Quoizel Elrod QFA6805MBK Installation Manual

WARNINGS AND CAUTIONS
Please read and understand this entire manual before attempting to assemble, install or operate the product.
WARNING
• RISK OF ELECTRIC SHOCK - Before beginning installation, turn off electricity at the circuit breaker box or the main fuse box.
• RISK OF FIRE - Use bulbs specified by the markings and/or labels on the fixture.
• RISK OF PERSONAL INJURY - DO NOT bend the blades when installing the fan, or cleaning the fan. Do not insert foreign objects in between
rotating fan blades.
• RISK OF FIRE, ELECTRIC SHOCK, OR PERSONAL INJURY - mount to outlet box marked (acceptable for fan support of 22.7kg(50lbs) or less)
and use mounting screws provided with the outlet box.
• All set screws must be checked, and re-tightened where necessary, before installation.
• After making the wire connections, the wires should be spread apart with the grounded conductor and the equipment-grounding conductor on one
side of the outlet box and the ungrounded conductor on the other side of the outlet box.
• Suitable for use with solid-state speed controls.
• use only with light kits marked suitable for use in damp locations.
• This unit weighs 9.94 kg (
CAUTION
• For your safety, read instructions completely before beginning installation.
• If in doubt about electrical installation, consult a licensed electrician.
• Disconnect fixture from the power source before replacing bulbs or cleaning. Make sure the bulbs are given sufficient time to cool be before
removing.
TOOLS REQUIRED
CARE AND MAINTENANCE
• Wipe clean using soft, dry cloth or static duster. Always avoid using harsh chemicals and abrasives to clean fixture as they may damage
the finish.
If you need further assistance call Quoizel Customer Care at 1-800-645-3184 (9:00am - 5:00pm EST), or visit us on-line at
www.quoizel.com.
PACKAGE CONTENTS
Fixture Body
A
x 1
PACKAGE CONTENTS (PARTS BAG 1)
Lock Washer
AA
x 4
Spring Washer
BB
x 4
INSTALLATION GUIDE FOR QFA6805MBK
READ AND SAVE THESE INSTRUCTIONS
21.87 lbs).
Inner Backplate
[pre-assembled to ceiling
B
canopy of Fixture Body]
x 1
CC
DD
Flat Washer
x 4
Wire Connector
[1pc replacement
connector included]
x 3
- 1 of 4 -
Released Date: 2024-09-18
Mounting Screw
[pre-assembled to ceiling
C
canopy of Fixture Body]
x 4
D
Blade
Assembly Nut
E
x 1
Screw Mechanical Screw
EE FF
x 2 x 2
Fan Blade
x 1
