- Page 1 24” Full HD IPS Monitor MODEL: A24MT-0125 User Manual AFTER SALES SUPPORT tempo.org/support 1300 002 534 MODEL: A24MT-0125 PRODUCT CODE: 718299 01/2025...
-
Page 2: Welcome
Welcome Congratulations on your purchase! This manual tells you everything you need to know about using your new BAUHN product. ® Please take special note of any important safety and usage information presented with the symbol. ® All products brought to you by BAUHN are manufactured to the highest standards of performance and safety. -
Page 3: Table Of Contents
Contents Welcome Contents Product Overview Before Using the Product Installation Connection Position Adjustment Control Panel Operation / OSD Menu Second Screen Mode Troubleshooting Specifications Compliance and Responsible Disposal Safety Strap Installation Warranty Information... -
Page 4: Product Overview
Product Overview What's in the box Before setting up your new product, check you have everything: A. 24" Full HD IPS Monitor B. Leg Stand C. Power Adaptor D. HDMI Cable E. User Manual F. Warranty Certificate G. General Safety Warnings 4 | UNPACK AND PREPARE 4 | PRODUCT OVERVIEW... -
Page 5: Before Using The Product
Before Using the Product Please put the monitor in a flat The warning signs are marked Do not plug with wet hands, it Please unplug the monitor plane to avoid falling and when cleaning. Do not use on the back of the monitor, may cause electric shock. -
Page 6: Installation
Installation 1. First, place the monitor face down on a flat surface with a soft cloth underneath. 2. Slide the neck attachment into the back cabinet aligning the plastic slots with the metal neck attachment. Slide forward until a click is heard. If at any stage the stand is to be removed, press the plastic tab on the rear cabinet and slide the neck backwards. -
Page 7: Connection
Connection Connecting the cable HDMI All-digital connection between the monnitor and computer. Supports Full HD resolution. Requires a HDMI cable (included). Analog connection between the monitor and any computer. Supports Full HD resolution. Requires a VGA cable (not included). Connect to your headphones, amplifier or audio device, using Headphone an AUX cable (not included). -
Page 8: Position Adjustment
Position Adjustment Adjust the Angle 15° 0° -5° The screen can be tilted forward and backward. The specific adjustment angle depends on different models. Generally, it is 5±2 degrees forward and 15±2 degrees backward. When adjusting the position of the monitor, be careful not to touch or press the screen area. -
Page 9: Control Panel
Control Panel Key Indication CONTROL PANEL | 9 CONTROL PANEL| 8... -
Page 10: Operation / Osd Menu
Operation / OSD Menu Operation / OSD Menu 10 | OPERATION / OSD MENU 9 |OPERATION... - Page 11 Operation / OSD Menu Cont. 体中文 日本語 한국 OPERATION / OSD MENU CONT. | 11 OPERATION| 10...
- Page 12 Operation / OSD Menu Cont. 12 | OPERATION / OSD MENU CONT. 11 | OPERATION...
-
Page 13: Second Screen Mode
Second Screen Mode Display Mode Settings • Once you have connected the monitor to your PC/laptop, select screen resolution/display settings on your PC/laptop. • Choose the desired display mode. • For Windows 10 computers, you can also press the keyboard +"P"... -
Page 14: Troubleshooting
Troubleshooting Problems Possible solution The power indicator Check if the power is turned on and whether the power does not light up cable is connected. Whether the PC matches with plug and play. Whether the display card matches plug and play. Can't achieve plug and play Whether the 15-pin D-type connector of the signal cable... - Page 15 Troubleshooting Problems Possible solution Lack of color (red, green, Check the monitor signal cable and make sure that the blue) pins are not bent The picture is not in the Adjust the clock (CLOCK) middle or the size is not right The image has a color difference (Inaccurate...
-
Page 16: 16 | Specifications
Model A24MT-012523.8" Conditions Screen Size 23.8” Color Black Storage Temperature -20°C to 45°C Light Type LED-backlit Operating Temperature 0°C to 40°C Aspect Ratio 16:9 Operating Humidity 10% to 85% Optimum Resolution 1920x1080 FHD Response Time 14ms(MPRT) Color Gamut 16.7M , 72% NTSC Brightness 250cd/(Typ.) Refresh Rate... -
Page 17: Compliance And Responsible Disposal
Compliance and Responsible Disposal Packaging The packaging of your product has been selected from environmentally friendly materials and can usually be recycled. Please ensure these are disposed of correctly. Plastic wrapping can National Television and Computer Recycling be a suffocation hazard for babies and young children. Please ensure all packaging materials are out of Scheme reach and are safely disposed of. -
Page 18: Safety Strap Installation
Warranty Information The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour. -
Page 19: Repair And Refurbished Goods Or Parts Notice
Repair and Refurbished Goods or Parts Notice Unfortunately, sometimes faulty products are manufactured, which need to be returned to the supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of repair, some or all of your stored data may be lost. -
Page 20: Online Support
Online support Visit bauhn.com.au for the latest User Manual. Warranty returns Should you for any reason need to return this product tempo.org/support for a warranty claim, make sure to include all accessories with the product. Product does not work? If you encounter problems with this product, or if it fails to perform to your expectations, please contact our After Sales Support Centre on 1300 002 534.
