ENGLISH
INSTRUCTION MANUAL
Wireless Borescope
• 6FT ARMORED
GOOSENECK
• 9MM CAMERA WITH
ON-BOARD LED LIGHTS
• RECHARGEABLE
LITHIUM ION BATTERY
• WIFI CONNECTION*
TO iPHONE
AND MOST
®
ANDROID
PHONES
®
*App is optimized for:
• Apple
iOS version 6 or higher
®
versions 4.0 or higher
• Android
®
9 m
3 m
IP67/42*
*Camera is rated IP67.
Body is rated IP42.
ESPAÑOL
pg. 17
FRANÇAIS
pg. 33
ET20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ET20 and is the answer not in the manual?

Questions and answers

Related Manuals for Klein Tools ET20

Summary of Contents for Klein Tools ET20

  • Page 1 ET20 ENGLISH INSTRUCTION MANUAL Wireless Borescope • 6FT ARMORED GOOSENECK • 9MM CAMERA WITH ON-BOARD LED LIGHTS • RECHARGEABLE LITHIUM ION BATTERY • WIFI CONNECTION* TO iPHONE AND MOST ® ANDROID PHONES ® *App is optimized for: • Apple iOS version 6 or higher ®...

  • Page 2: General Specifications

    ENGLISH GENERAL SPECIFICATIONS Klein Tools ET20 is a WiFi-connected borescope with a 0.35" (9mm) camera and a 6' (1.8 m) armored gooseneck. The video output is displayed on Android and iOS powered phones by ® ® a WiFi signal transmitted from the Borescope. The camera output can only be displayed on an iOS and/or Android device using the Klein Tools Borescope App, available on Google Play ®...
  • Page 3 WARNINGS KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE To ensure safe operation and service of the instrument, follow these instructions. Failure to observe these warnings can result in serious personal injury, re, or electrical shock. • The borescope, including the camera end, is NOT insulated. Avoid probing areas where energized conductive elements may be present.
  • Page 4 5mm between the radiator and your body. EU DECLARATION OF CONFORMITY Hereby, Klein Tools declares that this product is in compliance with Directive 2014/53/EU and all other applicable EU requirements. The complete declaration of conformity can be found on this product’s page at www.kleintools.com.

  • Page 5: Feature Details

    FEATURE DETAILS FRONT BACK NOTE: There are no user- serviceable parts inside. Power Button Increase Camera LED Output Button Decrease Camera LED Output Button WiFi Indicator Battery Status Indicator Micro USB Charging Port Charging Port Cover Pocket Clip 6' (1.8m) Gooseneck Camera Camera LED Hook Attachment...

  • Page 6: Wifi Indicator

    ENGLISH SYMBOLS ON BACK OF INSTRUMENT Warning or Wear approved NOT insulated - Will NOT protect against Caution eye protection electric shock Do not probe Conformité Européenne: Conforms Read moving ma- with European Economic Area Instructions chinery directives WEEE – DC voltage/ Electronics UKCA: UK Conformity Assessment...

  • Page 7: Downloading The App

    NOTE: Only use USB adapters/power supplies that meet specified charging requirements (see GENERAL SPECIFICATIONS section). DOWNLOADING THE APP The ET20 app is required for functionality. The app is available for free from Google Play or the App Store. CONNECTING YOUR PHONE TO THE BORESCOPE VIA WiFi 1.
  • Page 8 ENGLISH OPERATING INSTRUCTIONS DISPLAY MODE BUTTON/ICON DETAILS Photo/Video screen icon Borescope battery status Camera image Camera LED brightness slider Settings icon Rotate Image button Photo button Video start/stop button Elapsed Time (Video) Appearance while recording...
  • Page 9 OPERATING INSTRUCTIONS PHOTO/VIDEO FILE MENU BUTTON/ICON DETAILS ANDROID Previous Screen Select Items Video Menu Photo Menu Active Menu (Photo or Video) Files...
  • Page 10 ENGLISH OPERATING INSTRUCTIONS FILE MANAGEMENT MODE BUTTON/ICON DETAILS ANDROID Copy or send selected file (additional options on Android) Delete selected file Exit Edit Mode (when in Edit Mode only) File Selected Indicator Review Mode: File name Manage Mode: Files selected...
  • Page 11 OPERATING INSTRUCTIONS APP SCREEN ORIENTATION The app will display in Portriat or Landscape view, depending on the rotation of the phone. To change the orientation of the app screen, simply rotate the phone 90 degrees. Portrait View Landscape View...

  • Page 12: Taking Photos

    ENGLISH OPERATING INSTRUCTIONS ROTATING THE CAMERA IMAGE ON THE APP SCREEN Sometimes it may be necessary to rotate the camera image relative to the app screen. Each tap of the Rotate Image button will rotate the image clockwise in 90° increments. This does not affect the rotation of the entire app screen, just the camera image.

  • Page 13: Warranty

    App Store and iPhone are registered trademarks of Apple Inc., registered in the U.S. and other countries. IOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used by Apple, Inc. under license. CUSTOMER SERVICE KLEIN TOOLS, INC. 450 Bond Street Lincolnshire, IL 60069 1-800-553-4676 customerservice@kleintools.com...
  • Page 14 ENGLISH NOTES CUSTOMER SERVICE KLEIN TOOLS, INC. 450 Bond Street Lincolnshire, IL 60069 1-800-553-4676 customerservice@kleintools.com www.kleintools.com...
