Ignite
LITE
Ignite Lite - 2ch
Ignite Lite - 4ch (All Variants)
www.inspirehomeautomation.co.uk
rev 1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ignite LITE 2ch and is the answer not in the manual?

Questions and answers

Summary of Contents for Inspire Ignite LITE 2ch

  • Page 1 Ignite LITE Ignite Lite - 2ch Ignite Lite - 4ch (All Variants) www.inspirehomeautomation.co.uk rev 1.1...
  • Page 2: What's In The Box

    WARNING Electricity is dangerous. Before commencing work, ensure that you read and understand these instructions and isolate the relevant circuit. This product should only be installed by a qualified electrician or heating engineer and should be installed in accordance to BS 7671 (IEE Wiring Regulations), or to another equivalent standard.
  • Page 3: Specification

    INTRODUCTION The Ignite Lite - 2ch series is designed to control a typical domestic central heating system. The system can switch two independent channels, Central Heating and Hot Water (if applicable). The Ignite Lite - 4ch series is designed to control a zoned domestic central heating system.
  • Page 4 If you have a large number of WiFi devices in the property or you cannot get a good WiFi signal at your Receiver location (you can use your phone to get a good indication of WiFi signal strength), then we would strongly recommend that you upgrade your WiFi Network.
  • Page 5 Fig 2 As shown in Fig 2, ideally the Smart Sensor should be mounted on an internal wall at a height of 1 .5m and in a high traffic area. Avoid locating near draughts such as the front door or windows. Do not position above heat sources and avoid direct sunlight.
  • Page 6 The rooms where the Smart Sensors are located must have a working radiator and the Thermostatic Radiator Valve (TRV) must be removed if present. Most TRV's can be removed by turning it up to the maximum setting, gently pushing down from the top and undoing the metal collar.
  • Page 7: Installation

    Please consult your boiler installation manual for guidance on how to wire in external controls. Usually, there will be a wire link to remove on the boiler terminal block, then these two terminals are wired to terminals 3 & 4 on the Inspire Terminal board as shown in Fig 5.
  • Page 8 The majority of combi boilers can be wired using the 4 wire installation method. If your boiler manual suggests a 3 wire install, then refer to Fig 6, remembering to remove the link wire in the boiler (if required) and add a link wire between terminals 4 &...
  • Page 9 SYSTEM BOILER WITH EXISTING CONTROLS System Boiler with existing 2 channel programmer and optional Thermostat **Before commencing, take clear photos of the existing programmer wiring** S Plan (2 x 2 port zone valves, usually near hot water cylinder) Usually 4 Wires to existing programmer, Live, Neutral, CH ON, HW ON. (CH OFF and HW OFF not used) Y plan (1 x 3 port zone valve, usually near the hot water cylinder) Usually 5 wires to existing programmer, Live, Neutral, CH ON, HW ON, HW OFF.
  • Page 10 Once each wire is identified, remove the existing wires from the old programmer and install the Inspire Ignite Receiver as described in Installation - Receiver on page 13. Install the previously identified wires into the appropriate terminals (see Fig 8). As an example, the black wire in terminal 4 of the old programmer is identified as "CH ON"...
  • Page 11 Once each wire is identified, remove the existing wires from the old programmer and install the Inspire Ignite Receiver as described in Installation - Receiver on page 13. This is an example of existing programmer wiring.
  • Page 12 3. You would transfer zones 1 & 2 to CH1 and CH2, but zone 3 (The hot water zone) would be moved to CH4/HW in the inspire system. CH3 in this case would not be used.
  • Page 13 INSTALLATION - RECEIVER If you have a single gang back box, secure the receiver to this using two of the M3.5 screws provided. If you do not have an existing back box, use the receiver as a template and mark the location of the two holes on the wall.
  • Page 14: Testing The System

    Tools -> Register Thermostat from within the app. Or scan the QR code at the front of the manual for further assistance. Important You will need to be in the same location as the inspire system to complete the initial setup.
  • Page 15 IGNITE SMART SENSOR Note: Press button twice to Boost Heating On or Off. IGNITE RECEIVER...
  • Page 16: Video Tutorials

    Please go to www.inspirehomeautomation.co.uk/videos to get started on using your new Inspire system. PHONE APP Please go to this weblink to download the app www.inspirehomeautomation.co.uk/apps or search for "Inspire Home Automation" in the app store. TROUBLESHOOTING Please visit our website for further help and assistance: www.inspirehomeautomation.co.uk/help...
