- Page 1 Third Brake Light DUAL Antenna Mount 90201160 - Third Brake Light DUAL Antenna Mount 90201160 Fits the 2015-2025 Ford F-150 · 2017-2025 Raptor · 2017-2025 Super Duty ·2019-2025 Ranger and the 2022-2025 Maverick Installation Manual...
-
Page 2: Warranty
Introduction Thank you for your purchase of our vehicle specific Third Brake Light DUAL Antenna Mount! We hope that you find the installation simple and straightfor- ward. As our customer, your satisfaction is important to us, and for that reason we take pride in all of the products that we design and manufacture to ensure a reliable solution for years to come! Pre-caution... - Page 3 Parts List - 90201160 Description Qty. 2015+ F150 DUAL ANTENNA MOUNT ASSEMBLY #10-24 X 1” SOCKET HEAD CAP SCREW, 18-8 SS #10-24 X 1” BUTTON HEAD CAP SCREW, 18-8 SS #10-24 X 1-1/4” BUTTON HEAD CAP SCREW, 18-8 SS 480.247.2331 888.967.6653 bulletproofdiesel.com...
-
Page 4: Installation Steps
Installation Steps: Step. 1 Make sure you have all the required tools you will need for installation. TIP: Refer to page one (1) for tool list. Step. 2 Remove the four (4) screws holding the light housing in place using the TORX driver and pull away from the cab. - Page 5 Label each cable prior to feeding into the cab so you know which cable goes to which antenna. Step. 8 Feed the antenna cables into the cab to your desired location. Step. 9 Reconnect the light housing in the reverse steps of the removal. 480.247.2331 888.967.6653 bulletproofdiesel.com...
- Page 6 Step. 10 Re-install the light housing using the two (2) longer button head screws provided in the middle holes and the two (2) shorter button head screws in the outer holes. Once properly aligned, tighten all the screws. TIP: DO NOT OVERTIGHTEN Lastly - Attach desired NMO standard threaded antenna connectors and fasten the PL-259 male UHF connector to your compatible receiver.
- Page 7 Accessories NMO to 3/8" NMO Rain Cap Billet NMO Rain 24 Adapter Plastic Cap - Round BPD P/N 6000215 BPD P/N 6000214 BPD P/N 90201260 Ford Truck Antenna Mount Cover Plate 2015 - 2025 BPD P/N 6000295 480.247.2331 888.967.6653 bulletproofdiesel.com...
- Page 8 480.247.2331 888.967.6653 bulletproofdiesel.com 480.247.2331 888.687.6653 BULLETPROOFDIESEL.COM 888.967.6653 bulletproofdiesel.com...
