  • Page 1 E-GUITAR KIT ST-STYLE MANUAL...

  • Page 2: Table Of Contents

    E-GUITAR KIT ST-STYLE CONTENTS Introduction ................... 3 Body finish .................... 4 Neck finish .................... 5 Assembling of tuners ................6 Neck ...................... 7 Bridge Assembly ..................7 Wiring ....................10 Strap buttons ..................1 1 Setting up ....................12...

  • Page 3: Introduction

    E-GUITAR KIT ST-STYLE INTRODUCTION Thank you for buying this guitar kit. All the wood, hardware and electrical components of the guitar are contained in this package. Please read the following instructions for assembly and finishing.

  • Page 4: Body Finish

    E-GUITAR KIT ST-STYLE BODY The first consideration to be made before assembling is to choose the preferred finish of the guitar body. The roasted poplar body of this kit is unfinished and unsealed, allowing you to apply any finish you like. A wide variety of finishes can be procured from DIY, timber and automotive outlets in aerosol cans making finishing straight...

  • Page 5: Neck Finish

    E-GUITAR KIT ST-STYLE NECK FINISH The neck of the guitar is supplied sealed with a light coat of matte lacquer and is ready to use. If preferred, the neck can be finished with a colour or gloss lacquer. If so, do the following.

  • Page 6: Assembling Of Tuners

    E-GUITAR KIT ST-STYLE ASSEMBLING OF TUNERS Before attaching the neck to the body, fit the tuning machine-heads to the headstock by inserting the thread through the pre-drilled holes and setting a washer and bush over it. Screw down the bush onto the thread until it fits tightly to the touch and then adjust the rear of the machine-head so that the tuning button sits vertically above the top edge of the headstock.

  • Page 7: Neck

    E-GUITAR KIT ST-STYLE NECK With the body placed face up on a protective surface, position the neck into the neck cutout until it is fully inserted. Turn the assembly over and position the neck plate (with its black protective seal) over the four bolt holes at the rear of the body and drive in the four long screws through the neck plate, body and pilot holes in the neck until all fits tightly.

  • Page 8: Bridge Assembly

    E-GUITAR KIT ST-STYLE BRIDGE ASSEMBLY Position the body face-up on a soft surface. Take the bridge and set it into the right section toward the rear of the body, allowing the sustain block (the metal block underneath the bridge) to hang into the hole through the body.

  • Page 9: Wiring

    E-GUITAR KIT ST-STYLE WIRING The pickups and controls are pre-assembled on the pickguard and simply need to be connected to the output jack socket and earth. Wiring is implemented as plug-in modules, soldering is not required. There are two loose cables in the wiring assembly. One cable has a connector and the other one has no connector.
  • Page 10 E-GUITAR KIT ST-STYLE Now position the pickguard over the front of the body in a way that the pickups and all the wiring sit neatly in the routed cavities. Ensure that the edge of the pickguard sits snugly at the end of the neck and straight to the bridge assembly.

  • Page 11: Strap Buttons

    E-GUITAR KIT ST-STYLE STRAP BUTTONS Screw the strap buttons into the pre-drilled holes at the bottom edge of the body and at the tip of the upper horn of the body.

  • Page 12: Setting Up

    E-GUITAR KIT ST-STYLE SETTING UP Fitting strings to the guitar is achieved by threading from the rear, through the sustain block to the front, emerging through the relevant saddle on the bridge. Start with the thickest string bottom E in the uppermost position on the bridge.
  • Page 13 E-GUITAR KIT ST-STYLE The neck is fitted with a truss rod which may need adjusting. When the strings are tuned up, they will try to pull away from the neck, which may mean that the action becomes too high. If this happens, use the larger of the two hex keys provided to gradually tighten the truss rod –...
  • Page 14 E-GUITAR KIT ST-STYLE To setup into nation you just have to gently touch a string, right above the twelfth fret and then pick the string. The resulting chime-like sound is a harmonic (12th fret harmonic). This harmonic should have the same pitch as when the string is pressed at the twelfth fret.
