GK310
Arranger Keyboards
SERVICE MANUAL
GK330
2nd Edition
CODE: 270239
Index
2
Block Diagram & Wiring Connections, Specifications and Reset Procedure
3
L/R Contact Boards, Keyboard Interface Board and GK330 Controls Panel Board
4
GK310 Cpu & Sound Generator Board and Power Amplifier & Supply Board
5
GK330 Cpu & Sound Generator Board and Power Amplifier & Supply Board
6
Spare Part List
Warnings
Notice
✔
Service must be carried out by qualified personnel only. Any tampering carried out by unqualified personnel during the guarantee period
will forfeit the right to guarantee.
✔
For a correct operation of the instrument, after having switched off, be careful to wait at least 3 seconds before switching on again.
✔
To improve the device's specifications, the schematic diagrams may be subject to change without prior notice.
All components marked by this symbol have special safety characteristics, when replacing any of these components use only
manufacturer's specified parts.
✔
The (µ) micro symbol of capacitance value is substituted by U.
✔
Ω
The (
) omega symbol of resistance value is substituted by E.
✔
The electrolytic capacitors are 25Vdc rated voltage unless otherwise specified.
✔
All resistors are 1/8W unless otherwise specified.
✔
All switches shown in the "OFF" position. All DC voltages measured to ground with a voltmeter 20KOhm/V.
✔
Soldering point.
Supply voltage.
✔
Male connector.
Test point.
✔
Female connector.
Flag joined with one or more flags
✔
M/F faston connector.
with the same signal name inscribed.
ATTENTION
Observe precautions when handling electrostatic sensitive devices.
Address
✒
GENERALMUSIC S.p.A. Sales Division: 47842 S.Giovanni in Marignano (RN) ITALY - Via delle Rose, 12
¤
Phone 0541/959511 - Fax 0541/957404 - GENERALMUSIC on the NET: http://www.generalmusic.com
