MICROWAVE OVEN
Refer to the service manual in http://itself.sec.samsung.co.kr for more information.
BASIC:
AMC2206BAB
MODEL:
AMW61AST
MODEL CODE: AMW61AST/XAO
AMW61AST/XAP
FEATURES
1. New Appearance Design
(Family looking).
2. New Local Recipes.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMC2206BAB and is the answer not in the manual?

Questions and answers

Summary of Contents for Samsung AMC2206BAB

  • Page 1 BASIC: AMC2206BAB MODEL: AMW61AST MODEL CODE: AMW61AST/XAO AMW61AST/XAP MICROWAVE OVEN FEATURES 1. New Appearance Design (Family looking). 2. New Local Recipes. Refer to the service manual in http://itself.sec.samsung.co.kr for more information.
  • Page 2 © Samsung Electronics Co., Ltd. January 2006 Printed in Korea Code No. : DE68-04058A...
  • Page 3: Table Of Contents

    Contents 1. Precaution ..................2 1-1 Safety precautions .
  • Page 4: Precautions To Be Observed Before And During Servicing To Avoid Possible Exposure To Excessive Microwave Energy

    PRECAUTIONS TO BE OBSERVED BEFORE AND DURING SERVICING TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not operate or allow the oven to be (c) Before turning on microwave power for operated with the door open. any service test or inspection within the microwave generating compartments, (b) Make the following safety checks on all check the magnetron, wave guide or...
  • Page 5: Precaution

    1. Precaution Follow these special safety precautions. Although the microwave oven is completely safe during ordinary use, repair work can be extremely hazardous due to possible exposure to microwave radiation, as well as potentially lethal high voltages and currents. 1-1 Safety precautions ( 1.
  • Page 6: Special High Voltage Precautions

    1-2 Special High Voltage Precautions 1. High Voltage Warning Do not attempt to measure any of H. V. Capacitor the high voltages --this includes the filament voltage of the magnetron. High voltage is present during any cook cycle. Before touching any components or wiring, always unplug the oven and discharge the high voltage capacitor (See Figure 1-1) 2.
  • Page 7: Specifications

    2. Specifications 2-1 Table of Specifications Model Items Sub Items AMW61AST AMC2206BAB Capacity (cu.ft.) Power Source 120 V / 60 Hz 120 V / 60 Hz Power Output Power 1000W 1100W Consumption 1500W 1550W General Display Type Control Method Electronic(Membrane)
  • Page 8: Operating Instructions

    3. Operating Instructions 3-1 Control Panel � � � � � � � � � �� �� �� �� 1. Clock: Sets current time. 2. One Minute+: Press once for every minute of cooking at High Power 3. Sound Button: Sets sound on or off. 4.
  • Page 9: Features & External Views

    3-2 Features & External Views Door Ventilation Holes Light Door Latches Turntable Coupler Roller Ring Safty Membrane Interlock Panel Holes 442mm 454.7mm 600.4mm 462.3mm - 6 -...
  • Page 10: Accessory

    3-3 Accessory Item Description Code No. Q’ty Coupler DE67-00158A Roller ring DE97-00222A Turntable DE74-20015G - 7 -...
  • Page 11: Disassembly And Reassembly

    4. Disassembly and Reassembly 4-1 Replacement of Magnetron, Motor Assembly and Lamp Remove the magnetron including the shield case, permanent magnet, choke coils and capacitors (all of which are contained in one assembly). 1. Disconnect all lead wires from the magnetron and lamp. 2.
  • Page 12: Replacement Of Door Assembly

    Door "A" Door "C" 4-3 Replacement of Door Assembly Door "A" 4-3-1 Removal of Door “C” Door "A" Door "C" Insert flat screw driver into the gap between Door “A” and Door “C” to remove Door “C”. Be careful when handling Door “C” because it is fragile.
  • Page 13: Reassembly Test

    4-3 Replacement of Door Assembly (Continued) 4-3-4 Reassembly Test After replacement of the defective component parts of the door, reassemble it and follow the instructions below for proper installation and adjustment so as to prevent an excessive microwave leakage. 1. When mounting the door to the oven, be sure to adjust the door parallel to the bottom line of the oven face plate by moving the upper hinge and lower hinge in the direction necessary for proper alignment.
  • Page 14: Replacement Of Control Circuit Board

    4-6 Replacement of Control Circuit Board 4-6-1 Removal of Ass’y Control Box 1. Be sure to ground any static electric charge in your body and never touch the touch control circuitry. 2. Disconnect the connectors from the control circuit board. S CR E W S CR E W 3.
  • Page 15: Alignment And Adjustments

    5. Alignment and Adjustments PRECAUTION 1. High voltage is present at the high voltage terminals during any cook cycle. 2. It is neither necessary nor advisable to attempt measurement of the high voltage. 3. Before touching any oven components or wiring, always unplug the oven from its power source and discharge the high voltage capacitor.
  • Page 16: High Voltage Capacitor

    5-4 High Voltage Capacitor 1. Check continuity of the capacitor with the meter set at the highest resistance scale. 2. Once the capacitor is charged, a normal capacitor shows continuity for a short time, and then indicates 9MΩ. 3. A shorted capacitor will show continuous continuity. 4.
  • Page 17: Output Power Of Magnetron

    5-8 Output Power of Magnetron CAUTION MICROWAVE RADIATION PERSONNEL SHOULD NOT ALLOW EXPOSURE TO MICROWAVE RADIATION FROM MICROWAVE GENERATOR OR OTHER PARTS CONDUCTING MICROWAVE ENERGY. The output power of the magnetron can be measured by performing a water temperature rise test. Equipment needed : •...
  • Page 18: Procedure For Measurement Of Microwave Energy Leakage

    5-10 Procedure for Measurement of Microwave Energy Leakage 1. Pour 275±15cc of 20±5°C(68±9°F) water in a beaker which is graduated to 600cc, and place the beaker in the center of the oven. 2. Start to operate the oven and measure the leakage by using a microwave energy survey meter.
  • Page 19: Troubleshooting

    6. Troubleshooting PRECAUTION 1. CHECK GROUNDING BEFORE CHECKING FOR TROUBLE. 2. BE CAREFUL OF THE HIGH VOLTAGE CIRCUIT. 3. DISCHARGE THE HIGH VOLTAGE CAPACITOR. 4. WHEN CHECKING THE CONTINUITY OF THE SWITCHES OR TRANSFORMER, DISCONNECT ONE LEAD WIRE FROM THESE PARTS AND THEN CHECK CONTINUITY WITHOUT THE POWER SOURCE ON. TO DO OTHERWISE MAY RESULT IN A FALSE READING OR DAMAGE TO YOUR METER.
  • Page 20 6-1 Electrical Malfunction (continued) SYMPTOM CAUSE CORRECTIONS Oven lamp and fan motor 1. Misadjustment or loose wiring Adjust door and latch switches. turn on of primary latch switch 2. Defective primary latch switch Oven can program but timer 1. Open or loose wiring of secondary i Adjust door and interlock switches.
  • Page 21 6-1 Electrical Malfunction (continued) Oven does not operate. *Inspection method Make sure to inspect the power relay after replacing primary Is Primary interlock switch, secondary interlock Is Fuse OK? interlock switch switch and door sensing switch. normal? Primary interlock switch Secondary interlock switch Door sensing switch *Latch switch assembly...
  • Page 22 6-1 Electrical Malfunction (continued) Buttons of the control panel do not work. *Inspection method buttons pressed Refer to User Manual in the correct order? Tact Type Switch (Tact Switch) Is the Button connector of the control panel normal? Replace PCB. Connector Membrane Type Membrane...
  • Page 23: Error Code Numbering Rule

    6-2 Error Code Numbering Rule 1. ERROR CODE NUMBERING RULE is applied to a microwave oven and an oven.(CMO, OTR, Grill, Convection, Commercial etc.) 2. All sensors and devices have their own number. ex) Gas Sensor = 1, Temp. Sensor = 2, ... 3.
  • Page 24: Error Code List

    6-2 Error Code Numbering Rule(continued) Error Code List Gas Sensor Error Code Gas Sensor Error Case (E-1X) E-11 Open E-12 Short E-13 T1 Max Time Error E-14 Dry Up / No Load Temp Sensor Error Code Temp. Sensor Error Case (E-2X) E-21 Open E-22...
  • Page 25 6-2 Error Code Numbering Rule(continued) Error Code List Eeprom Error Error Code EEPROM Error Case (E-5X) E-51 Open (Sense Failure) E-53 Read/Write Error E-54 Zero not to be set Humidity Sensor Error Code Humidity Sensor Error Case (E-6X) E-61 Open E-62 Short E-63...
  • Page 26: Exploded Views And Parts List

    7. Exploded Views and Parts List 7-1 Exploded Views M001 D049 M019 D006 D004 M002 D024 M093 T001 D002 M022 T017 M029 M015 M034 M023 H018 M020 W002 D007 D011 B018 M029 C021 C133 M051 M099 M036 B006 B001 M049 B002 M038 C004...
  • Page 27: Main Parts List

    7-2 Main Parts List (S.N.A : SERVICE NOT AVAILABLE) Level Code No. Description Specification Q’ty SA/SNA Remark M039 2501-001016 C-OIL 950nF,2.1KV,BK,35x54x80,20mm M019 3601-001198 FUSE-CARTRIDGE 250V,20A,SLOW-BLOW,CERAMI M036 DE07-00005A LAMP-INCANDESCENT -,130V,-,40W,ORG,TERMI M038 DE26-00097A TRANS H.V SHV-UT10KA,120V,60HZ,2250V,3.2 M049 DE31-10154A MOTOR SYNCHRONOUS M2HJ49ZR02,ST-16,50/60 M015 DE39-20146E ASSY POWER CORD MSP-36,-,-,-,-,-,SPT-2 3...
  • Page 28: Door & Control Parts List

    7-3 Door & Control Parts List (S.N.A : SERVICE NOT AVAILABLE) Level Code No. Description Specification Q’ty SA/SNA Remark C082 DE94-01413H ASSY CONTROL-BOX 120V60HZ,AMW61AST/XAX,S C004 DE34-00247E SWITCH MEMBRANE AMW61AST/XAP,-,W75.3,PET C006 DE61-70026A SPRING-BUTTON D17,CS,SWP,SWP,PI0.7,PI0.7 C007 DE64-01626A BUTTON-PUSH LATIN1.7,PC LEXAN141,-,-,BLA C001 DE94-01427B ASSY CONTROL-PANEL 120V60HZ,AMW617,STS,- C021...
  • Page 29: Standard Parts List

    7-4 Standard Parts List (S.N.A : SERVICE NOT AVAILABLE) Level Code No. Description Specification Q’ty SA/SNA Remark 6002-001320 SCREW-TAPPING TH,+,2S,M4,L8,PASS OUT-PANEL 6002-001325 SCREW-TAPPING TH,TORX,2S,M4,L12,ZPC(YEL) O/PANEL 6006-001170 SCREW-ASSY TAPP WS,TH,+,M4,L10,ZPC(YEL) S-M-EA 6006-001176 SCREW-ASSY TAPT WT,PH,+,M4,L8,ZPC(YEL) BKT-HVC DE60-10051A SCREW-TAP PH -,-,MSWR,-,PH,M4,-,L6,-,- MOTOR SYNC. DE60-10080A SCREW-WASHER -,-,-,-,M5,L12,-,2S,-,-...
  • Page 30: Schematic Diagrams

    8. Schematic Diagrams 8-1 Schematic Diagrams ( This Document can not be used without Samsung’s authorization ) OJ03 +12V- 1 IC04 78L05 IC01 TPM87PH47U 47uF +12V CN01 ZMM55CV1 SMW250-07AV_RED ZD01 100nF 1N4004 1N4004 1N4004 IC02 78L05 40 VDD 13 a...
  • Page 31: Electrical Parts List

    9. Electrical Parts List (S.N.A : SERVICE NOT AVAILABLE) Level Code No. Description Specification Q’ty SA/SNA Remark RAS-D2LED3-61 ASSY PCB PARTS AMW612W/XAX ,120V60HZ 3501-000264 RELAY-POWER 12VDC,-,16000MA,-,9MS,5MS RY03 3501-001154 RELAY-MINIATURE 12VDC,200MW,3000MA,1FORM RY01 3708-001551 CONNECTOR-FPC/FC/PIC 14P,1.25mm,STRAIGHT CN03 3711-000940 CONNECTOR-HEADER BOX,4P,1R,2.5mm,STRAIGH CN02 3711-004143 CONNECTOR-HEADER BOX,2P,1R,5mm/2.5mm, CN01...
  • Page 32: Wiring Diagrams

    10. Wiring Diagrams 10-1 Wiring Diagrams ( This Document can not be used without Samsung’s authorization ) NOTE: CIRCUIT SHOWN WITH DOOR IS OPENED POSITION. WARNING NOTE: FOR SERVICE REPLACEMENT USE 16 GA 105° C POWER MUST BE DISCONNECTED THERMOPLASTIC COVERED WIRE EXCEPT BEFORE SERVICING THIS APPLIANCE FOR HIGH VOLTAGE LEADS OR AS NOTED ON SPECIAL LEADS.
  • Page 33 10-1 Wiring Diagrams (Continued) ( This Document can not be used without Samsung’s authorization ) MAGNETRON HIGH VOLTAGE DIODE TO CHASSIS SECONDARY SWITCH HIGH VOLTAGE CAPACITOR DOOR SENSING SWITCH MONITOR SWITCH BOTTOM CENTER SYMBOL COLOR ORANGE HIGH VOLTAGE WHITE TRANSFORMER...
  • Page 34: Reference

    • It may happen when the Press the Start button. oven is out of order. • Contact the nearest Samsung after-sales service center. Ground • Ground problem may • If the oven is placed in a humid area, buy an electric wire in a happen when the oven is store selling electrical products.
  • Page 35 (However, the smells produced from the food exposed such as herbal remedies are not removed.) Accessory • Visit the nearest Samsung Service Center or local dealer to buy accessories. Before visiting, check the model name printed on the lower right side of the front panel of the oven.
