INSTALLATIONSANLEITUNGEN
Mindestabstand über der Kochfläche: 50 cm bei Elektroplatten, 70 cm bei Gasmulden oder gemischt
betriebenen Kochfeldern.
Schreiben die Installationsanweisungen des Gaskochfelds einen größeren Abstand vor, ist dieser
natürlich zu beachten.
Schließen Sie das Gerät erst nach seiner kompletten Installation an das Stromnetz an.
Aufgrund des schweren Gewichtes sind mindestens zwei oder noch mehr Personen zur Beförderung
und Installation der Abzugshaube erforderlich.
GB
INSTALLATION DATA SHEET
Minimum height above cooker: 50 cm for electric cookers, 70 cm for gas or combined cookers.
If the installation instructions for a gas cooker specify a greater distance, then this distance must be
observed.
Do not connect the hood to the electrical power supply until installation is completed.
Very heavy product; hood handling and installation must be carried out by at least two persons.
F
FICHE D'INSTALLATION
Distance minimale par rapport à la cuisinière : 50 cm minimum dans le cas d'une cuisinière électrique,
70 cm dans le cas d'une cuisinière à gaz ou mixte.
Si les instructions d'installation du dispositif de cuisson à gaz indiquent une distance supérieure, il est
nécessaire de la respecter.
Ne branchez pas l'appareil tant que l'installation n'est pas terminée.
Appareil excessivement lourd ; la manutention et l'installation de la hotte doivent être effectuées par
deux personnes ou plus.
NL
INSTALLATIEKAART
Minimumafstand tot het kooktoestel: 50 cm bij elektrische kooktoestellen, 70 cm bij kooktoestellen
op gas of gemengd.
Als de installatie-instructies van het kooktoestel op gas een grotere afstand aangeven, moet hiermee
rekening gehouden worden.
Geef het apparaat geen stroom totdat de installatie geheel voltooid is.
Aangezien dit apparaat zwaar is, dient het door minstens twee of meer personen verplaatst en
geïnstalleerd te worden.
E
FICHA DE INSTALACIÓN
Distancia mínima desde los quemadores: 50 cm si las cocinas son eléctricas y 70 cm si son a gas o
mixtas.
Si en las instrucciones de instalación de la placa de cocina a gas se especifica una distancia mayor
respecto a la indicada, es necesario tenerlo en cuenta.
No conecte el aparato a la corriente eléctrica hasta que la instalación esté completamente finalizada.
Producto con peso excesivo; la campana extractora ha de ser transportada e instalada por dos o más
personas.
P
FICHA DE INSTALAÇÃO
Distância mínima dos fogões: 50 cm no caso de fogões eléctricos, 70 cm no caso de fogões a gás ou
mistos.
Respeite as instruções de instalação do dispositivo de cozedura a gás se estas especificarem uma
distância superior à indicada.
Não ligue o aparelho à corrente eléctrica enquanto a instalação não estiver concluída.
Produto com peso excessivo. A movimentação e a instalação do exaustor devem ser feitas por pelo
menos duas ou mais pessoas.
5019 318 33241
LI25BA
