OPERATION & SERVICE MANUAL
Model: eTT-8X/ eTT-12X
Electric Tow Tractor
05/2023 − Rev. 01
For Spare Parts, Operations & Service Manuals or Service Needs
Scan the QR code or visit Tronair.com/aftermarket
Eagle Tugs
Phone: (734) 442-1000 | 800-671-0431
1 Air Cargo Pkwy East
Web: www.eagletugs.com
Swanton, OH 43558
Email: sales@eagletugs.com
