Summary of Contents for Aeon NOVA Super10
- Page 1 AEON Laser U s e r M a n u a l w w w . a e o n l a s e r . n e t...
-
Page 2: Table Of Contents
Chapter 1 Safety notice Preface 1.1 General safety information --------------------------------------------------1 Thank you for choose Aeon Laser. This user manual will help you to get to know how to use our laser 1.2 Safety Notes ------------------------------------------------------------1 machine properly and effectively step by step, also learn how to maintain the machine to get as much from it.The manual is divided into six chapters,Including machine general information, safety note,... -
Page 3: General Safety Information
General safety information ＊ Preparation, change parts, maintenance and repair activities must only performed with equipment Working Principle of CO2 laser switched off, by trained personel. It is forbidden to perform unauthorized modifications and changes The word LASER is the acronym for Light Amplification by Stimulated Emission of Radiation. A CO2 to the machine. -
Page 4: Processable Materials
Natural Inorganic Materials Gemstones Shell Laser Path Hazard Label Stone Glass AEON laser equipment is very safe under normal Natural Organic Materials Leather working conditions.Laser path warning labels will be Wood affixed to possible laser paths. When operators approach Elastomer Rubber/Silicone these paths, ignoring warning labels is prohibited. -
Page 5: Application
Application Packinglist Aeon laser system is used for engraving and cutting of signs, stamps, etc. A wide variety of materials can be processed, such as rubber, acrylic, coated metal,tin,special steel,anodized aluminum, cork, cardboard, glass, leather, marble, plastics and wood. * The engraving process must only be performed with a perfectly adjusted machine. -
Page 6: Machine Parts Overview
Machine parts overview Machine parts overview Dust-proof Transmission Belt Integrated autofocus Sealed Dust-Proof Guide Rail Synchronous Drive Shaft Material Pass-through-door WIFI laser Head Control Panel Active airflow fa Waste Collection Device Cooling Fan RF Metal Tube Sealed Co2 Glass Tube External Air Compressor Port Buit-in Industrial Chiller Built-in Exhaust Fan... -
Page 7: Installation Guide
Setup and installation guide Power on Machine Turn on the power switch, Release the emergency stop button turn on the key switch Note: When installing for the first time, do NOT run the machine immediately after powering This laser machine with highly compact design, it has integrated a water cooling system and an air assist on. -
Page 8: Lcd Function Description
Opertation Panel Instruction : Set Origin : Start/Pause After power on the machine, the panel will display the following interface: : Frame : Autofocus TempFile File： 500mm/s Speed : 50.0%/50.0% MaxPower : Pulse : Return to the previous menu, 719.6mm X：... - Page 9 Laser Path Alignment Before setting the panel parameters, first set the language you are familiar with (default Each Aeon laser has gone through a standard inspection process before delivery, including the calibration language is English). of the laser path. However, during the long-distance transportation and handling of the machine, some deviations in the optical path may occur, which would affect the machine’s performance.
- Page 10 Beam Spot Location： Adjust Method： Facing the laser beam entrance of the 4th reflect mirror, cover beam entrance with acrylic sheet or multi-layer paper-based tape,continue to pulse with the glass tube, make sure that the 4 spots on the four corners of the working table all overlap and are located in the center of the 4th reflect mirror. If the dot position is offset, the adjustment measures are as follows: Note: Although the 3rd reflect mirror with the same structure as other mirrors, it is installed horizontally (to ensure the light entrance &...
- Page 11 Note：Before adjusting the reflect mirror, adjust the fastening nut on the lower edge of the screw to ensure Find red dot component on the back of first mirror (as shown below). Use a 2mm Allen key to that the adjustment screw has enough adjustable space; after finishing the adjustment, remember to adjust the adjusting nut circled in the photo.
-
Page 12: Pulse Setting
point deviation, the adjustment measures are as follows: The Pulse mode is divided into continuous pulse and Spot location： Adjust method： discontinuous pulse (Pulse). Continuous means as long Pulse Mode： PULSE as you are pressing the pulse button on the PULSE 1st reflect mirror spot 4th reflect mirror spot Pulse Duration：... - Page 13 Try Your Aeon Laser Out!!! ： Layer 1 Speed (mm/s) ： 2000 mm/s Find a piece of material suitable for processing and place it on File： tiger22 ： Power 1(%) 12.0 (Min) Speed 600mm/s the worktable, move the laser head to the upper right corner of...
- Page 14 Install 2" focus lens 2. Orderly place the lens tube, lens, .Remove the brass attachment on 3.Pull out the lens tube and remove 4.Remove the nozzle and use the lens fasteners, and brass attachment the lower edge of the lens tube. on a piece of dust-free cloth.
-
Page 15: Chiller Maintenance
This series is equipped with 5000/5200 built-in water chiller to ensure the machine’s stable working. The Aeon laser MIRA 7 has no function of refrigeration, but the water thermometer always indicates Therefore, it is necessary to routinely maintain the water source and piping of the water chiller.
