages

    Enter the number or select the contact and then press the send key When in a call use the left and right sides of the navigation pad to adjust the volume. When calling a contact press the top right key beneath the Display, you can select Contacts which will give access to all contacts, alternatively you can access via the Main menu and scrolling to Contacts in this menu.

  • Page 12: Adding Contacts

    5.3 Adding Contacts 1. Open the Main menu > Contacts > Options. 2. Select New and then choose the location to save the contact. 3. Enter the details as per image below. 6.0 Applications & Features Bluetooth: Connect to speakers, headsets, or other phones within range of the ...

  • Page 13: Managing Files & Storage

    3. Calculator: Perform basic and advanced calculations. 4. FM Radio: Requires a wired headset to act as an antenna. 5. Sound Recorder: Record voice notes. 6. Profiles: as discussed earlier in the manual allowing alternative ringtones other than the default. 7.0 Managing Files &...

  • Page 14: Key Specifications

    8.0 Key Specifications Screen Size 2.4 inch Rear camera 64MB 128MB External memory Up to 128GB Battery size 1800mAh B1,2,3,5,7,8,20,28a/b VoLTE VoWiFi IP rating IP69 Drop test 1.8M onto concrete MIL Spec 810H Dimensions 147 x 63 x 18mm Weight 162g Other Dedicated torch...

  • Page 15: Troubleshooting & Faqs

    9.0 Troubleshooting & FAQs Phone not turning on  Hold down the Power Key for 5 seconds. If the phone does not power on then try charging the phone according to the charging instructions in this user manual. If the phone will not charge with the original cable the phone was delivered with, then please try with an alternative cable if still not functioning try a di@erent charger.

  • Page 16: Warranty & Support

    10.0 Warranty & Support For warranty details and support, visit www.jcbphone.com or email support@jcbphone.com. 11.0 Notice Some features of the product and its accessories described here rely on the software installed, capacities and settings of local network, and may not be activated or may be limited by local network operators or service providers.
