Morphy Richards IB29015 Operating Instructions

Stereo CD
Clock Radio
29015 OPERATING INSTRUCTIONS
Illustration
6
7
8
9
10
11
25
26
27
28
29
30
35
5
4
3
2
1
12
13
23 21 19
24 22 20
18
17
16
15
14
31 32 33 34
P.3
Location of controls
1. CD Door open.
2. CD Compartment.
3. Tuning knob : To select your radio station
4. Band switch AM-FM-FM ST.
5. Volume control
6. Alarm Mode : Off / Buzzer / Auto
7. Alarm Selector : AL 1 / AL 1+2 / AL 2
8. Function selector : CD / Radio
9. SNOOZE : Interval alarm repetition
10. Phones jack
11. FM wire antenna
12. AC power cord
13. Battery compartment
14. Speakers
15. REPEAT : To play the disc continuously
16. RANDOM : To select the random play mode
17. Skip Search (backward / forward) / MINUTE / HOUR
- CD track skip and fast search within the track
- All clock functions - minute and hour setting
18. STOP : To stop playing the disc
19. PLAY/PAUSE : To start playing the CD or to stop the disc player momentarily
20. FM stereo LED indicator
21. CD repeat function LED indicator
22. CD Random function LED indicator
23. CD Program LED indicator
24. Power LED indicator
25. POWER
26. PTS (PROGRAM) : to set programmable CD tracks
27. ALARM 1 : set
28. SLEEP
29. TIME : set
30. ALARM 2 : set
31. ALARM 1 LED Indicator
32. Digital Display
33. Dial scale and pointer
34. ALARM 2 LED Indicator
35. PM indicator
Maintenance
Do not expose your cd clock radio to extremes of temperature. The product should
be kept in a warm environment free from dust and damp. For external cleaning
use only a soft, clean, damp cloth. Use of detergents may damage the finish.
Electrical requirements
Check the voltage on the rating plate of your CD clock radio corresponds
with your house electricity supply which must be A.C. (Alternating current).
If the socket outlets in your home are not suitable for the plug supplied with
this appliance the plug should be removed and the appropriate one fitted.
WARNING: The plug removed from the mains lead, if severed, must be
destroyed as a plug with a bared flexible cord is hazardous if engaged
into a live socket outlet.
Should the fuse in the 13 amp plug require changing a 3 amp BS1362 fuse
must be fitted.
Battery back-up facility
(unit will work without a battery being fitted)
Your alarm CD clock radio is equipped with a battery back-up facility.
1 Remove the battery compartment cover (located underneath the unit) by
pushing in the clip and lifting off.
2 Insert a battery size 9 volts PP3/6LR61 (Ensure battery is inserted correctly)
3 Replace the battery compartment cover.
Should a power interruption occur the clock will continue to run, however, time
keeping will not be accurate. The display will be extinguished to conserve battery
life but the memory will retain details of the clock time and alarm settings.
If the optional battery is not installed in case of the AC power failure the display
will blink to indicate the power was interrupted. You will need to reset the clock
and alarm.
Battery back-up is designed to operate for a short period only.
If the unit is not to be used for a prolonged period, remove the battery to
avoid battery leakage.
In the interests of environmental safety : dispose of batteries safely.
More information
• Do not use your cd clock radio immediately after moving from a cold place
to a warm place as there may be condensation problems.
• Make sure that you keep your unit away from water and high temperatures.
• Clean the player with a soft cloth, or a damp chamois leather. Never use
solvents.
Notes on compact discs
• If there is a scratch, dirt or fingerprints on the CD, it may cause a tracking
error.
• Before playing, clean the CD with a cleaning cloth. Wipe the CD from the
centre out. Don't store discs in places with high temperatures or high
humidity, they can become warped. After playing, store the CD in it's case.
