Bauhn RQ2422 User Manual

User Manual
Manual de usuario
TRUE WIRELESS BLUETOOTH EARBUDS
VERDADEROS AURICULARES BLUETOOTH INALÁMBRICOS
EN
Safety information
Please read the safety instructions carefully before using the product for the
first time and keep the instructions for future reference.
1. This product is not a toy. Keep it out of reach of children.
2. Warning: This product includes lithium polymer batteries.
3. Keep product out of the reach of children and pets to avoid chewing and
swallowing.
4. Product operating and storage temperature is from 32 degree Fahrenheit to 104
degree Fahrenheit. Under and over this temperature might affect the function.
5. Never open the product. Touching the inside electrics can cause electric
shock. Repairs or service should only be performed by qualified personnel.
6. Do not expose to heat, water, moisture, direct sunlight!
7. Please remove the earphones in case of any leakage or excessive heat
from the product to avoid burns or rash.
8. Please protect your ears against loud volume. Loud volume can damage
your ears.
9. Bluetooth wireless technology operates within a range of about 10 m (30
feet). The maximum communication distance may vary depending on the
presence of obstacles (people, metal objects, walls, etc.) or the electro-
magnetic environment.
10. Microwaves emitting from a Bluetooth device may affect the operation of
electronic medical devices.
11. The earbuds are IPX5 waterproof.
1 2 3
Delivery Content:
1. Two earbuds (L / R) 2. USB charging cable
3. Charging case 4. Instruction manual
Usage Instructions
1. Pairing the earbuds with
your smartphone
2
EN
Step 1. The earbuds would turn on once the cover of charging case is opened
(no need to take the earbuds out of it), or long press the touch panels of
both earbuds to turn on the earbuds, with voice prompt of 'Power on'.
Step 2. RED and BLUE LED would start blinking on both the earbuds.
Both of the earbuds would automatically pair with each other within 5 secs.
Once they are paired with each other, one of the earbuds would show a RED
and BLUE LED blinking alternatively, which means they are ready to pair
with your smartphone.
Step 3. Now switch on Bluetooth in your smartphone to search for nearby
devices and pair with the name 'RQ2422' with voice prompt 'Connected'
after the pairing succeed. Enter '0000' if prompted for password.
The earbuds would re-connect with smartphone automatically after pairing.
Notes:
The L or R earbud can be used alone to pair with your smartphone, and
thus only mono sound is available.
2. During Music Playback
User Manual
2.1 Touch the L or R panel ONCE to Play / Pause the track
Manual de usuario
2.2 Touch the L or R panel TWICE to skip to Next track
2.3 Touch the L or R panel THREE TIMES to skip to Prev. track
2.4 Long touch the L or R panel for 3 seconds to trigger the Siri or Google
Assistant.
3. During Calls
3.1 Touch the L or R panel ONCE to attend the incoming call / end the call.
3.2 Touch the L or R panel for 2 seconds to reject the incoming call.
4
4. Charge the Earbuds & Charging Case
4.1 Put the earbuds back into the charging case and close the cover of it,
Touch panel the earbuds power off and start charging automatically.
4.2 When the Case is charging, the case indicator blinks, and indicator glows
when the case is fully charged.
Note: The charging case can be charged both by standard USB-C cable and
wireless charging pad (not included.)
3
EN
5. Product Parameters
Model name: RQ2422
Bluetooth version: 5.3
Bluetooth name: RQ2422 (L / R / Both Earbuds)
Standby time: Approx. 40 hours
Music playback time: up to 7 - 8 hours (40% volume)
Earbuds battery capacity: 40 mAh x L / R
Charging case battery capacity: 450 mAh
Please notice - All products are subject to change without any notice.
We take reservations for errors and omissions in the manual.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
This device may not cause harmful interference,and This device must accept any
interference received, including interference that may cause undesired operation.
Caution: Changes or modifications of this product is not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.FCC ID: 2A9MY-RQ2422
4
3
711817
RQ2422 07/2025
EN
