INSTALLATION INSTRUCTIONS
NAM*V2*5S
This manual must be left with the homeowner for future reference
WARNING
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, personal
injury or loss of life. Installation and service must be
performed by a licensed professional HVAC installer or
equivalent, service agency, or the gas supplier.
IMPORTANT
The Clean Air Act of 1990 bans the intentional venting of
refrigerant (CFCs, HCFCs and HFCs) as of July 1, 1992.
Approved methods of recovery, recycling or reclaiming
must be followed. Fines and/or incarceration may be
levied for noncompliance.
NOTICE
A thermostat is not included and must be ordered
separately.
In all cases, setup is critical to ensure proper system
operation.
WARNING
only be carried out by competent persons. This appliance
is not to be used by persons (including children) with
reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
Children should be supervised to ensure they do not
play with the appliance.
Contact GE Appliances at:
Homeowner:
www.geappliances.com
HVAC Pro:
www.geappliancesairandwater.com
866-814-3633
Split System USAC and USHP matches:
www.AHRIDirectory.org
GE Appliances
A Haier Company
Appliance Park
Louisville, KY 40225
508446G01 / 31-5000954
Multi-Position Air Handler

Table of Contents

General Information .......................................................3
Shipping and Packing List .............................................3
Field Control Wiring .......................................................4
Target CFM Tables ......................................................15
Requirements ..............................................................17
sions Inches (mm) ........................................................19
Installation Clearances ................................................20
Installing the Unit .........................................................20
Sensor / Bracket Installation.........................................30
Brazing Connections ...................................................32
Installing the Condensate Drain ..................................34
Condensate Drain.........................................................35
Sealing the Unit ...........................................................36
Unit Operating Sequences ..........................................37
Cooling Operation ........................................................43
Error Code / Recall Mode ............................................44
Indoor Blower Test .......................................................45
Operation .....................................................................45
Homeowner Maintenance ............................................46
Professional Maintenance ...........................................46
Sensor Maintenance ....................................................47
Decommissioning ........................................................49
NOTE - This unit is a PARTIAL UNIT AIR CONDITIONER,
complying with PARTIAL UNIT requirements of this
Standard, and must only be connected to other units
PARTIAL UNIT requirements of this Standard, UL 60335-
2-40/CSA C22.2 No. 60335-2-40, or UL 1995/CSA C22.2
No 236. Partial units shall only be connected to an
appliance suitable for the same refrigerant.
or
Maximum Altitude of application is 10,500 ft. (3,200 m)
above sea level.
The installation guidelines in this document are based on
UL60335-2-40 Edition 4. For information on installation
consistent with UL 60335-2-40 Edition 3, please refer to
www.geappliancesairandwater.com
Issue 2425
WARNING
(P) 508446G01
Page 1 of 51
R454B
