  • Page 1 EDB7 MANUAL...

  • Page 2: Information For Your Safety

    EDB7 INFORMATION FOR YOUR SAFETY! THE FCC REGULATION WARNING (for USA) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 3 EDB7 PRECAUTIONS Please keep this manual in a safe place for future reference. Power Supply Please connect the designated AC adaptor to an AC outlet of the correct voltage. Do not connect it to an AC outlet with voltage that is different to what your equipment is made for.
  • Page 4 EDB7 Handling • Do not apply excessive force to the switches or controls • Do not let Paper, metal, or any other object hit the Drumkit or the Power Adaptor • If this happens, unplug the AC adaptor from the wall outlet •...

  • Page 5: Table Of Contents

    EDB7 CONTENTS Installation Instructions Installing Frame ................... Installing Pads ..................... Installing Cymbals ..................Installing Module ..................Panel Description Front & Back Panel ..................Connections Connecting an Audio Device ..............Connecting Headphones ................Connecting an MP3 Player ................ Connecting a Computer ................

  • Page 6: Installation Instructions

    EDB7 INSTALLATION INSTRUCTIONS...

  • Page 7: Installing Frame

    EDB7 1. Installing Frame Pay attention to the direction when installing tube ③, the module holder should face to right side NEXT...
  • Page 8 EDB7 Install cymbal stand NEXT Make sure the stand sleeves are on stand!

  • Page 9: Installing Pads

    EDB7 2. Installing Pads To mount the snare and tom pads, place the pad onto the pad holder. To adjust the angle of the pad, loosen the screw of the pad holder slightly, then turn the pad holder to the desired angle and retighten the screw.

  • Page 10: Installing Module

    EDB7 4. Installing Module 1. Pull the drum cable through 2. Connect the Module to the drum the module holder. cable. Use the three finger-screws to lock the Module in place. Drum Cable Module Holder Finger Screw 3. Loosen the module holder screw to adjust the angle of the Module.

  • Page 11: Front & Back Panel

    EDB7 FRONT AND BACK PANEL 1. Kit Button Enters the Kit menu. 2. Metronome Button Turns the Metronome on or off. 3. Tempo Button Adjusts the tempo of the metronome. 4. Minus (-) Button Decreases a parameter. 5. Plus (+) Button Increases a parameter.

  • Page 12: Connections

    EDB7 9. OFF Switch Powers off the module. 10. Output/Headphone Volume Knob Controls the volume of the outputs. 1 1. DC jack Connects the 9V adapter to power up the module. 12. AUX IN jack ( 3.5 Stereo jack) Connects input devices such as MP3 player, phone, or tablet.

  • Page 13: Connecting An Mp3 Player

    EDB7 EDK924M DRUM KIT MANUAL Connecting an MP3 Player Connect an MP3 player or other audio source to the stereo AUX IN jack located on the side of the drum module. The input signal is mixed with the drum signal, allowing you to play along.

  • Page 14: Settings

    EDB7 EDK924M DRUM KIT MANUAL SETTINGS Power On/Off The Drum Kit Switch the button to ON, and the LCD will show 001. REVERB...

  • Page 15: Drum Kit Selection

    EDB7 EDK924M DRUM KIT MANUAL Drum Kit Selection The EDB7 comes with 20 Preset Kits. To change the sound, press the KIT button then +/- to select your preferred kit. Metronome Press the metronome button to start the metronome. It will automatically be set to 4/4.

  • Page 16: Setting Up A Kick Drum Pad

    EDK924M DRUM KIT MANUAL SETTING UP A KICK DRUM PAD The EDB7 comes with a switch pedal for the kick drum. However, if you want to connect a drum pad and beater, you can follow these steps to calibrate the pad to the module: 1.

  • Page 17: Maintenance

    EDB7 EDK924M DRUM KIT MANUAL MAINTENANCE Now that you’re set up and ready to play your new drum kit, there are some important things to remember to ensure your drum kit stays in good condition: • It is important to use the correct amount of force when playing the drum kit.
