Sony ULT FIELD 7 Reference Manual

Home Audio System
Reference Guide
Guía de referencia
ULT FIELD 7
©2024 Sony Corporation
Printed in China
https://www.sony.net/
English Home Audio System
Model: YY7858E
The term "product" in this document refers to the unit or its accessories.
Do not install the product in a confined space, such as a bookcase or built-in cabinet.
Install the unit so that the power cord can be unplugged from the wall socket immediately in the event
of trouble.
The unit is not disconnected from the AC power source (mains) as long as it is connected to the wall
outlet, even if the unit itself has been turned off.
Do not expose the batteries (battery pack or batteries installed) to excessive heat, such as sunshine, fire
or the like, for a long time.
Do not subject the batteries to extreme low temperature conditions that may result in overheating and
thermal runaway.
Do not dismantle, open, or shred secondary batteries.
In the event of a secondary battery leaking, do not allow the liquid to come in contact with the skin
or eyes. If contact has been made, wash the affected area with copious amounts of water and seek
medical advice.
Secondary batteries need to be charged before use. Always refer to the manufacturer's instructions or
product manual for proper charging instructions.
After extended periods of storage, it may be necessary to charge and discharge the secondary batteries
several times to obtain maximum performance.
Dispose of properly.
Do not expose the unit to naked flame sources (for example, lighted candles).
This product has magnet(s) which may interfere with pacemakers, programmable shunt valves for
hydrocephalus treatment, or other medical devices. Do not place this product close to persons who use
such medical devices. Consult your doctor before using this product if you use any such medical device.
Inserting the USB plug or AC plug while it is wet may cause a short circuit due to foreign matter or liquid
(tap water, seawater, soft drinks, etc.) getting on the main unit or charging cable.
This may cause malfunctions or abnormal overheating.
Never insert the USB plug or AC plug while the main unit or charging cable is wet.
Licenses
• This product contains software that Sony uses under a licensing agreement with the owner of
its copyright. We are obligated to announce the contents of the agreement to customers under
requirement by the owner of copyright for the software. Please access the following URL and
read the contents of the license.
https://rd1.sony.net/help/speaker/sl/24/
• This product is protected by certain intellectual property rights of Microsoft Corporation. Use
or distribution of such technology outside of this product is prohibited without a license from
Microsoft or an authorized Microsoft subsidiary.
• Services offered by third parties may be changed, suspended, or terminated without prior notice.
Sony does not bear any responsibility in these sorts of situations.
Notes on waterproof and dustproof features
(Read before using the unit)
The supplied accessories are neither waterproof nor dustproof.
On waterproof and dustproof performance of the unit
The unit, with the cap fastened securely, has a waterproof specification of IPX7 as specified in "Degree
of protection against water immersion" of the IEC60529 "Ingress Protection Rating (IP Code)", and a
dustproof specification of IP6X as specified in "Degrees of protection against solid foreign objects".
• The supplied accessories and the connectors of this unit (AC IN, USB, AUDIO IN, MIC) are neither
waterproof nor dustproof. To reduce the risk of fires or electric shocks, do not expose the unit to water
or droplets while using any connectors (AC IN, USB, AUDIO IN, MIC) .
Note that malfunctions as a result of water immersion or dust intrusion caused by misuse by the
customer are not covered by the warranty.
To maintain waterproof and dustproof performance
Carefully note the precautions below to ensure proper use of the unit.
• Do not pour high-temperature water or blow hot air from a hair dryer or any other appliance on the
unit directly. Also never use the unit in a place subject to high temperatures, such as in a sauna or
near a heat source.
CAUTION : Handle the cap with care. The cap plays a very important role in maintenance of the
waterproof and dustproof performance. When using the unit, make sure that the cap is closed
completely. When closing the cap, be careful not to allow foreign objects inside. If the cap is not closed
completely the waterproof and dustproof performance may deteriorate and may cause a malfunction of
the unit as a result of water or dust particles entering the unit.
Passive
radiator
Precautions
On the power cord
• The supplied AC power cord (mains lead) is designed exclusively for this unit. It should not be used in
combination with any other devices.
• Completely disconnect the AC power cord (mains lead) from the AC outlet (mains) if it is not going to
be used for an extended period of time. When unplugging the AC power cord (mains lead), always
grip the plug. Never pull the cord itself.
• AC power cord (mains lead) must be changed only at a qualified service shop.
On placement
• To eliminate the risk of malfunctions, avoid the following locations when placing or leaving this unit.
– A place subject to high temperatures, such as under direct sunlight or lighting equipment, near a
heat source, or in a sauna
– Inside a vehicle with the windows closed (especially in summertime)
– A place exposed to hot air, such as from a hair dryer
• Place this unit on a flat, level surface. When placed on a sloped surface, the unit may fall over or
fall off the surface due to its own vibration, resulting in injuries, malfunctions, or performance
degradation.
• This unit is not anti-magnetic. Keep objects susceptible to magnetism (recorded tapes, watches, cash
cards and credit cards with magnetic coding, etc.) away from the unit. When you carry around the
unit, keep this in mind as well.
5-056-531-92(1)
Model, Modelo: YY7858E
https://rd1.sony.net/
help/speaker/7858/h_zz/
Cap
How to care for the unit
Although the fabric part of the unit has water repellent treatment applied, you can use the unit more
comfortably and for a longer period of time by following the maintenance procedure below.
• If the surface of the unit gets dirty in the following cases, wash the unit with fresh water (tap water,
etc.) promptly to remove the dirt. Leaving dirt on its surface may cause the fabric part or the passive
radiator section to discolor or deteriorate, or the unit to malfunction.
Ex.
– When the unit has sand, salt (chlorine), or other residue on it after having been used in a mountain
area, by a swimming pool, etc.
– When the unit is stained with foreign substances (sunscreen, suntan oil, etc.)
Note
• If the surface of the unit gets dirty, do not use detergent, thinner, benzine, alcohol, etc. to clean the
unit because it will affect the water repellent function of the fabric part of the unit.
• If sand grains, etc. enter the fabric or other part of the unit, remove them carefully. Never use a
vacuum cleaner, etc. on the unit. It may cause damage of the speaker section or other part of the unit.
Other notes
• Do not use or leave the unit in an extremely cold or hot environment (temperature outside the range
of 5 °C – 35 °C). If the unit is used or left in outside the above range, the unit may automatically stop to
protect internal circuitry.
• Even if you do not intend to use the unit for a long time, charge the battery to its full capacity once
every 6 months to maintain its performance.
• If your skin remains in contact with the handle for a long time while the light is turned on, there is
a risk of low-temperature burns. To carry a speaker while it is powered on, turn the light (lighting
function) off.
• If you have any questions or problems concerning this unit that are not covered in this manual, please
consult your nearest Sony dealer.
Trademarks
• Microsoft and Windows are registered trademarks or trademarks of Microsoft Corporation in the
United States and/or other countries.
• The BLUETOOTH® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and
any use of such marks by Sony Group Corporation and its subsidiaries is under license.
• LDAC and LDAC logo are trademarks of Sony Group Corporation or its affiliates.
All other trademarks and registered trademarks are trademarks or registered trademarks of their
respective holders. In this manual, ™ and ® marks are not specified.
Specifications
BLUETOOTH®
Frequency band
2.4 GHz band (2.400 0 GHz - 2.483 5 GHz)
General
Inputs
• Type A USB port: Supported USB Device (Mass Storage Class)
• AUDIO IN jack (Φ 3.5 mm)
• MIC/GUITAR jack (Φ 6.3 mm)
DC OUT
Type A USB port (for charging the battery of a connected device) (DC 5 V/MAX. 1.5 A)
Power
AC 120 V - 240 V, 50/60 Hz or, using built-in lithium-ion battery
Power consumption
Approx. 45 W
Standby power consumption
When BLUETOOTH standby mode is set to on: 2 W or less
When BLUETOOTH standby mode is set to off: 0.5 W or less
Lithium-ion battery life (while Battery Care mode*
With playback via a BLUETOOTH connection
Approx. 30 hours* 2
– Volume level: 16
– Sound: ULT1/2 on
– Lighting: off
Approx. 25 hours* 2
– Volume level: 16
– Sound: ULT1/2 on
– Lighting: on
Approx. 3 hours* 2
– Volume level: 50 (MAX.)
– Sound: ULT1/2 on
– Lighting: on
Time required for charging the built-in rechargeable battery (while Battery Care mode*
Approx. 5 hours* 3
– 10 minutes of charging provide approximately 3 hours*
(Volume level: 16 / Sound: ULT1/2 on / Lighting: off)
Operating temperatures
5 °C – 35 °C
Dimensions (including projecting parts and controls)
Approx. 512 mm × 224 mm × 222 mm (w/h/d)
Mass (including battery)
Approx. 6.3 kg
Included items
Home Audio System (1)
AC power cord (mains lead) (1)
AC plug adaptor (1)* 4
Documents (1 set)
1
* Mode for prolonging the durability life of the built-in rechargeable battery by limiting the charging
capacity up to approximately 90%. The unit in this mode is capable of playing for a shorter period of
time than stated.
* 2 The built-in battery life above is measured using our specified music source. Actual performance time
may vary from the listed time due to the volume, songs played, surrounding temperature, and usage
conditions.
* 3 Time required for the empty battery to be fully charged (100%) while the unit is powered off.
* 4 This plug adaptor is not for the use in Chile and Paraguay. Use this plug adaptor in the countries/
regions where it is necessary.
Design and specifications are subject to change without notice.
Español Reproductor de audio
Modelo: YY7858E
El término "producto" en este documento se refiere a la unidad o sus
accesorios.
POR FAVOR LEA DETALLADAMENTE ESTE MANUAL DE INSTRUCCIONES
ANTES DE CONECTAR Y OPERAR ESTE EQUIPO.
RECUERDE QUE UN MAL USO DE SU APARATO PODRÍA ANULAR LA
GARANTÍA.
No instale el producto en un espacio reducido, como una estantería o un
armario empotrado.
Instale la unidad de manera que el cable de alimentación pueda
desenchufarse de la toma de corriente de la pared rápidamente si se
produce algún problema.
La unidad no se desconecta de la fuente de alimentación de ca (red
eléctrica) siempre que esté conectada a la toma de pared, aunque se haya
apagado la propia unidad.
No exponga las baterías (paquete de baterías o baterías instaladas) a un
calor excesivo, como la luz del sol, el fuego o similares durante un periodo
prolongado.
No someta las baterías a condiciones de temperatura extremadamente
bajas, ya que podría producirse sobrecalentamiento y fuga térmica.
No desmonte, abra ni corte las baterías secundarias.
En caso de fuga de una batería secundaria, no deje que el líquido entre en
contacto con la piel o los ojos. Si se ha producido contacto, lave la zona
afectada con abundante agua y busque asistencia médica.
Hay que cargar las baterías secundarias antes de utilizarlas. Consulte
siempre las instrucciones del fabricante o el manual del producto para
conocer las instrucciones de carga adecuadas.
Después de periodos prolongados de almacenamiento, es posible que
se deba cargar y descargar las baterías secundarias varias veces a fin de
alcanzar su rendimiento máximo.
Deséchelas correctamente.
No exponga la unidad a fuentes de llama viva (por ejemplo, velas
encendidas).
AVISO IMPORTANTE PARA MÉXICO
La operación de este equipo está sujeta a las siguientes dos condiciones:
(1) es posible que este equipo o dispositivo no cause interferencia
perjudicial y (2) este equipo o dispositivo debe aceptar cualquier
interferencia, incluyendo la que pueda causar su operación no deseada.
Para consultar la información relacionada al número del certificado, refiérase
a la etiqueta del empaque y/o del producto.
Nota
Información de dispositivo(s) para funcionalidades inalámbricas:
Modelo: BMS002
Marca: Sunitec
Este producto contiene un imán (o imanes) que puede interferir con
marcapasos, válvulas de derivación programables para tratamientos para
la hidrocefalia u otros productos sanitarios. No coloque el dispositivo cerca
de personas que usen tales dispositivos médicos. Consulte con su médico
antes de usar este producto si usa un dispositivo médico tal.
1 is not activated)
1 is not activated)
2
of music playback.
