PowerBase LW C02A Instruction Manual

20v cordless pressure washer

Hide thumbs

Table Of Contents

Quick Links

Download this manual

20V Cordless

Pressure Washer 660841

These instructions contain important information that will help you get the best

from your product, ensuring it is assembled correctly and safely. If you need help

or have damaged or missing parts, call the Customer Helpline on 01904 727 509.

53cm Self Propelled Petrol

Rotary Lawn Mower

Instruction

Manual

IMPORTANT!

Please read these

instructions fully before

starting assembly.

Table of Contents

Need help?

Do you have a question about the LW C02A and is the answer not in the manual?

Questions and answers

Summary of Contents for PowerBase LW C02A

Page 1 Instruction Manual 53cm Self Propelled Petrol Rotary Lawn Mower IMPORTANT! 20V Cordless Please read these Pressure Washer 660841 instructions fully before starting assembly. These instructions contain important information that will help you get the best from your product, ensuring it is assembled correctly and safely. If you need help or have damaged or missing parts, call the Customer Helpline on 01904 727 509.
Page 2: Table Of Contents
Contents General Safety Warnings Intended Use Safety Information In the Box Assembly Operation Application Maintenance Troubleshooting Technical Data Disposal Getting Help Warranty...
Page 3: General Safety Warnings
General Safety Warnings Safety warnings WARNING! Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. WARNING! Read all safety warnings and instructions designated by symbol. Save all warnings and instructions for future reference.
Page 4 Additional product safety warnings WARNING! The liquid must not be directed towards equipment containing electrical components. Remove or disconnect the battery pack after use and before carrying out user maintenance on the power tool. The power tool should not be left unattended while it is connected to the battery pack.
Page 5 WARNING! Children should be supervised to ensure that they do not play with the power tool. • Before charging the battery, read all the instructions carefully. • After charging, disconnect the battery charger from the mains supply; remove the chassis connection and then the battery connection.
Page 6 • Keep the battery charger’s slots free of foreign objects and protect it from dirt and humidity. Store in a dry and frost- free place. • When charging batteries, ensure that the battery charger is in a well-ventilated area and away from flammable materials.
Page 7 by conductive materials. When the battery pack is not in use, keep it away from other metal objects like paper clips, coins, keys, nails, screws or other small metal objects that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.
Page 8: Intended Use
normal room temperature (20°C ± 5°C). • When discharging several battery packs, keep battery packs of different electrochemical systems separate from each other. • Do not use any battery pack which is not designed for use with the equipment. • Keep the battery pack out of the reach of children.
Page 9: Safety Information
Safety Information Please read these instructions fully before operating or maintaining your power tool. Description of symbols The following warning symbols appear throughout this manual and indicate the appropriate safety measures you should take when operating and maintaining the electric cordless pressure washer. Caution/Warning.
Page 10 Warning symbols on the charger Read instruction handbook before operating this machine. The charger is for indoor use only. Class II equipment Pole orientation T/3.15A Fuse T/3.15A WEEE symbol. Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
Page 11: In The Box
In the Box Parts 1. 5-in-1 lance 2. H/L/Pressure Switch Button 3. Safety Lock Button 4. Battery Pack 5. ON/OFF Switch Trigger 6. Handle Rotary Lock Button a. 5-in-1 lance Foam sprayer b. Pressure washer g. Net bag c. Hose h.
Page 12: Assembly
Assembly Install the 5-in-1 lance Align the lance to the main housing and push down firmly, then rotate the lance to secure in place. NOTE: Make sure that the lance button is positioned on the top side. Choose your water source Using the pressure washer with your garden hose pipe: Attach the hose pipe to the pressure washer connector and make sure that it is locked into position.
Page 13 Check the connection by gently pulling upon the hose, make sure the hose is locked into position. Water that has passed through a backflow preventer is classified as undrinkable. NOTE: A backflow preventer is available from specialist retailers. NOTE: Water pressure from the tap should not be higher than 0.6Mpa.
Page 14: Operation
Operation Charging the battery WARNING! The charger and battery pack are specifically designed to work together, so do not attempt to use any other devices. Never insert or allow metallic objects into your charger or battery pack connections; an electrical failure and hazard will occur.
Page 15 Important charging notes Never allow the battery to completely discharge before recharging. The battery pack should be placed on the charger whenever the battery pack is noticeably running down or the tool no longer performs a task it previously performed. 2.
Page 16 Removing or installing the battery pack WARNING: Always release the on/off trigger before insertion or removal of the battery pack. To remove the battery pack: Depress button (A) on the end of the battery pack, and then remove the pack from the tool. USB-A port Install the battery pack: Align the ribs on both sides of the battery pack with the slots in the housing, and slip it into place.
Page 17 Switching off: Release the switch trigger. 0° 25° 40° 40°...
Page 18: Application
Application Adjusting rotary handle Press and hold down the rotary handle button. 2. Adjust the handle to your preferred working position and then release the button. 0° 25° 40° 40° 5-in-1 nozzle Whilst holding the lance, rotate the nozzle to your selected position, making sure that the nozzle is aligned with the lance arrow.
Page 19 40° 40° 0° 25° Using the brush Remove the lance and nozzle. 40° 40° Align the brush to the main housing, push down firmly and rotate to secure in place. When using the brush it is advised to use the H/L setting to save water.
Page 20 Working with the pressure washer WARNING! Risk of fatal injury! Use special care when cleaning tyres. Vehicle tyres/tyre valves may become damaged or burst when handled improperly. First signs of damage include discoloration on the tyre. Damaged vehicle tyres/tyre valves pose a life-threatening risk.
Page 21: Maintenance
Maintenance WARNING! Before performing any repair work, always ensure that the battery pack has been removed. Overview of cleaning Clean the power tool. Wipe the unit with a slightly damp cloth. Do not clean the appliance using a high-pressure water jet. 2.
Page 22 Hose filter cleaning section The pressure washer is equipped with a water filter to protect the pump. If the filter is not kept clean, the water flow to the power tool will be restricted and the pump may be damaged. Disassemble the filter from the hose.
Page 23: Troubleshooting
Troubleshooting Suspected malfunctions are often due to causes that the user can fix themselves. Therefore, check the product using this section. In most cases, the problem can be solved quickly. WARNING! Only perform the steps described within these instructions! All further inspection, maintenance and repair work must be performed by an authorised service centre or a similarly qualified specialist if you cannot solve the problem yourself!
Page 24 • The nozzle is • Re-align the nozzle not aligned with correctly with the lance lance correctly • Replace the accessory • O-ring split/broken. or change the O-ring Attachments are not • Remove & re-install the installed correctly attachment correctly •...
Page 25: Technical Data
Technical Data Model No. LW C02A Voltage Max. Max. water inlet pressure 6 Bar Working pressure Low: 13 Bar High: 22 Bar Working flow rate 370 L/h Weight 1.9kg Charger Model no. B0Q-SP06-20ZB Input voltage & power 220-240V AC, 50/60Hz 65W Output voltage &...
Page 26 Technical Data Noise emission value: Noise measurement value determined in accordance with EN 62841. The A-rated noise level of the power tool is typically as follows: Sound pressure level L : 75.7dB(A) Uncertainty k=3dB(A) Sound power level L : 86.7dB(A) Uncertainty k=3dB(A) Guaranteed sound power level L : 94dB(A)
Page 27: Disposal
Disposal The pressure washer and its accessories are made of various recyclable materials. Dispose of the pressure washer in accordance with your local recycling regulations. Getting help Our dedicated UK-based customer helpline is open 7 days a week to assist you with assembly, parts queries and technical support. We are open during office hours but you can always send an email via support@coreservice.co.uk.
