Features
Martphone APP control (need to buy 2.4GHz gateway)
●
2.4G RF wireless remote control
●
Push dimming function
●
Trailing edge phase-cut technology
●
0~100% stepless dimming and icker free
●
Lowest brightness setting function
●
Built-in temperature detecting switch, over heart /loading
●
protection
Auto transmitting function, unlimited control distance
●
Screw connector is reliable and easy to do installation
●
Anti- re PC shell is more safety
●
Parameters
Name: AC Triac Dimmer
Model No.:
TRI-C1
Input Voltage:
100-240V~ 50/60Hz
Output:
100-240V~
Output Current:
Max 1.36A
Output Power:
150W @110V; 300W @220V
Protocol:
2.4GHz RF
Control Distance:
2.4G: 30M
AC Triac Dimmer (2.4G + Push)
Model No.: TRI-C1
IP Rating:
Working Temperature:
EMC Standard (EMC):
Safety Standard (LVD):
Radio Equipment (RED):
Certi cation:
IP20
-10~40℃
ETSI EN 301 489-1 V2.2.3(2019-11)
ETSI EN 301 489-3 V2.3.2 (2023-01)
EN 61347-2-11: 2001+A1: 2019
EN 61347-1: 2015+A1:2021
EN 62493: 2015+A1:2022
ETSI EN 300 440 V2.2.1 (2018-07)
CE, EMC, LVD, RED
Advertisement
Related Manuals for Mi-Light MiBOXER TRI-C1
Summary of Contents for Mi-Light MiBOXER TRI-C1
- Page 1 AC Triac Dimmer (2.4G + Push) Model No.: TRI-C1 Features Martphone APP control (need to buy 2.4GHz gateway) ● 2.4G RF wireless remote control ● Push dimming function ● Trailing edge phase-cut technology ● 0~100% stepless dimming and icker free ●...
-
Page 2: Connection Diagram
Connection Diagram Short press " Link" button 1 time for Output: 100-240V remote linking. Long press "Link" button 3 seconds for Triac dimming LED light Zigbee pairing while indicator flashes Tradi�onal filament lamp quickly. Short press " Min. Set" button for mini Halogen lamp Input: 100-240V brightness. - Page 3 Compa�ble with these 2.4G RF remote controls (Purchased separately) B1 / B1-B / T1 B2 / T2 K1 / K1-B WL-Box1 Auto transmi�ng (2.4G RF remote signal) can transmit remote signal to another automa�cally while controller controller the distance between lights are 30m, the remote control distance is unlimited. (A�en�on: all must be linked with same remote) controllers...
- Page 4 2.4G RF Remote control instruc�on Linking Code Instruc�ons Triac Power Dimmer Triac Power Link / Unlink Dimmer bu�on Link Power off 10 seconds and Short press " I " bu�on Lights blink 3 �mes power on again or short 3 �mes within 3 seconds. slowly means linking press "Link"...
- Page 5 A�en�on 1. Please turn off power supply before installa�on. 2. Please ensure input voltage to be same as requirements from device. 3. Don’t disassemble device if you are not expert, otherwise it will damage it. 4. Please do not use the light in the place with widely range metal area or strong electromagne�c wave nearby, otherwise, the remote distance will be seriously affected.
