- Page 1 Video Wall Controller/ Board Enclosure Quick Guide V1.02...
-
Page 2: Packing List
Packing List Contact your local dealer if the package is damaged or incomplete. The package contents may vary with device model. Table 1-1 Video Wall Controller Packing List Name Unit Host Power module (including power cable) Grounding cable Serial cable Mounting bracket Pair Screw components... -
Page 3: Front View
panels to illustrate the slot types. 2.1.1 Front View Please insert the corresponding board according to the color mark on the side of the board slot. Cascade Board Slot Switch Board Slot Control Board Slot NOTE! If only one control board is used, please insert it into M1 slot (numbered 1 in the ... - Page 4 Module Name Description Running indicator: Blinking: The board is starting up. RUN indicator Steady on: The board runs normally. Off: The board is powered off. Alarm indicator: Steady on: The board is faulty. ALM indicator Off: The board runs normally. ...
-
Page 5: Switch Board
Module Name Description Grounding Connects a grounding cable. Screw 2.2.2 Switch Board Figure 2-1 Switch Board of Controller Figure 2-2 Switch Board of Board Enclosure Connect to the cascade interface on the cascade board. Name Description SLOT1~10: Indicates the operation status of service boards in the slots. -
Page 6: Check Before Installation
2.2.3 Cascade Board NOTE! Cascade boards are only required when connecting board enclosures. The cascade boards are used for connecting board enclosures, and support connecting 5 board enclosures. Cascade Interface 2.2.4 Service Board This device provides ten slots for different service boards, you can freely match boards according to application scenarios. - Page 7 3.2 Place the Device 3.2.1 Place the Device into a Cabinet Plan the space in the cabinet based on the device height (3U). If the cabinet is equipped with a tray, preferentially use the tray. Otherwise, purchase a bracket slide rail from our company.
- Page 8 service boards as an example for illustration. Remove the filler panel Use a Phillips screwdriver to loosen the screws on the filler panel, and remove the panel. Install service boards Align the board with the slot, and push the board in gently to keep both sides parallel.
- Page 9 Press the latch, and remove the filler panel/power module. Align the power module with the slot, and press the latch to push the power module inward gently until it is firmly locked. 3.5 (Optional) Install the Cable Management Bracket You can use a cable management bracket (sold separately) to keep cables organized. Use a Phillips screwdriver to fix the four screws attached to the cable management bracket to the positions shown in the figure below on both sides of the chassis.
-
Page 10: Connect The Grounding Cable
Fix the cable management bracket onto the screws on both sides of the chassis. 3.6 Connect Cables 3.6.1 Connect the Grounding Cable Connect one end of the grounding cable to the grounding screw of your device and the other end to a reliable grounding position. 3.6.2 Connect the Mini-SAS HD Cable Connect the cascade board and the switch board of the board enclosure via four Mini- SAS HD cables as shown in the figure below. -
Page 11: Web Login
Startup CAUTION! Before connecting the power supply, ensure that the device is properly grounded: it is recommended to use a single-phase three-wire power socket with a neutral point, and the neutral point must be reliably grounded in the building. The full load power of the device is less than 350 W. -
Page 12: Maintenance Precautions
operations. The default network settings are shown in the table below and may be modified as required. Item Defaults IP address/subnet mask: 192.168.1.14/255.255.255.0 Network address Gateway: 192.168.1.1 Username admin 123456 Note: The default password is intended only for your first login. To Password ensure security, please change the password after your first login. - Page 13 The product described in this manual may contain proprietary software owned by Uniview and its possible licensors. Unless permitted by Uniview and its licensors, no one is allowed to copy, distribute, modify, abstract, decompile, disassemble, decrypt, reverse engineer, rent, transfer, or sublicense the software in any form by any means.
- Page 14 To the extent allowed by applicable law, in no event shall Uniview’s total liability to you for all damages for the product described in this manual (other than as may be required by applicable law in cases involving personal injury) exceed the amount of money that you have paid for the product.
- Page 15 Keep firmware up to date: It is recommended that your device is always upgraded to the latest version for the latest functions and better security. Visit Uniview's official website or contact your local dealer for the latest firmware.
- Page 16 Verify that the device is properly installed before connecting it to power. Do not remove the seal from the device body without consulting Uniview first. Do not attempt to service the product yourself. Contact a trained professional for maintenance.
- Page 17 (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Visit http://en.uniview.com/Support/Download_Center/Product_Installation/Declaration/ for SDoC. Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
