  • Page 1 iEP-5020G-Series User Manual...

  • Page 2: Copyright Notice

    In no event shall ASRock Industrial, its directors, officers, employees, or agents be liable for any indirect, special, incidental, or consequential damages (including damages for loss of...

  • Page 3: Important Safety Instructions

    Important Safety Instructions For user safety, please read and follow all instructions, Warnings, Cautions, and Notes marked in this manual and on the associated device before handling/operating the device, to avoid injury or damage. 1. Read these safety instructions carefully. 2.
  • Page 4 40°C or 50°C (For input 19-36Vdc) or 70°C (For input 6-36Vdc) minimum. If further assistance is needed, please contact ASRock Industrial for further information. 19. The terminal block is suitable for V+& V- for 14~28AWG. The torque value is 0.19Nm.

  • Page 5: Replaceable Batteries

    Replaceable batteries CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS BURN HAZARD Hot surface! Do not touch! Touching this surface could result in bodily injury. To reduce risk, allow the surface to cool before touching. CAUTION The equipment is equipped with a battery-powered real-time clock circuit.

  • Page 6: Contact Information

    HDMI Licensing LLC in the United States and other countries. Contact Information If you need to contact ASRock Industrial or want to know more about ASRock Industrial, you’re welcome to visit ASRock Industrial’s website at www.asrockind.com; or you may contact your dealer for further information.

  • Page 7: Table Of Contents

    Contents Chapter 1 Introduction 1.1 Package Contents 1.2 Order Information 1.3 Optional Items 1.4 Product Specifications 1.4.1 System : iEP‐5020G‐020 1.4.2 System : iEP‐5020G‐021 1.4.3 System : iEP‐5020G‐022 1.4.4 System : iEP‐5020G‐023 1.4.5 System : iEP‐5020G‐024 1.5 Block Diagram Chapter 2 Product Overview 2.1 System Front Panel 2.2 System Top Panel 2.2.1 System : iEP-5020G-020...
  • Page 8 3.2 How to Install the Wi-Fi Module (2230/2260) to the M.2 E Key Slot (Optional) 3.3 How to Install the 4G LTE/5G Module (3042/3052) to the M.2 B Key Slot (Optional) 3.4 How to Install the M.2 SSD Device (2280) to the M.2 M Key Slot 3.5 How to Install the Memory Modules and the Heatsinks 3.6 How to Install a Nano SIM Card and Micro SD Card 3.7 How to Install the Wall Mounting Bracket (Optional)
  • Page 9 5.3.3 Intel(R) Time Coordinated Computing 5.3.4 Storage Configuration 5.3.5 Super IO Configuration 5.3.6 ACPI Configuration 5.3.7 USB Configuration 5.3.8 Trusted Computing 5.4 Hardware Health Event Monitoring Screen 5.5 Security Screen 5.6 Boot Screen 5.7 Exit Screen...

  • Page 10: Chapter 1 Introduction

    Series Chapter 1 Introduction Because the hardware specifications might be updated, the content of this documentation will be subject to change without notice. 1.1 Package Contents iEP-5020G-020 • 1 x iEP-5020G-020 • 3 x M2*2 Screw Package • 2 x 3-pin phoenix connector •...

  • Page 11: Order Information

    If any items are missing or appear damaged, contact your authorized dealer. 1.2 Order Information Model Name Description iEP-5020G-020 90PXGCC0-00000000 Basic SKU W/O RAM, SSD, ADAPTER iEP-5020G-021 90PXGCC0-10000000 POE SKU W/O RAM, SSD, ADAPTER iEP-5020G-022 90PXGCC0-20000000 5LANWIFI W/O RAM, SSD, ADAPTER iEP-5020G-023 90PXGCC0-30000000 5LAN5G W/O RAM, SSD, ADAPTER...

  • Page 12: Optional Items

    Series 1.3 Optional Items Model Name PN Description Wall Mount 13G020760000AI Attach the wall mounting brackets Kits Din Rail Kits 13G020761000AI Attach the din-rail brackets and can place to the din rail. 4G LTE Kits 14G15A004000AI ANTENNA SUB 6G x 4pcs...

  • Page 13: Product Specifications

    1.4 Product Specifications 1.4.1 System : iEP‐5020G‐020 Intel Atom® x7433RE Frequency 1.5GHz Processor BIOS AMI SPI 256 Mbit Technology DDR5 4800 MHz (Support In-Band ECC) Memory Max Capacity 16GB Socket 1 x 262-pin SO-DIMM Chipset Graphics Display Port DisplayPort 1.4a , DP++ Max resolution up to 1920x1200@60Hz RF&Antenna 6 x Antenna Hole 1 x M.2 Key B (3042/3052) with PCIe Gen3/USB 3.2 for...
  • Page 14 Series Mounting Din-Rail, Wall Mount (Optional) Mechanical Dimensions 58mm (W) x 125mm (D) x 157mm (H) Net Weight 1.208 kg Windows & Linux Support Real-Time TSN, TCC support under Linux Enablement...

  • Page 15: System : Iep-5020G-021

    1.4.2 System : iEP‐5020G‐021 Intel Atom® x7433RE Frequency 1.5GHz Processor BIOS AMI SPI 256 Mbit Technology DDR5 4800 MHz (Support In-Band ECC) Memory Max Capacity 16GB Socket 1 x 262-pin SO-DIMM Chipset Graphics Display Port DisplayPort 1.4a , DP++ Max resolution up to 1920x1200@60Hz RF&Antenna 6 x Antenna Hole 1 x M.2 Key E (2230/2260) with PCIe Gen3/USB 2 for Expansion...
  • Page 16 Series Windows & Linux Support Real-Time TSN, TCC support under Linux Enablement...

  • Page 17: System : Iep-5020G-022

    1.4.3 System : iEP‐5020G‐022 Intel Atom® x7433RE Frequency 1.5GHz Processor BIOS AMI SPI 256 Mbit Technology DDR5 4800 MHz (Support In-Band ECC) Memory Max Capacity 16GB Socket 1 x 262-pin SO-DIMM Chipset Graphics Display Port DisplayPort 1.4a , DP++ Max resolution up to 1920x1200@60Hz RF&Antenna 6 x Antenna Hole 1 x M.2 Key E (2230/2260) with PCIe Gen3/USB 2 for Expansion...
  • Page 18 Series Windows & Linux Support Real-Time TSN, TCC support under Linux Enablement...

  • Page 19: System : Iep-5020G-023

    1.4.4 System : iEP‐5020G‐023 Intel Atom® x7433RE Frequency 1.5GHz Processor BIOS AMI SPI 256 Mbit Technology DDR5 4800 MHz (Support In-Band ECC) Memory Max Capacity 16GB Socket 1 x 262-pin SO-DIMM Chipset Graphics Display Port DisplayPort 1.4a , DP++ Max resolution up to 1920x1200@60Hz RF&Antenna 6 x Antenna Hole 1 x M.2 Key B (3042/3052) with PCIe Gen3/USB 3.2 for Expansion...
  • Page 20 Series Windows & Linux Support Real-Time TSN, TCC support under Linux Enablement...

  • Page 21: System : Iep-5020G-024

    1.4.5 System : iEP‐5020G‐024 Intel Atom® x7433RE Frequency 1.5GHz Processor BIOS AMI SPI 256 Mbit Technology DDR5 4800 MHz (Support In-Band ECC) Memory Max Capacity 16GB Socket 1 x 262-pin SO-DIMM Chipset Graphics Display Port DisplayPort 1.4a , DP++ Max resolution up to 1920x1200@60Hz RF&Antenna 6 x Antenna Hole 1 x M.2 Key E (2230/2260) with PCIe Gen3/USB 2 for Expansion...
  • Page 22 Series Windows & Linux Support Real-Time TSN, TCC support under Linux Enablement...

  • Page 23: Block Diagram

    1.5 Block Diagram DSB-1020-WT DP++ Channel A DDR5 4800MHz Connector SO-DIMM Realtek RTD2168 Connector PCIe x2 Gen3 or SATA x1 M.2 Key M 1 x USB 2.0 Type C (3042/2280) 1 x USB 2.0 Connector 1 x USB 3.2 Gen2 1 x USB 3.2 PCIe x1 Gen2...

  • Page 24: Chapter 2 Product Overview

    DC-IN Connector: The V+ and V- pins provide DC power input and the chassis ground pin allows connection of the chassis to ground for better EMC compatibility. The DC power input for the iEP-5020G Series supports a voltage input range from 6V to 36V DC.
  • Page 25 Reset Button: Use this button on a computer that allows you to turn it off and on again when a program does not work correctly. Power Button : The power button allows you to turn on or off the system. You can use the power button to put your system into sleep mode, or press it for four seconds to shut down you system.
  • Page 26 Series Description HDD Status LED Wi-Fi/Bluetooth LED Status LED Definitions HDD Status LED Status Description Solid Green HDD active Blinking Green HDD accessing or reading No HDD Wi-Fi /Bluetooth LED Status Description Solid Green LED indicator behaviors vary depending on the 4G LTE / 5G module you use.

  • Page 27: System Top Panel

    Top Panel Features (For iEP-5020G-020) Top Panel Feature 2.2 System Top Panel 2.2.1 System : iEP-5020G-020 Description Antenna Hole: The antenna hole allows you to connect 5G wireless antenna to enhance wireless signal reception. 2, 3 Serial (COM) Port: The 9-pin RS232/422/485 serial connector allows you to connect devices that have serial ports.

  • Page 28: System : Iep-5020G-021/022/023

    Series 2.2.2 System : iEP-5020G-021/022/023 Description 1, 4 Antenna Hole: The antenna hole allows you to connect 5G wireless antenna to enhance wireless signal reception. LAN4/PoE1 & LAN5/PoE2: The RJ-45 LAN ports support a standard Ethernet cable for connection to local network, and support PoE.

  • Page 29: System : Iep-5020G-024

    023) Top Panel Features (For iEP-5020-024) 2.2.3 System : iEP-5020G-024 Description 1, 3 Antenna Hole: The antenna hole allows you to connect 5G wireless antenna to enhance wireless signal reception. Digital Input/Output Connector (JGPIO1): This system provides sink/source isolation 36V circuits for the customer's device. Signal Signal M C U _ S P I 0 _...
  • Page 30 Series VGA: Use a VGA cable to connect between the system and your monitor. Signal Signal RED_VGA GRN_VGA BLU_VGA VGA_SDA HS_5V VS_5V VGA_SCL...

  • Page 31: Inside View

    Motherboard Layout 2.3 Inside View Description Memory: Single Small Outline Single Inline Memory module slot designed for DDR5 memory module. M.2 Slot (E Key): The M.2 slot allows you to install 2230/2260 Wi-Fi/BT module. M.2 Slot (B Key): The M.2 slot allows you to install 3042/3052 4G LTE/5G module.

  • Page 32: Rear View

    Mounting Hole: The holes support Wall Mount and DIN Rail brackets for system in vertical position. SO-DIMM memory, hard drive and M.2 SSD are not included with this system. 2.5 Position The iEP-5020G Series should be placed in vertical position only.

  • Page 33: Chapter 3 Hardware Installation

    Chapter 3 Hardware Installation This chapter helps you install or remove important components. 3.1 How to Remove the Front Cover 1. Remove the screws on the case. 2. Then lift up and remove the front cover.

  • Page 34: How To Install The Wi-Fi Module (2230/2260) To The M.2 E Key Slot (Optional)

    Series 3.2 How to Install the Wi-Fi Module (2230/2260) to the M.2 E Key Slot (Optional) 1. Locate the WiFi Module slot on the motherboard. 2. Carefully insert the WiFi Module into the slot at a 30-degree angle. 3. Tighten the screw to secure the WiFi Module to the motherboard.
  • Page 35 5. Remove the antenna rubber on the box cover. 6. Attach the SMA cable and washer to both sides of the cover, and secure them with the nut. 7. Install the Wifi antenna onto the SMA cable. The Wi-Fi antenna and SMA cable are not provided by default. Please purchase them separately if needed.

  • Page 36: How To Install The 4G Lte/5G Module (3042/3052) To The M.2 B Key Slot (Optional)

    Series 3.3 How to Install the 4G LTE/5G Module (3042/3052) to the M.2 B Key Slot (Optional) 1. Locate the 4G LTE/5G Module slot on the motherboard. 2. Carefully insert the 4G LTE/5G Module into the slot at a 30-degree angle.
  • Page 37 5. Remove the antenna rubber on the box cover. 6. Attach the SMA cable and washer to both sides of the cover, and secure them with the nut. 7. Install the 4G LTE/5G antenna onto the SMA cable. The 4G LTE/5G antenna and SMA calbe are not provided by default. Please purchase them separately if needed.

  • Page 38: How To Install The M.2 Ssd Device (2280) To The M.2 M Key Slot

    Series 3.4 How to Install the M.2 SSD Device (2280) to the M.2 M Key Slot 1. Locate the M.2 slot on the motherboard. 2. Carefully insert the M.2 SSD (Type 2280) into the slot at a 30-degree angle.

  • Page 39: How To Install The Memory Modules And The Heatsinks

    3.5 How to Install the Memory Modules and the Heatsinks The iEP-5020G Series requires DDR5 SO-DIMM (1.2V). The SO-DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.

  • Page 40: How To Install A Nano Sim Card And Micro Sd Card

    Series 3.6 How to Install a Nano SIM Card and Micro SD Card 1. Release the screws on the iEP-5020G Series and remove the SIM/Micro SD Card slot cover.. SIM Card Micro SD C 2. With the gold contacts facing front, carefully insert the SIM Card or the SD Card into the designated slot until it clicks.
  • Page 41 3. Place the cover back and secure it to the iEP-5020G Series with screws. SD Card Turn upward 90 degrees black (-) white (+)

  • Page 42: How To Install The Wall Mounting Bracket (Optional)

    Series 3.7 How to Install the Wall Mounting Bracket (Optional) 1. Attach the wall mounting brackets to the iEP-5020G Series and secure it with screws. 2. Then you can attach the iEP-5020G Series to the wall with screws. Dimension of the iEP-5020G Series...
  • Page 43 Dimension of the iEP-5020G Series with Wall Mounting Bracket Installed 100 mm 86 mm The Wall Mounting Bracket is not provided by default. Please purchase it separately if needed. Turn upward 90 degrees...

  • Page 44: How To Install The Din Rail Mounting Bracket (Optional)

    Series 3.8 How to Install the Din Rail Mounting Bracket (Optional) 1. Attach the Din Rail Bracket to the iEP-5020G Series and secure it with screws. 2. Then you can place the iEP-5020G Series to the Din Rail. SIM Card Micro SD Admissible DIN rail : TS35/7.5 or TS35/15...

  • Page 45: How To Remove The Membranes

    SIM Card Micro SD Card 3.9 How to Remove the Membranes Please note to remove the membranes from the heatsinks before reinstall the bottom case. Turn upward 90 degrees black (-) white (+)

  • Page 46: How To Install Phoenix Connector And The Adapter (Optional)

    Series 3.10 How to Install Phoenix Connector and the Adapter (Op- tional) 1. Insert white (+) cable of the adapter into the left port of the phoenix connector, and insert the black (-) cable into the middle port. Ensure the cables are inserted to the end.

  • Page 47: Chapter 4 Motherboard

    Chapter 4 Motherboard 4.1 Motherboard Layout Top Side : COM1 VGA1 COM2 Bottom: Middle: TC_U3D_0 Top: USB 3.2 Gen2 (Type-C) LAN1 USB3_2 USB 3.2 Gen2/DP DDR5_A1 Middle: Industrial Top: Bottom: USB 3.2 Gen2 USB 2.0 USB3_3 USB2_6 DSB-1020-WT Bottom: Top: LAN2 LAN3 M2_E1...

  • Page 48: Rear Side

    Series Rear Side : SIM1 ESPI1...
  • Page 49 1 : COM Port (COM1) (RS232/422/485) 2 : COM Port (COM1) (RS232/422/485) 3 : Top : D-Sub Port (VGA1) 4 : Chassis Intrusion Header (CI1) 5 : Digital Input/Output Connector (JGPIO1) 6 : Clear CMOS Header (CLRMOS1) 7 : 12V_TEST1 8 : ATX/AT Mode Jumper (SIO_AT1) 9 : Clear CMOS Header (CLRMOS2) 10 : DACC Jumper (DACC1)

  • Page 50: Jumpers Setup

    Series 4.2 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on pins, the jumper is “Short.” If no jumper cap is placed on pins, the jumper is “Open. ” The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short”...
  • Page 51 ATX/AT Mode Jumper Setting Description Open ATX Mode (Default) (2-pin SIO_AT1) Short AT Mode (see p. 38, No. 8) The header provides auto boot function when AC power on. If you need the function, short SIO_AT1 pin 1 and pin 2. DACC Jumper Setting Description...

  • Page 52: Onboard Headers And Connectors

    Series 4.3 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard! Digital Input/Output Connector...
  • Page 53 Backside: ESPI Header (20-pin ESPI1) Signal Name (see p. 39, No. 12) C_ESPI_CLK C_ESPI_CS# DEBUG_RESET SMB_CLK_MAIN SMB_DATA_MAIN C_ESPI_IO0 C_ESPI_IO1 C_ESPI_IO2 C_ESPI_IO3 +3VSB C_ESPI_ALERT#...

  • Page 54: Expansion Slots (M.2 Sockets)

    Series 4.4 Expansion Slots (M.2 Sockets) There are three M.2 sockets on the motherboard. Signal Name Signal Name +3.3V USB_D+ +3.3V M.2 Key-E Socket (M2_E1): USB_D- 9 CNV_WGR_D1- CNV_RF_RESET 10 (see p. 38, No.11) 11 CNV_WGR_D1+ MODEM_ CLKREQ 15 CNV_WGR_D0-...

  • Page 55: Chapter 5 Uefi Setup Utility

    Chapter 5 UEFI Setup Utility 5.1 Introduction ASRock Industrial UEFI (Unified Extensible Firmware Interface) is a BIOS utility which offers tweak-friendly options in an advanced viewing interface. The UEFI system works with a USB mouse and offers users a faster, sleeker experience.

  • Page 56: Uefi Menu Bar

    Series 5.1.2 UEFI Menu Bar The top of the screen has a menu bar with the following selections: Main For setting system time/date information Advanced For advanced system configurations H/W Monitor Displays current hardware status Security For security settings...

  • Page 57: Navigation Keys

    5.1.3 Navigation Keys Use < > key or < > key to choose among the selections on the menu bar, and use < > key or < > key to move the cursor up or down to select items, then press <Enter> to get into the sub screen.

  • Page 58: Main Screen

    Series 5.2 Main Screen When you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. Because the UEFI software is constantly being updated, the following UEFI setup screens and descriptions are for reference purpose only, and they may not exactly match what you see on your screen.

  • Page 59: Advanced Screen

    5.3 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, Chipset Configuration, Intel(R) Time Coordinated Computing, Storage Configuration, Super IO Configuration, ACPI Configuration, USB Configuration, and Trusted Computing. Setting wrong values in this section may cause the system to malfunction.

  • Page 60: Cpu Configuration

    Series 5.3.1 CPU Configuration Active Processor E-Cores This allows you to select the number of cores to enable in each processor package. CPU C States Support This allows you to enable CPU C States Support for power saving. It is recommended to keep C3, C6 and C7 all enabled for better power saving.
  • Page 61 Intel Virtualization Technology When this option is set to [Enabled], a VMM (Virtual Machine Architecture) can utilize the additional hardware capabilities provided by Vanderpool Technology. This option will be hidden if the installed CPU does not support Intel Virtualization Technology. Configuration options: [Enabled] [Disabled] Intel SpeedStep Technology Intel SpeedStep technology allows processors to switch between multiple frequencies and...

  • Page 62: Power Limit

    Series Power Limit 2 Power Li mit 2 va lue i n Mi l li Wat ts. BIOS w i l l rou nd to t he nea rest 1/8W when programming. 0 = no custom override. For 12.50W, enter 12500. Processor applies control...

  • Page 63: Chipset Configuration

    5.3.2 Chipset Configuration VT-d Intel® Virtualization Technology for Directed I/O helps your virtual machine monitor better utilize hardware by improving application compatibility and reliability, and providing additional levels of manageability, security, isolation, and I/O performance. Configuration options: [Enabled] [Disabled] SR-IOV Support If system has SR-IOV capable PCIe Devices, this option Enables or Disables Single Root IO Virtualization Support.
  • Page 64 Series GNA Device (BO:D8:FO) This allows you to enable or disable GNA Device. Configuration options: [Enabled] [Disabled] Onboard LAN1 This allows you to enable or disable the Onboard LAN1 feature. Onboard LAN2 This allows you to enable or disable the Onboard LAN2 feature.

  • Page 65: Intel(R) Time Coordinated Computing

    5.3.3 Intel(R) Time Coordinated Computing #AC Split Lock Enable or Disable Alignment Check Exception (#AC). When enabled, this will assert an #AC when any atomic operation has an operand that crisses two cache lines. #GP Fault UC Lock Enable or Disable GP Fault Exception (GP#). When enabled, this will assert an GP# when encountering a Lock to un-cacheable memory before the bus is locked.

  • Page 66: Storage Configuration

    Series 5.3.4 Storage Configuration SATA Controller(s) The option allows you to enable or disable the SATA controllers. Configuration options: [Enabled] [Disabled] SATA Mode Selection AHCI supports new features that improve performance. Configuration option: [AHCI] AHCI (Advanced Host Controller Interface) supports NCQ and other new features that will improve SATA disk performance but IDE mode does not have these advantages.
  • Page 67 Hard Disk S.M.A.R.T. S.M.A.R.T stands for Self-Monitoring, Analysis, and Reporting Technology. It is a monitoring system for computer hard disk drives to detect and report on various indicators of reliability. Configuration options: [Enabled] [Disabled]...

  • Page 68: Super Io Configuration

    Series 5.3.5 Super IO Configuration COM1 Use this to set parameters of COM1. Type Select Use this to select COM1 port type: [RS232], [RS422] or [RS485]. COM2 Use this to set parameters of COM2. Type Select Use this to select COM2 port type: [RS232], [RS422] or [RS485].

  • Page 69: Acpi Configuration

    5.3.6 ACPI Configuration Suspend to RAM Suspend to R A M a l lows you to select [Disabled] for ACPI suspend t y pe S1. It is recommended to select [Auto] for ACPI S3 power saving. Configuration options: [Auto] [Disabled] Onboard LAN Power On Use this item to enable or disable onboard LAN to turn on the system from the power- softoff mode.

  • Page 70: Usb Configuration

    Series 5.3.7 USB Configuration USB Power Control Use this option to control USB power. M.2 Key_B USB Function The item enables or disables M.2 Key_B USB function.

  • Page 71: Trusted Computing

    5.3.8 Trusted Computing Security Device Support Security Device Support allows you to enable or disable BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available. Configuration options: [Enabled] [Disabled] Active PCR banks This item displays active PCR Banks.

  • Page 72: Device Select

    Series Storage Hierarchy This item allows you to enable or disable Storage Hierarchy. Configuration options: [Enabled] [Disabled] Endorsement Hierarchy This item allows you to enable or disable Endorsement Hierarchy. Configuration options: [Enabled] [Disabled] Physical Presence Spec Version Select this item to tell OS to support PPI spec version 1.2 or 1.3. Please note that some HCK tests might not support version 1.3.

  • Page 73: Hardware Health Event Monitoring Screen

    5.4 Hardware Health Event Monitoring Screen In this section, it allows you to monitor the status of the hardware on your system, including the parameters of the CPU temperature, motherboard temperature, CPU fan speed, and the critical voltage. NOTE: Options vary depending on the features of your motherboard. CPU_Fan 1 Setting This item allows you to select a fan mode for CPU Fan 1.

  • Page 74: Security Screen

    Series 5.5 Security Screen In this section, you may set, change or clear the supervisor/user password for the system. Supervisor Password Set or change the password for the administrator account. Only the administrator has the authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password.

  • Page 75: Boot Screen

    5.6 Boot Screen In this section, it will display the available devices on your system for you to configure the boot settings and the boot priority. Boot From Onboard LAN The item allows the system to be woke up by the onboard LAN. Configuration options: [Enabled] [Disabled] Setup Prompt Timeout The item...

  • Page 76: Exit Screen

    Series 5.7 Exit Screen Save Changes and Exit When you select this option, the following message “Save configuration changes and exit setup?” will pop out. Select [Yes] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option, the following message “Discard changes and exit setup?”...
