Summary of Contents for Camouflage EZ4G-PRO
- Page 1 Trail Camera EZ4G-PRO Instruction Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS QUICK START WHOLE VIEWS AND DETAILS OF THE CAMERA INTRODUCTION OPERATION LIST SPECIFICATIONS TROUBLESHOOTING WARRANTY ATTENTION... - Page 3 CAMOUFLAGE WEBSITE Scan the QR code to go directly to our website, where you'll find a wide range of videos, guides, and product tutorials. Quickly and easily access all the information you need to make the most of your product!
-
Page 4: What Is In The Box
1. QUICK START 1.1 WHAT IS IN THE BOX? 1x Trail Camera 1x USB Cable 1x Mounting strap 1x Antenna 1x User Guide... -
Page 5: How To Get The Camera Ready
1. QUICK START 1.2 HOW TO GET THE CAMERA READY? 1. Insert the batteries Open the camera house and insert the batteries as electrodes marked in the battery case. Note: 8AA Alkaline or Ni-MH are recommended. For better performance, please choose the “Battery Type” of the batteries. 2. -
Page 6: How To Set Up The Camera
1. QUICK START 1.3 HOW TO SET UP THE CAMERA? 1. Power on the Camera Switch to ON; the camera is ready to work upon motion triggers (the screen will not light up upon “ON”). If you prefer default settings, you can mount it to work directly after this. - Page 7 1. QUICK START 1.4 CAMERA DEFAULT SETTINGS IN RED LETTER Camera Mode Photo/Video/PIC+Video Image Size 8M/12M/24M Multi-Shot 1/2/3/4/5P Video Size FHD (10sec), HD(10sec) Max. Range Night Mode Balanced Min. Blur Flash Power High/Low Cam ID ON/OFF OFF/ON Unlimited Max Num/Day 1~99 4G Setup Auto/Manual...
-
Page 8: Whole View And Details Of Camera
2. WHOLE VIEW AND DETAILS OF CAMERA 2.1 FIGURE 1: FRONT VIEW OF CAMERA Antenna 60 IR LEDs Indicator light • Light sensor • (day/night) Lens 60 IR LEDs... - Page 9 2. WHOLE VIEW AND DETAILS OF CAMERA 2.2 FIGURE 2: BOTTOM VIEW OF CAMERA SIM CARD Golden Part Faces Front Housing Side...
- Page 10 2. WHOLE VIEW AND DETAILS OF CAMERA 2.3 FIGURE 3: INTERNAL, SIDE AND BACK VIEW OF CAMERA SIM CARD Golden Part Faces Front Housing Side...
-
Page 11: Fully Functionality Introduction
3. INTRODUCTION With contents in previous pages, believe you’ve already got a brief idea about how this camera works. Before more details are presented, here we want to thank you for choosing one of our easy operation highly qualified products. You now may enjoy the excellence reflected in this series product. - Page 12 3. INTRODUCTION A. BATTERIES The camera runs on 8AA-size batteries and can work with alkaline and high-quality NiMH rechargeable batteries. However, we suggest running the camera with NiMH batteries only as the performance of alkaline batteries is much poorer than NiMH batteries. Pls also choose the battery type you’re using in the menu option “Battery Type”...
-
Page 13: Solar Panel
3. INTRODUCTION B. SOLAR PANEL To give users a better user experience, our engineers designed this camera to work with most standard 12V/2A lithium battery built-in solar panels. Solar panels can’t charge the batteries when using in-camera battery cases. C. POWER ADAPTOR—SECURITY SURVEILLANCE PURPOSE This camera can also be powered by an external 12V/ 2A DC adapter. -
Page 14: Sd Card Selection
3. INTRODUCTION 3.3 SD CARD SELECTION Using a memory card is required to operate the camera. When the camera is "ON" and no memory card is used, the screen displays "No card". The SD slot of the camera has a 32 GB memory capacity. Before inserting or removing the memory card, the camera must be turned "OFF". -
Page 15: Usb Connection
3. INTRODUCTION 3.4 USB CONNECTION When the camera is connected via a USB cable; the screen displays “MSDC”, press “Menu” once, and “MSDC” turns to “PC Cam”, The camera now can be used as a PC camera; press “Menu” again, camera exits PC camera mode. -
Page 16: Key Features
3. INTRODUCTION 3.6 KEY FEATURES 0.4 seconds trigger speed; 100°FOV lens; 80°PIR angle; 24MP/ 1080P@30FPS; Programmable 8/12/24 Megapixel high-quality resolution; 60pcs invisible IR LEDs offer 20 meters (65 feet) real night vision distance; crystal clear day & night photo/video quality; 1 photo burst per second to get full moving track of the object;... -
Page 17: Operation List
4. OPERATION LIST 4.1 VIDEO/PHOTO PLAYBACK Turn the “Power Switch” to the SETUP position to enter test mode, press the arrow button “↑” to enter Playback; press “←” and “→” for selection, and “OK” to play photo/video. Press the button “Menu” again to exit. In Playback Mode, press the “↓”... - Page 18 4. OPERATION LIST Settings Programmable Options Photo, Video, PIC+VIDEO Photo: The camera shoots photos only based on configured Multi-shot & Image Size; 2) Video: The camera shoots videos only based on the Cam Mode configured Video Length/Size; 3) “PIC+VIDEO”, the camera shoots photo(s) first, then video upon same trigger event based on Video Length/Size and Multi-shot/ Image Size user configured;...
- Page 19 4. OPERATION LIST OFF/ ON Select “ON”, and press “OK”, to set 12 digits/ alphabets for Cam ID each camera. Such a function can help users to identify which photos are from where and which camera. ON/OFF With GPS turned ON, GPS info will be shown on the picture stamp;...
- Page 20 4. OPERATION LIST Settings Programmable Options OFF/ON Note: a) th PIR Switch off, the camera will not be able to take PIR Switch photos/ video per motion; b) With the PIR Switch on, the camera can take photos/ videos per motion even when Time Lapse is ON. High, Middle, Low Higher sensitivity is 1) more sensitive to movements by smaller subjects;...
- Page 21 4. OPERATION LIST Select “ON”, and press “OK”, to set the interval; the camera will shoot pics or video clips automatically upon the interval Time Lapse the user sets. Object motion can still trigger the camera to take photos/ videos if the PIR Switch is ON. Configurable interval: 00:00:05~23:59:59.
- Page 22 4. OPERATION LIST Other Language English, Dutch, Spanish, French Imprints of programmed camera ID, moon phase, Stamp temperature, date, and time on photo Alkaline/ NI-MH/LI Battery Type Choosing the correct battery type of batteries in the camera makes the camera perform better. Select “ON”, and press “OK”, the camera will continue to SD Cycle record photos/videos by deleting the earliest photos or...
-
Page 23: Specifications
5. SPECIFICATION Frequency band B1/B3/B7/B8/B20/B28 Max radio B1/B3/B7/B8/B20/B28 frequency Image Sensor 4 Mega Pixels Color CMOS Effective Pixels 2688x1520(16:9) Day/Night Mode IR range IR Setting 60pcs LED, 940nm-IR LED Memory SD Card (8GB – 32GB) Operating keys Lens DFOV=100°；F=2.4// Auto IR-Cut-Remove (at night) PIR Angle 80°... -
Page 24: Troubleshooting
6. TROUBLE SHOOTING 6.1 PHOTOS DO NOT CAPTURE THE SUBJECT OF INTEREST Check the “Sensor Level” (PIR sensitivity) parameter setting. For warm environmental conditions, set the Sensor Level to “High” and for cold weather use, set the sensor to “Low”. Try to set your camera up in an area where no heat resources are in the camera’s field of view. - Page 25 6. TROUBLE SHOOTING 6.3 NIGHT VISION FLASH RANGE DOESN’T MEET EXPECTATIONS Please check to make sure that batteries are fully charged or left power is enough; “Max Range” offers a better IR flash range. Given IR flash range values are based on the Max Range setting; so please adjust Night Mode to Max Range for better night vision flash range;...
-
Page 26: Warranty
7. WARRANTY With great pride and full confidence in our products, we always keep our word which are given to our customers as specified warranty terms and services below. Based on a strict QC system, we initially offer all our customers a year-long time-limited warranty, which comes along with a selectable chargeable renewal policy of warranty as one, two, three, or four years. -
Page 27: Attention
8. ATTENTION 8.1 MOUNTING INSTRUCTIONS The camera can be attached to a tree using the installation strap through the intended slots on the back to prevent the camera from falling. Choose a tree that will not move in the wind, as movement will cause false detection.
