- Page 1 RAIL SAW RAIL SAW RDS-14PN RDSC-14PN OPERATION AND MAINTENANCE MANUAL ENGLISH ENGLISH (translation of the original instruction)
-
Page 2: Warning Signs
1. WARNING SIGNS 1. WARNING SIGNS Before using the machine, carefully read the instructions contained in this manual. SAVE THESE INSTRUCTIONS: this manual contains important safety and operating instructions for the machine. It is mandatory to wear approved personal protective equip- ment, such as: - Flame retardant clothing. -
Page 3: Safety Instructions
The machine should only be used by trained, competent personnel. • Do not use the RAIL SAW for purposes other than those intended by CEMBRE or for grinding operations using the side surface of the cutting disc as this may break and cause serious injury. -
Page 4: Main Components
3. DESCRIPTION 3. DESCRIPTION Descriptions and possible configurations: • RDS-14PN RDSC-14PN* • AA-RDS • SA-RDS • • RDS-14PN-AA RDSC-14PN-AA* * RDSC type rail saws are provided with a support arm ignition control, it works only if mounted on the support arm. If the rail saw is not mounted onto the support arm, an automatic cut-off device stops the engine! Main components (Ref. - Page 5 FIG. 1...
-
Page 6: General Characteristics
3.1) General Characteristics: RDS-14PN RDSC-14PN Application range Cutting rail with suitable abrasive cutting disc support arm ignition control dimensions refer to Fig. 2 and 3, page 38 weight 25,5 Cutting group n° of revs of drive shaft 4700 drive shaft diameter mm (inch) 25,4 (1) max. - Page 7 The safety devices supplied on the RAIL SAW and listed below must be fully functional and checked before each use. If this is not the case do not use the machine and contact CEMBRE for any repairs.
-
Page 8: Technical Details
3.3) Auxiliary switching device REAR VIEW Aerial STOP button (1) (switches the rail saw off ) Hook RESET button (2) (stops the air filter cleaning alarm) Protective rubber case Battery compartment TECHNICAL DETAILS: frequency: 433 Mhz max. distance: 5 metres power: CR2032 Lithium cell battery Cover... - Page 9 3.4) Abrasive cutting discs For maximum performance, use the rail saw in conjunction with the high quality C-Rex range CEMBRE discs listed below, in compliance with the requirements of the standard EN 12413 for bonded abrasives: Dimensions Peripheral DISC speed...
- Page 10 4. PREPARING THE RAIL SAW 4. PREPARING THE RAIL SAW 4.1) Fuel mixture preparation Risk of explosion or fire, petrol is extremely flammable, handle with caution. Risk of intoxication, avoid inhalation of petrol vapours. Risk of irritation, avoid prolonged and repeated contact with skin. The rail saw has a 2-stroke air cooled engine which runs on an oil-petrol mix;...
- Page 11 non-spill fuel container min. 3 m (10ft) min. 3 m (10ft) 4.3) Mounting the cutting disc WARNINGS: – This operation must be performed with the engine switched off. – Before using a cutting disc, always verify its compatibility with the rail saw and observe the rules set out in §...
-
Page 12: Starting And Stopping The Engine
4.4) Starting and stopping the engine Always start the machine at a safe distance from the refuelling area. Start the engine only when the abrasive cutting disc is mounted. Before starting, check that the abrasive cutting disc can rotate freely. ONLY FOR RDSC-14PN TYPE: The rail saw must be started only when mounted on the support arm otherwise the engine will be stopped by a cut-off device. - Page 13 Fig. f ONLY FOR RDS-14PN TYPE : the rail saw can be started Fig. f both on the earth and when mounted on the support arm, we recommend to start the rail saw on the earth for the first phase of warming up, then to switch it off and to mount it on the arm where to start it again.
- Page 14 6. AA-RDS TYPE AUTOMATIC SUPPORT ARM 6. AA-RDS TYPE AUTOMATIC SUPPORT ARM The AA-RDS automatic support arm allows the machine to cut rail without operator contact as it picks up the motion from the rail saw and automatically simulates the movement of the ope- rator during cutting;...
- Page 15 Serial Number Numéro de série Seriennummer Número de serie Serial Number Numero di Matricola Numéro de série Seriennummer Número de serie Numero di Matricola...
- Page 16 4 dentini Fig. a d’appoggio NOTE: The fixing clamp is designed to allow a precise and secure tightening of the arm on Vignole type rails; for the fixing of the arm on different rail types contact CEMBRE. Type Vignole Contact CEMBRE...
- Page 17 15 for optimal function of the rail saw under the following conditions of use: – CEMBRE ø 350 mm cutting disc type CRDL 4381 or CRDL 4387 or similar. – Rail to be cut type UIC 60 or similar.
- Page 18 Rotate the blue lever (18) in order to lock it in the external position, to facilitate this operation it is advisable to keep the arm slightly raised from the base by gripping it in position (A) with one hand. - At the same time unlock red lever (17).
- Page 19 IMPORTANT (Ref. to figure below): Make sure that at the end of rotation, lever (L) is resting on the bushes (A) so that the spring rod is positioned downwards; otherwise, it will not be possible to support the rail saw and perform the cut. 6.3.1) Rotating the interface group The overturning of the arm from one side of the rail to the other also requires the rotation of the interface group...
- Page 20 The figure shows the correct positioning of the rail saw supported by the arm on the two sides of the rail, in stationary position. 6.4) Mounting/dismounting the rail saw on the automatic support arm Before mounting the rail saw on the support arm: Check the gear (8) is in the downward position as described in §...
- Page 21 7. CUTTING IN AUTOMATIC MODE 7. CUTTING IN AUTOMATIC MODE WARNING: - Always consult your employer’s rules and procedures to cut rails in presence of electrical traction return current. - Never leave the rail saw unattended while cutting. - Make sure that everyone keeps a safe distance away from the cutting zone. - During the cutting operation move to a safe distance and always keep the auxiliary switching device close to hand if any problems occur during cutting.
- Page 22 – With the disc in contact with the rail, completely release the arm. – The rail saw will automatically perform regular alternate movements simulating the cutting action of an operator. During operation always keep a safe distance and always monitor the cutting process in order to readily intervene in case of problems.
- Page 23 If the rail saw stops at the rail head shortly after starting the cut, it means that the cutting force is too high: rotate the adjustment ring a couple of turns towards higher values in order to put more load on the contrast spring. If the rail saw stops at the intersection between the rail web/foot towards the end of the cut, it means that the cutting force is insufficient: rotate the adjustment ring towards lower values in order to unload the suspension.
- Page 24 Description 1. Rail saw locking handle 2. Mobile arm 3. Sliding track 4. Clamp locking wheel/release 5. Cutting reference plate 6. Fixed jaw clamp 7. Stationary positioning lever 8. Knob to adjust arm height 9. Vertical arm Serial Number 10. Mobile jaw clamp Numéro de série 11.
- Page 25 8.1) Attaching the arm to the rail Place the arm on the rail, the fixed clamp is the same to that of the AA-RDS arm and follow the procedure described in § 6.1. 8.2) Adjusting the height of the manual arm The SA-RDS support arm can be adjusted to met the cutting requirements based on the rail dimensions and to allow the operator to adopt...
- Page 26 The figure shows the correct positioning of the rail saw on the support arm on both sides of the rail. 8.4) Mounting/dismounting the rail saw on the manual support arm Before mounting the rail saw on the support arm, make sure that clamp (6) is firmly locked as described in §...
- Page 27 9. CUTTING IN MANUAL MODE 9. CUTTING IN MANUAL MODE WARNINGS: - Always consult your employer’s rules and procedures to cut rails in presence of electrical traction return current. - Follow the precautions described in § 9.1. - Ensure that everyone keeps the safety distance from the cutting zone. - Remove aggregate (min.
- Page 28 – Start the cut by using regular alter- nate movements, maintaining a steady pressure during the whole cutting phase. The double articulation of the support arm will relieve the operator of the weight of the machine thus making the cutting operation easier.
- Page 29 To cut short rail sections, the section must be sta- bilised with appropriate fixtures to avoid the risk of unexpected machine movement; the stabilising support CEMBRE type SSR1 fulfils this function and is available as an accessory. SSR 1 stabilising support...
-
Page 30: Maintenance Plan
The maintenance procedures described may be carried out by the operator. For any eventual fine tuning or repairs, return to CEMBRE. The maintenance plan provided is intended for a machine which is used daily, so intervals may vary according to usage frequency. - Page 31 There are two alarm AUDIBLE ALARM OPERATIONS TO BE PERFORMED codes which sound Check the wear of the drive belt. when the machine Beep..Beep..Beep... Check: is switched off: (intermittent) • engine air filter (Ref. to § 10.1) • cover filter (Ref.
-
Page 32: Re-Setting The Alarm
RE-SETTING THE ALARM After switching off the machine, while the alarm has been trigge- red, point the auxiliary switching device towards the machine and press the yellow RESET button (2) three times in succession to reset the alarm. Each time you press the button, the machine will beep in recognition. -
Page 33: Exhaust Muffler
Minimum rpm advised: 2700 rpm. The cutting disc must remain still at minimum speed. If the cutting disk rotates at a minimum speed, contact CEMBRE. Do not use the product until the minimun running has been adjusted or repaired. 10.5) Exhaust Muffler... - Page 34 10.6) Transmission cooling system The ventilation openings situated on the side cover allow the suction of fresh air and its expulsion so that the transmission system, including the two belts, can be cooled. After use and on a daily basis it is good practice to check that these openings are perfectly cle- an.
-
Page 35: Replacing Belts
10.7) Replacing belts – Disassemble the side cover (Ref. to § 10.7). Replacing the timing belt: (spare part code: 6003791) Fig. a – Remove the belt from the pinion first. Assemble the new belt (Ref. to Fig. a) Timing belt starting from the pulley side. -
Page 36: Troubleshooting Guide
Prepare mixture with more oil. engine: Obstructed cooling fins. Clean the cooling fins. Check engine for seizure, contact CEMBRE (§ 13). - Too much exhaust Too much oil in fuel mixture. Prepare mixture with less oil. Clean spark plug, if necessary (§ 10.3). -
Page 37: Transport And Storage
During transport or storage of the machine always remove the cutting disc. To facilitate transport and protect the Rail Saw, support arms and accessories from accidental knocks and dirt, CEMBRE recommends the use of appropriate containers, robust wooden crate with convenient spaces. - Page 38 Test Certificate supplied by CEMBRE together with the machine or, if no other references are available, indicate the approximate purchase date and the machine serial number.
- Page 39 DECLARATION DE CONFORMITE - KONFORMITÄTSERKLÄRUNG - DECLARACIÓN DE CONFORMIDAD - DICHIARAZIONE DI CONFORMITÁ We Nous Wir Nos Noi: CEMBRE S.p.A. Via Serenissima, 9 – 25135 Brescia (Italy) Declare under our sole responsibility that the product - Déclarons sous notre seule responsabilité que le produit - Erklären in alleiniger Verantwortung dass das Produkt - Declaramos bajo nuestr responsabilidad que el producto...
- Page 40 CEMBRE S.p.A. CEMBRE Ltd. CEMBRE S.a.r.l. CEMBRE España S.L.U. CEMBRE GmbH CEMBRE GmbH CEMBRE Inc. 22 Avenue Ferdinand via Serenissima, 9 Dunton Park, Calle Verano 6 y 8 Geschäftsbereich Geschäftsbereich Raritan Center Business Park de Lesseps 25135 Brescia Kingsbury Road,...
