Xo XOU15WGSL Manual

Undercounter
Hide thumbs

Advertisement

Table of Contents

UNDERCOUNTER
I worked really hard
on this manual -
so please read it...

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XOU15WGSL and is the answer not in the manual?

Questions and answers

Related Manuals for Xo XOU15WGSL

Summary of Contents for Xo XOU15WGSL

  • Page 1 UNDERCOUNTER I worked really hard on this manual - so please read it...
  • Page 2 Before you proceed, take just a moment to register your XO at: www.xoappliance.com/register-your-product/ REGISTRATION HELPS YOU BY - Ensuring warranty coverage should you need service Providing ownership verification for insurance purposes Let’s XO notify you in the event of product changes or recalls.
  • Page 3 Safet y Instructions Electrical and Grounding Instructions 8 - 1 1 Installation Instruc tions Sizes and Installation Dimensions Leveling Your XO Door Handle Installation O p erating Instruc tions 12 - 19 Control System Over view Set ting the Temperature...
  • Page 4 To ensure that the installation process is successfully completed, here are few things to review... Is the unit plugged in? Are the controls on? (Panel will illuminate.) Are the controls operating correctly? Has the unit been properly leveled - both side to side and front to back - with all 4 leveling feet securely making contact with the floor? After installation, does the door open sufficiently to fully extend the shelves? Is the door sealing properly?
  • Page 5 WINE COOLERS XOU15WGS XOU24WGS XOU24WDZGS BEVERAGE CENTERS XOU15BCGS XOU15BCSF XOU24BCGS XOU24BCSF XOU24BWDDGS XOU30BWDDGS take a minute to circle your model above and record your serial number here in case you need it later...
  • Page 6 For maximum efficiency, keep the door tightly shut unless loading or unloading and never overload your XO unit. Before installing, allow your XO unit to sit upright for 2 hours at the install site. This will allow the cooling system to stabilize after transportation. Failure to follow this step may cause problems.
  • Page 7 Damages caused by ambient extremes are not covered by the warranty Your XO unit is built to operate on 115V 60Hz and should be plugged directly into a dedicated 15 amp 3 prong outlet. If you are uncertain as to the...
  • Page 8 - or - install under counter MODEL DIMENSION “A” XOU15 15” (381mm) XOU24 24” (610mm) XOU30 30” (762mm) 34 1/4” min. ALL XO UNDERCOUNTER (870mm) UNITS ARRIVE PRE-WIRED 7" (178mm) WITH LOW PROFILE PLUGS FOR EASY INSTALLATION 4" (100mm) “A”...

  • Page 9: All Other Models

    15” 24” 30” MODELS MODELS (Single or Double Door) MODELS MODELS 1/8" (867mm) HIGH 14 15/16" 23 7/8" 23 7/8" 29 9/16" (379mm) (605mm) (605mm) (751mm) MODELS WITH ALL OTHER OVERLAY DOORS MODELS THE DEPTH IS SHOWN WITHOUT HANDLES EITHER THE STANDARD OR PRO HANDLE WILL ADD 1 3/4”...

  • Page 10: Leveling Legs

    get your level out DO NOT NEGLECT THIS IMPORTANT STEP Rotate to raise or lower the LEVELING LEGS located at each of the four corners until all four legs are seated firmly on the floor and the interior floor of the unit is level both front to back and side to side.
  • Page 11 Two extra set screws are included in the hardware bag. H a n d l e O p t i o n Your XO Wine Cellar comes with both the designer stainless bar handle - and our PRO Style Handle - you get to choose which style to install...
  • Page 12 LEVELING LEGS WHAT’S THAT NOISE... You new XO is designed for quiet operation but you may hear some sounds your old unit didn’t make. Because they are new you might be concerned, but they are usually normal. Sounds can also be amplified by hard surfaces like flooring or tiles. Here is a description of the types of sounds you might hear and what might be causing them.

  • Page 13: Led Lights

    temperature Single Zone Wine Coolers and Beverage Centers have identical control panels. Single Zone Wine Cooler Temp. Settings Beverage Center Temp. Settings Factory Preset: 54 F (Ideal Storage) Factory Preset: 43 F Adjustable Range: 41 F to 64 F Adjustable Range: 34 F to 50 F Your Wine Cooler or Beverage Center remembers your temperature setting in case of a power failure and automatically adjusts to the previous setting when power is restored.

  • Page 14: Switching Modes

    Press again and the light will ch ange to amber. switching modes When you turn your XO Unit on, it is set to work in standard mode. Press ECO mode is turned on. ECO Mode is an energy saver function.
  • Page 15 beverage centers or 1 zone wine coolers ON /OFF But ton Press & Hold for 1 Second to turn ON Press & Hold for 3 Seconds to turn OFF Press to Silence Alarm Light Function But ton Toggle Bet ween 3 Light Functions L1, L2, L3 Indicator Light TEMPER ATURE D ISPL AY...
  • Page 16 2 zone wine coolers ON /OFF But ton Press & Hold for 1 Second to turn ON Press & Hold for 3 Seconds to turn OFF Press to Silence Alarm Light Function But ton Toggle Bet ween 3 Light Functions L1, L2, L3 Indicator Light TEMPER ATURE D ISPL AYS...
  • Page 17 wine bottles can this hold Wine bottles come in many shapes and sizes. The following MAXIMUM capacities are based on two of the most popular types in 750 ml. MODEL WIDTH ZONES BORDEAUX BURGUNDY 6 Shelves of 5 5 Shelves of 3 XOU15WGS 15”...
  • Page 18 A LL S HE LVES MUST BE PUSHED A LL THE WAY I N BEFORE CLOSI NG THE DOOR DOOR MUST BE FULLY OPENED BE FORE PULLI NG SHELVES OUT Easy to change + more shelf positions give you more storage options with XO.
  • Page 19 (All double door beverage center side and outdoor models) STEP 1: Remove the Beverage Center shel f SHELF With the shelf pushed all the way in, tilt one side of the shelf up as far as it will go.
  • Page 20 Door Surface - Use only mild, non-abrasive detergents applied with a clean sponge or soft cloth. Rinse well with damp cloth. NOTE: Do not use cleaners containing ammonia or alcohol on your XO unit. Ammonia or alcohol can damage the appearance of the appliance.
  • Page 21 for best results change every 3 to 6 months Your Air Refresh Charcoal Filter s Located H ere P/N: XOUAIRFILTER Rotate the filter 1/4 turn to unlock Pull straight out to remove Align the tabs and inser t the new filter Rotate filter 1/4 turn to lock in place...
  • Page 22 This may be a sensor malfunction. Unplug the unit and call for service. more “q & a” Why does condensation form on the inside or outside of my XO unit? It may be that the door is either opened repeatedly or not closed completely. It may also be due to an excessive ambient humidity, in which case it will clear when the humidity drops.

  • Page 23: Warranty

    OUTSIDE U.S. This warranty does not apply to, and XO is not responsible for, any warranty claims made on products sold or used outside the 48 continental United States.
  • Page 24 UNDERCOUNTER When buying any XO appliance you can be confident you have chosen a high quality, innovative and stylish product from a company that cares about you! If you require service or have questions, Help is only a phone call away - call: 973-403-8900 Talk to one of our undercounter experts.
