- Page 1 How to Connect a Uniview KB-1100 to an NVR?
-
Page 2: Operating Steps
Title How to Connect a Uniview KB-1100 to an NVR? Version: V1.1 Product Date 9/26/2023 How to Connect a Uniview KB-1100 to an NVR? Description Note: This method is applicable to most of the scenarios. If the method still cannot solve your problem, it is recommended to consult our Tech Support Team. - Page 3 Title How to Connect a Uniview KB-1100 to an NVR? Version: V1.1 Product Date 9/26/2023 Note: Please make sure that the IP address you set up for the keyboard is in the same network segment as that of the NVR. For example, if the IP of NVR is 172.1.90.252, then the keyboard IP can be set to 172.1.90.179.
- Page 4 Title How to Connect a Uniview KB-1100 to an NVR? Version: V1.1 Product Date 9/26/2023 Set ID, name, device type and connection type like below, then press Enter and put in the IP address of NVR. ID: any number which needs to be unique in the same local area network...
- Page 5 Title How to Connect a Uniview KB-1100 to an NVR? Version: V1.1 Product Date 9/26/2023 Name: any one that is unique in the same local area network D_Type: Select NVR. L_Type: Set up to Network, and then put in the IP address of the NVR (Port number is 60000) Press Enter and then ESC to save the configuration.
- Page 6 Title How to Connect a Uniview KB-1100 to an NVR? Version: V1.1 Product Date 9/26/2023 Put in the ID we set up for the NVR in Step 3. Press Enter and then we will be able to control the NVR with the keyboard.
